tronical Tune User Manual

MANUAL

V 2.12

MANUAL

V 2.12

WE ARE SPINNING HEADS!

WWW.TRONICAL-COMPONENTS.COM

2

TRONICAL TUNE - INDEX

TRONICAL TUNE OVERVIEW 3

TRONICAL TUNE  INSERT/REPLACE BATTERY 45

TUNE CONTROLLER 6

GETTING STARTED INSTALL THE SYSTEM TO THE GUITAR 78

STRING YOUR GUITAR 912

STRING UP AND DOWN MODE 13

HOW TO TUNE / ADDITIONAL INFO 14

PERFORMANCE SPECIFICATION 15

START TO TUNE MULTISTRING / SINGLESTRING TUNING 1617

SWITCH BETWEEN BANKS 18

EXAMPLE 19

BANK OVERVIEW 20

FUNCTION MENU FUNCTION OVERVIEW 21

CUSTOM TUNING | SAVING 2223

REFERENCE TUNING 24

FIRMWARE VERSION 25

BATTERY LEVEL 26

CONFIGURATION MENU

OVERVIEW 27

ACCURACY MODE 28

ROBOHEAD DELAY 29

RESET MODE 30

ROBOHEAD SPEED 31

INTERFERENCE LEVEL 32

SYSTEM CONFIGURATION EXPERT MENU 3337

CHARGING THE BATTERY 38

LEGAL INFORMATION 39

WWW.TRONICAL-COMPONENTS.COM

3

6 ROBOHEADS

WITH NEW SURFACE LOCKING MECHANISM

TRONICAL TUNE  OVERVIEW

BAT

e B G D A E

MENU

INTEGRATED LEDDISPLAY

6 STRING LEDS, 1 MENU LED, 1 CHARGE LEVEL LED

BATTERY

EXCHANGEABLE, RECHARGEABLE

3.7 VOLTS, LIPOLYMER, APPROX. 300 TUNINGS

TUNE CONTROLLER

UP, DOWN, LEFT, RIGHT, ENTER

AVAILABLE SPARE PARTS

Li Po BATTERY

CHARGER WITH WALLPLUG

ROBOHEADS

TUNING CONTROLLER WITH
MOUNTING BOARD

WRENCH, LOCK NUTS &
RING WASHERS

ON/OFF/BACK

BLACK TUNING CONTROLLER

BLACK MOUNTING BOARD WITH ROBOHEAD GUIDANCE

WWW.TRONICAL-COMPONENTS.COM

4

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

INSERT BATTERY

TRONICAL TUNE

ATTENTION: USE CAUTION WHEN INSTALLING

THE BATTERY. ENSURE YOU PAY ATTENTION
TO THE SLOTTED DESIGN TO GUARANTEE
PROPPER ORIENTATION. SLIDE IN THE BATTERY
WITH THE TIP SIDE ONLY. DO NOT APPLY ANY
FORCE AS YOU MAY CAUSE DAMAGE TO THE
ELECTRONICS.

!

WWW.TRONICAL-COMPONENTS.COM

5

PRESS ON THE BATTERY
TO RELEASE.

PULL OUT THE BATTERY

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

1 2

REPLACE BATTERY

TRONICAL TUNE

ATTENTION: USE CAUTION WHEN INSTALLING THE BATTERY. ENSURE YOU PAY ATTENTION TO THE SLOTTED DESIGN

TO GUARANTEE PROPPER ORIENTATION. SLIDE IN THE BATTERY WITH THE TIP SIDE ONLY. DO NOT APPLY ANY FORCE
AS YOU MAY CAUSE DAMAGE TO THE ELECTRONICS.

!

WWW.TRONICAL-COMPONENTS.COM

6

EXPLANATION  TUNE CONTROLLER

: FREQUENCY MEASUREMENT IN PROGRESS

: INTERFERENCE BETWEEN LOWER AND HIGHER STRINGS

: STRING IN TUNE

: BATTERY FULLY CHARGED

: RESPECTIVE ROBOHEAD IS IN MOVEMENT

: FREQUENCY OUT OF PITCH WINDOW

: BATTERY IS EMPTY

: FUNCTION MENU

: ACOUSTIC GUITAR

BLINKING MENU LED

: SYSTEM CONFIGURATION

: ELECTRIC GUITAR

PUSH AND HOLD THE ”OFF-BUTTON“
TO SWITCH OFF THE SYSTEM.

