BD 11
EN
OPERATING MANUAL
LASER DISTANCE MEASURING
DEVICE
TRT-BA-BD11-TC-001-EN
Table of contents
Notes regarding the operating manual................................. 1
Safety .....................................................................................1
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
Information about the device................................................3
Transport and storage...........................................................5
Operation ...............................................................................5
Maintenance and repair ........................................................8
Errors and faults....................................................................9
Disposal .................................................................................9
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of laser radiation
This symbol indicates dangers to the health of persons
due to laser radiation.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
BD11
https://hub.trotec.com/?id=41856
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• The device may only be used in dry surroundings and must
not be used in the rain or at a relative humidity exceeding
the operating conditions.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device with a tool.
• Avoid looking directly into the laser beam.
• Never point the laser beam at people or animals.
1 EN
laser distance measuring device BD 11
• Only use the device if sufficient safety precautions were
taken at the surveyed location (e.g. when performing
measurements along public roads, on building sites etc.).
Otherwise do not use the device.
• Observe the storage and operating conditions as given in
the Technical data chapter.
Intended use
Only use the laser distance measuring device BD11 for
measuring distances, areas and volumes by means of the
integrated laser and within the measuring range specified in the
technical data. Observe and comply with the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Improper use
Do not use the laser distance measuring device BD11 in
potentially explosive atmospheres or for measurements in
liquids. Never point it at people or animals. Trotec accepts no
liability for damages resulting from improper use. In such a
case, any warranty claims will be voided.
Any unauthorised modifications, alterations or structural
changes to the device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
laser measuring devices.
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Warning of electrical voltage
There is a risk of a short-circuit due to liquids
penetrating the housing!
Do not immerse the device and the accessories in
water. Make sure that no water or other liquids can
enter the housing.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of explosive substances
Do not expose the battery to temperatures above
45 °C! Do not let the battery come into contact with
water or fire! Avoid direct sunlight and moisture. There
is a risk of explosion!
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 650nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
EN 2
laser distance measuring device BD 11
Information about the device
BD11
3
4
6
5
1
2
BD11
FUNC
UNITS
8
10
9
7
Device description
The laser distance measuring device BD11 is used to determine
distances, areas and volumes in interior spaces. Indirect
measurements are carried out employing the Pythagoras
function.
The multi-line, illuminated displayindicates the determined
values.
Owing to the dust- and splash-proof housing (IP54), the device
is also suited for use on construction sites.
Measuring distance
The range of the device can be gathered from the Technical
data chapter. Under certain conditions – e.g. at night, in twilight
or when the target is hidden in the shade – greater distances
are possible even without target plate. During the day use a
target plate to increase the distance for poorly reflecting targets.
Target surfaces
There might be measurement errors when the laser encounters
colourless liquids (e.g. water), dust-free glass, styrofoam or
other semi-permeable materials. The measurement result may
also be falsified if the laser encounters a high-gloss surface and
is deflected by it. Non-glossy, non-reflective or dark surfaces
can extend the measurement duration.
No. Designation
1 Optical sensor
2 Laser
3 MiniUSB port (for charging)
4 Eyelet for wrist strap
5 Operating elements
6 Display
Operating elements
Device depiction
No. Operating element
7 Press briefly: Switch-on/measurement button
Press for a long
time:
Button for permanent distance
measurements
8 Press briefly: Plus/Minus button
Press for a long
Reference button
time:
9 Press briefly: Delete button
Press for a long
Switch-off button
time:
10 Press briefly: Function button (area, volume or
indirect measurement)
Press for a long
time:
Unit button (ft, in, m)
3 EN
laser distance measuring device BD 11
Display
01/10
16
17
18
19
20
22
24
11
14
15
21
13
12
23
No. Display element
11 Laser active
12 Reference value front
13 Symbols for non-stop/min./max. measurement:
Measured maximum value
Measured minimum value
Δ Delta = maximum minus minimum
14 History indication
15 Charging symbol indication
16 Battery status
17 Measurement value display top section:
The three upper measurement value displays show the
past three measured values, the minimum and
maximum value or the measured values to be added or
subtracted.