i

MUTE LOWER STRINGS THAT ARE IN TUNE
AND STRUM HIGHER STRINGS AGAIN.

i

BAT

e B G D A E

MENU

RIGHT

ON/OFF/BACK

ENTER / OK

UP

DOWN

LEFT

WWW.TRONICAL-COMPONENTS.COM

7WWW.TRONICAL-COMPONENTS.COM

INSTALL THE SYSTEM TO THE GUITAR

GETTING STARTED

NOTE: DO NOT USE ANY TOOLS TO FIX THE LOCK NUT

AND DO NOT OVER TIGHTEN AS YOU MAY. USE A 1 CENT COIN TO TIGHTEN
THE LOCKNUT, OTHERWISE YOU MAY DAMAGE THE GEAR WHEELS!!

USE ONLY SUPPLIED WRENCH OR TORQUE WRENCH TO
TIGHTEN THE HEX NUTS MAX. 1NM TORQUE

IT IS RECOMMENDED TO USE A CONTACT CLEANING SOLUTION BEFORE INSTALLING
THE ROBOHEADS TO THE PCB BOARD AND TO ALSO NOT OVER TIGHTEN THE HEX NUTS
BEFORE ENSURING ALL CONTACTS ARE MAKING A GOOD CONNECTION.

USE CAUTION WHEN INSTALLING BATTERY AND ENSURE YOU PAY ATTENTION TO THE
SLOTTED DESIGN TO GUARANTEE PROPER ORIENTATION!!!

WWW.TRONICAL-COMPONENTS.COM

8

INSTALL THE SYSTEM TO THE GUITAR

GETTING STARTED

AT FIRST REMOVE ALL ORIGINAL

HEADSTOCKPARTS OF YOUR GUITAR.

TAKE THE ROBOHEADS OUT OFF THE

CONTACTING PCB.

PLACE THE CONTACTING PCB ON THE NECK

OF THE GUITAR, THE BATTERY COMPARTMENT

HAS TO FACE TOWARDS THE TOP OF

THE HEADSTOCK.

MAKE SURE THAT ALL PCB DRILL HOLES ARE

IN ALIGNMENT WITH THE NECKS TUNER HOLES.

PUT THE ROBOHEADS THROUGH THE

RESPECTIVE HOLES. MOUNT THE HEXNUTS.

USE THE WRENCH WHICH COMES

WITH THE SET TO SCREW TIGHT THE HEX

NUTS OF THE ROBOHEADS.

NOW TRONICAL TUNE IS READY TO

STRING UP YOUR GUITAR.

1

4

2

5

3

6

WWW.TRONICAL-COMPONENTS.COM

9

STRING YOUR GUITAR

GETTING STARTED

MAX. RECCOMENDED STRING GAUGES: .013 .017 .026 .035 .045 .056 THIRTEEN TO FIFTYSIXES

NOTE: HIGHER STRING GAUGES MAY CAUSE DAMAGE TO THE TUNERS!

PLEASE NOTE THE BASS SIDE ROBOHEADS TURN IN THE OPPOSITE DIRECTION FROM USUAL.
THEY NOW TURN CLOCKWISE TO SHARPEN AND COUNTERCLOCKWISE TO FLATTEN.

WWW.TRONICAL-COMPONENTS.COM

10

HOW TO USE THE STRING SHAFT WITH
SURFACE LOCKING MECHANISM

GETTING STARTED

LOCK NUT: YOU NEED THE LOCK NUT TO TIGHTEN THE STRING.

STRING SHAFT: THE STRING SHAFT WINDS THE STRING.

STRING RECESS: THE STRING RECESS GUIDES THE STRING.

HEX NUT: USE THE WRENCH WHICH COMES WITH THE SET TO

TIGHTEN THE HEX NUTS OF THE ROBOHEADS.

LOCK NUT

STRING RECESS

STRING SHAFT

HEX NUT

1

1

2

3

4

3

4

3

USE ONLY SUPPLIED WRENCH OR TORQUE WRENCH TO
TIGHTEN THE HEX NUTS MAX. 1NM TORQUE

NOTE: DO NOT USE ANY TOOLS TO FIX THE LOCK NUT

AND DO NOT OVER TIGHTEN AS YOU MAY. USE A 1 CENT COIN TO TIGHTEN
THE LOCKNUT, OTHERWISE YOU MAY DAMAGE THE GEAR WHEELS!!