18 Additional indication for units of area and volume
19 Display of the selected unit. Possible units are:
ft, ft2, ft3, in, m, m2, m
3
20 Measurement value display bottom section: The lower
measurement value display indicates the last measured
value or the result of a calculation.
21 Indication for addition and subtraction
22 Indication of lines to be measured
No. Display element
23 Measuring mode indication:
Area measurement
Volume measurement
Indirect measurement (two auxiliary
measurements)
Indirect measurement (three auxiliary
measurements)
24 Reference value rear
Technical data
Parameter Value
Model: BD11
Weight: 23.8 g
Dimensions (H x W x D): 74.5x 33.9x 14.7 mm
Measuring range: 0.05 to 30 m
Accuracy: ±3 mm*
Measuring range resolution: 1 mm
Number of recordings
logged in the history:
Type of protection: IP54
Operating temperature: 0 °C to 40 °C
Storage temperature: -20 °C to 70 °C
Laser output: < 1 mW (620-690 nm)
Laser class: II
Ø
Automatic switch-off of the
device:
Automatic switch-off of the
laser:
*under favourable conditions (good target surface, room
temperature) up to 30 m
Battery (integrated)
Type Li-ion
Nominal voltage 5 V
Capacity 200 mAh
10
10mm/10m
12mm/20m
20mm/40m
After approx. 3 minutes of
non-use
After approx. 30 seconds of
non-use
Scope of delivery
EN 4
laser distance measuring device BD 11
• 1 x Laser distance measuring device BD11
• 1 x Wrist strap
• 1 x Mini USB charging cable
• 1x Manual
Transport and storage
Operation
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
The supplied Li-ion batteries are subjects to the requirements of
dangerous goods legislation.
Observe the following when transporting or shipping Li-ion
batteries:
• The user may transport the batteries by road without any
additional requirements.
• If transport is carried out by third parties (e.g. air transport
or forwarding company), special requirements as to
packaging and labelling must be observed. This includes
consulting a dangerous goods specialist when preparing
the package.
– Only ship batteries if their housing is undamaged.
– Please also observe any other national regulations.
For transporting the device use a suitable bag to protect it from
external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• with a cover to protect it from invasive dust if necessary
• The storage temperature is the same as the range given in
the Technical data chapter.
Switching the device on
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 650nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
1. Briefly press the Switch-on/measurement button(7).
ð The display will be switched on and the device ready for
operation.
Switch-off
1. Press the Switch-off button(9) for a long time.
ð The display is switched off.
Basic settings
Aborting the measurement and deleting the display
Briefly press the Delete button(9) to abort the current
measurement or to delete the displayed measured values one at
a time. The laser switches off for this purpose.
Setting the reference value
The device always measures the total distance starting at the
reference point. This means that if the rear end of the device is
set as reference point, the length of the device will be part of
the measurement. By default the reference point is set to the
rear of the device. You can, however, also relocate the
reference point to the front part of the device.
To do so, please proceed as follows:
1. Press the Reference button(8) for a long time to relocate
the reference point to the front end of the device.
ð The Reference value front indication(12) appears on the
display.
2. Press the Reference button(8) for a long time once again
to relocate the reference point to the rear end of the
device.
When switching the device off and then on again, the reference
value will automatically be relocated to the rear end of the
device.
Changing the units
1. Press the Unit button(10) for a long time to switch
between the units for the measured values. Available units
are ft, in and m.
5 EN
laser distance measuring device BD 11
Calling up a measured value in the device history
The device automatically saves the last 10 measured values.
The saved measured values can be called up as follows:
1. Briefly press the Function button (10) five times to call up
the history.
ð The History indication(14) appears on the display.
2. Briefly press the Plus/Minus button(8) to navigate through
the history and call up the saved measured values.
ð In the History indication(14) you can see which saved
measured value is currently displayed.
3. You can return to the normal measuring menu by briefly
pressing the Delete button(9).
4. By briefly pressing the Measurement button(7) you can
use the saved value for your current measurement.
Carrying out measurements
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 650nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
Info
Note that moving from a cold area to a warm area can
lead to condensation forming on the device's circuit
board. This physical and unavoidable effect can falsify
the measurement. In this case, the display shows
either no measured values or they are incorrect. Wait a
few minutes until the device has become adjusted to
the changed conditions before carrying out a
measurement.
Info
For a correct measurement, please observe the
distances from the measuring object stated in the
technical data. If the reference point is less than
0.05metres away from the measuring object, the
device will not perform a measurement.
Carrying out single distance measurement
1. Briefly press the Switch-on/measurement button(7) to
activate the laser if it is switched off.
2. Point the laser at the target area.
3. Briefly press the Switch-on/measurement button(7) again
to perform a distance measurement.
ð The measured value is displayed in the lower
measurement value display(20) immediately.
Adding / subtracting measured values
1. Carry out a single distance measurement.
ð The measured value is indicated on the display.
2. To add a measured value, briefly press the Plus/Minus
button(8) one time.
3. To subtract a measured value, briefly press the Plus/Minus
button(8) twice.
4. Press the Switch-on/measurement button(7) to determine
the next measured value.
ð The overall result will be indicated in the lower
measurement value display(20). The individual
measured values will be indicated in the upper
measurement value displays(17).
Performing an area measurement
1. Briefly press the Function button(10) one time.
ð The symbol for area measurement appears on the
display.
2. Briefly press the Switch-on/measurement button(7) to
carry out the first measurement (e.g.length).
ð The measured value is indicated in the upper
measurement value display(17).
3. Briefly press the Switch-on/measurement button(7) again
to carry out the second measurement (e.g.width).
ð Upon pressing the Switch-on/measurement button(7)
for the second time the device calculates the area and
displays this value in the lower measurement value
display(20). The most recently measured value will be
indicated in the upper measurement value display(17).
Performing a volume measurement
1. Briefly press the Function button(10) twice.
ð The symbol for volume measurement appears on
the display.
ð The side to be measured is indicated by red arrows in
the measurement value display.
2. Briefly press the Switch-on/measurement button(7) to
carry out the first measurement (e.g.length).
ð The measured value is displayed in the upper
measurement value display(17).
3. Briefly press the Switch-on/measurement button(7) again
to carry out the second measurement (e.g.width).
ð The measured value is additionally displayed in the
upper measurement value display(17).
EN 6
laser distance measuring device BD 11
4. Briefly press the Switch-on/measurement button(7) again
A
B
to carry out the third measurement (e.g.height).
ð The measured value is additionally displayed in the
upper measurement value display(17).
ð Upon pressing the Switch-on/measurement button(7)
for the third time the device independently calculates
the volume and displays this value in the lower
measurement value display(20).
Performing a non-stop / min and max measurement
Use the non-stop measuring function to correlate
measurements e.g. with construction drawings. With this
measurement method the device can be moved closer toward
the target with the measured value being recalculated roughly
every 0.5 seconds. The corresponding maximum and minimum
measured values are displayed in the first and second line of the
upper measurement value display(17) respectively.
For instance, you can direct the laser beam at a wall and then
retreat from it step by step. Keep reading the measured values
until the desired distance is achieved.
Indirect height measurement (Pythagoras)
Using this method the length of an unknown straight-line
segment can be determined via the Pythagorean Theorem. This
method is suitable for e.g. height measurements.
Measurement requirements:
• The device is aligned horizontally to the lowest point (B) of
the line segment to be determined.
• The reference point is located at the rear of the device. See
chapter Setting the reference value.