WWW.TRONICAL-COMPONENTS.COM

11

SCREW OFF THE LOCK NUT AND
MAKE SURE THAT THE RECESS IS AT
AROUND 90 DEGREES TO LONG
ITUDINAL DIRECTION OF THE NECK.
YOU CAN TURN MANUALLY ON THE
KEY OR BY STRING UP MODE PAGE 11

PULL TIGHT ON THE STRING TO GET
PRETENSION AND BEND IT ONE HALF
TURN AROUND THE BOTTOM SIDE OF
THE STRING SHAFT.

MERGE THE STRING UP TROUGH THE
STRING RECESS TOWARDS THE THREAD.

NOTE

TO ENSURE BOTH HIGH „e“ & „B“
SRINGS ARE SECURELY LOCKED,
WE RECOMMEND MAKING TWO WIN
DINGS AFTER RAISING THE STRING
UP TO THE THREAD OF THE POST.

BEND THE STRING AROUND THE
SHAFT AS SHOWN IN THE PICTURE
AN SCREW ON THE LOCK NUT.

1 2 43

HOW TO USE THE STRING SHAFT

GETTING STARTED

90°

2X

WINDINGS

WWW.TRONICAL-COMPONENTS.COM

12

HOW TO USE THE STRING SHAFT

GETTING STARTED

TIGHTEN WITH A SMALL COIN THE
LOCK NUT SMOOTHLY BY HAND. THE
STRING MUST ENCIRCLE THE STRING
SHAFT COMPLETELY.

5

CUT THE END OF THE STRING CLOSE
TO THE STRING SHAFT.

6 7

NOTE: DO NOT USE ANY TOOLS TO FIX THE LOCK NUT

AND DO NOT OVER TIGHTEN. USE A 1 CENT COIN TO TIGHTEN THE
LOCKNUT, OTHERWISE YOU MAY DAMAGE THE GEAR WHEELS!!

WWW.TRONICAL-COMPONENTS.COM

13

STRING UP AND DOWN MODE

FOR RESTRINGING YOUR GUITAR

BAT

e B G D A

MENU

BAT

e B G D A

MENU

BAT

e B G D A E

MENU

SELECT WHITE “E“ LED. PUSH “ENTER“ to confirm.
The MENU LED switches OFF, The “E“ lights up RED.

PRESS “DOWN“ to unwind the low “E“ string or PRESS “UP“ to wind up the

low “E“ string.

PRESS “LEFT“ or “RIGHT“ button to choose any other string to wind up or
down in the same manner.

PRESS “BACK“ for FUNCTION MENU.

DURING “STRING UP AND DOWN MODE” THE “SINGLESTRING
TUNING MODE” IS ACTIVE. IT IS RECOMMENDED TO WIND THE
STRING ROUGHLY + 300 CENT TO STANDARD PITCH, THEN
RELEASE THE UP/DOWN BUTTON AND PLUCK THE STRING. THE
SYSTEM TAKES OVER AND WILL TUNE THE STRING TO STANDARD
PITCH AND AUTOMATICALY MOVE TO THE NEXT STRING.

E

E

D

LEFT / RIGHT

ENTER

E

SWITCH BETWEEN STRINGS

BACK

DOWN

UP

FUNCTION MENU

PUSH “ON“ button. The system activates with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.

TO ENTER

PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.

SEE ADDITIONAL

FUNCTIONS

PG. 19

!

IMPORTANT!
REFER to Page 36 to SELECT GUITAR TYPE
(ACOUSTIC or ELECTRIC INSTALLATION)

!

!

WWW.TRONICAL-COMPONENTS.COM

14

STRUM BY THUMB, CLOSE TO THE NECK JOINT SOUND HOLE, 1 STRUM = ALL STRINGS WITHIN 1 SEC.

WAIT 35 SECONDS BETWEEN TWO STRUMS

AFTER STRUMMING, MUTE STRINGS THAT ARE ALREADY IN TUNE GREEN LED ON TUNE CONTROLLER AND
STRUM THE OUTOFTUNE STRINGS ONLY.

To change the actual tuning (e.g. from Standard to DADGAD) you can select the “SINGLESTRING MODE” or the “MULTISTRING MODE” .