1. Briefly press the Function button(10) three times.
1. Press and hold the Switch-on/measurement button(7) for
approx. 2 s.
ð The indications , and Δ(13) appear on the
display.
2. With reference to the target point, move the device slowly
back and forth as well as up and down (e.g.in a corner).
3. Briefly press the Switch-on/measurement button(7) to
terminate the non-stop measurement.
ð The maximum and minimum measured values and the
differenceΔ(13) between these two are indicated on
the display. Additionally, the last measured value will be
displayed in the lower measurement value display(20).
ð The symbol for indirect measurements appears on
the display.
ð The bar for the hypotenuse is marked in red.
2. Aim the device at the highest point (A) and briefly press the
Switch-on/measurement button(7) once to perform a
measurement. Make sure to hold the device as steady as
possible and place it level on the ground with the two rear
edges. The position at the two rear edges must not be
changed during the measurements!
ð The length of the line segment will be indicated in the
1st line of the upper measurement value display.
ð The bar for the horizontal leg is marked in red.
3. Align the device horizontally (point B) and briefly press the
Switch-on/measurement button(7) one time to measure
the horizontal distance.
ð The second measured value will be indicated in the
second line of the upper measurement value display.
ð The line segment to be determined is displayed as
result in the lower measurement value display(20).
7 EN
laser distance measuring device BD 11
Twofold indirect height measurement
A
B
C
This method is suitable for e.g. height measurements.
1. Briefly press the Function button(10) four times.
ð Line C is marked in red.
2. First, aim the device at the highest point (C) and briefly
press the Switch-on/measurement button(7) once to
perform a measurement. In doing so, hold the device as
steady as possible. The alignment of the device in
relation to the reference point must not be changed
during the measurements!
ð The first measured value will be displayed in the upper
measurement value display.
ð Line B is marked in red.
3. Align the device horizontally (B) and briefly press the
Switch-on/measurement button(7) one time to measure
the horizontal distance.
ð The second measured value will be indicated in the
second line of the upper measurement value display.
ð Line A is marked in red.
4. Aim the device at the lowest point(A) and briefly press the
Switch-on/measurement button(7) once to perform a
measurement.
ð The third measured value will be indicated in the third
line of the upper measurement value display.
ð The line segment to be determined is displayed as result in
the lower measurement value display(20).
Maintenance and repair
Charging the battery
The battery should be charged when the battery is low. The
battery power is shown on the display(6) in the battery status
indication(16). Proceed as follows:
1. Open the rubber side cover.
2. Connect the mini USB cable to the device.
3. The charging symbol(15) is shown on the display(6).
When the battery is fully charged, the battery symbol in the
battery status indication(16) is completely green.
Cleaning
Clean the device with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Do not use any sprays,
solvents, alcohol-based cleaning agents or abrasive cleaners,
but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
EN 8
laser distance measuring device BD 11
Errors and faults
ERROR
Li-Ion
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
Icon Cause Remedy
The battery is
almost empty.
Calculation error Repeat the measurement. Pay
The temperature is
too high.
The temperature is
too low.
The reception of the
reflected signal is
too strong or too
weak.
The ambient light is
too intense.
Recharge the battery.
attention to the measurement
sequence and position of the
device.
Allow the device to cool down.
Observe the permissible
operating temperature according
to the Technical data chapter.
Allow the device to warm up.
Observe the permissible
operating temperature according
to the Technical data chapter.
Repeat the measurement on
another surface with better
reflective properties or use a
target plate.
Change the ambient light
conditions for the measurement.
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
In the European Union, batteries and accumulators must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September 2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.
Hardware fault Repeatedly switch the device on
and off. If the symbol does not
disappear, please contact your
retailer.
9 EN
laser distance measuring device BD 11
Trotec GmbH & Co. KG
Grebbener Str. 7
D-52525 Heinsberg
+49 2452 962-400
+49 2452 962-200
info@trotec.com
www.trotec.com
Loading...