SINGLE STRING MODE is activated with a PRESS AND HOLD “ENTER“

MULTI STRING MODE is activated with a PUSH, “ON“ button (for details please refer to “ Tune Mode page 15 and following”).

SINGLE STRING MODE is recommended to get familiar with the system and when you use the system in a loud environment with ambient noise
(especially with acoustic guitars).

MULTISTRING MODE is recommended as the default mode as soon you are used to the system.

HOW TO TUNE / ADDITIONAL INFORMATION

RETUNING

CHANGE TUNING

GETTING STARTED

1

1

2

3

!

PLEASE NOTE THE BASS SIDE ROBOHEADS TURN IN THE OPPOSITE DIRECTION FROM USUAL.
THEY NOW TURN CLOCKWISE TO SHARPEN AND COUNTERCLOCKWISE TO FLATTEN.

WWW.TRONICAL-COMPONENTS.COM

15

1 BEST PERFORMANCE UNDER FOLLOWING CONDITIONS:

* FOLLOW THE MANUAL FROM PAGE 3 TO PAGE 14!!

* FOR THE BEST TUNING PERFORMANCE MAKE SURE THAT THE STRINGS ARE NOT STICKING IN THE NUT STRING FRICTION.

* THE INTONATION OF 12TH FRET FINGERED TO 12TH FRET HARMONIC SHOULD BE CORRECT

* FOR STANDARD TUNING 440 HZ

* DETUNING WITHIN THE NOMINAL +/ 30 CENT RANGE.

* WITH A GOOD BATTERY CHARGE, EG. ”BAT” INDICATOR IS GREEN

* ACCURACY SET TO STANDARD, 3 LEDS +/ 2.5 CENT ACCURACY

SINGLESTRING MODE

3 5 10

3 10 20

1

1 3 5

NOM

NOM

MAX

MAX

UNIT

UNIT

MIN

MIN

2

4

sec per string

sec all strings

strums per string

strums all strings

SINGLESTRING MODE

MULTISTRING MODE

MULTISTRING MODE

TUNING TIME

NUMBER OF STRUMS

PERFORMANCE SPECIFICATION

GETTING STARTED

WWW.TRONICAL-COMPONENTS.COM

16

TUNE MODE  MULTISTRING TUNING

START TO TUNE

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

1- PRESS ”ON”. The MULTI-STRING MODE activates with the last completed
tuning.

2 Strum ALL strings at once (within 1sec.)
3- Wait 3-5 seconds and mute the strings with your hand.
4 Mute the strings that are already in tune GREEN.
5 Pick only the out-of-tune strings (RED)

IT IS IMPORTANT TO STRUM THE SAME WAY ALWAYS AT THE SAME POSTION
NEAR THE END OF THE NECK WITH EITHER YOUR THUMB, FINGER OR PICK.

WHEN TUNING IS COMPLETED THE SYSTEM TURNS OFF AUTOMATICALLY.

ON

: FREQUENCY MEASUREMENT IN PROGRESS

: INTERFERENCE BETWEEN LOWER AND HIGHER STRINGS

: STRING IN TUNE

: RESPECTIVE ROBOHEAD IS IN MOVEMENT

MUTE LOWER STRINGS THAT ARE IN TUNE
AND STRUM HIGHER STRINGS AGAIN.

i

PRESS & HOLD ”ENTER” TO CHANGE TO SINGLE STRING MODE.

!

ENTER

: FREQUENCY OUT OF PITCH WINDOW

WWW.TRONICAL-COMPONENTS.COM

17

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

1- PRESS & HOLD ”ON”. The SINGLE STRING MODE activates with the last
completed tuning.

If you are in TUNING SELECTION MODE already,
select desired PRESET, then PRESS & HOLD “ENTER“
for single string tuning.

2 PICK ONE STRING AT A TIME as indicated, until all strings
are in tune GREEN.

ON

E

E

A

LEFT / RIGHT

!

TUNE MODE  SINGLESTRING TUNING

START TO TUNE

PRESS “LEFT“ OR “RIGHT“ TO SELECT A STRING YOU WOULD LIKE TO TUNE.

MUTE STRINGS THAT ARE ALREADY IN TUNE GREEN.

SEE LED EXPLANATION ON PAGE 4 OR SEE MULTISTRING TUNING

WHEN TUNING IS COMPLETED THE SYSTEM TURNS OFF AUTOMATICALLY.

i

i

i

WWW.TRONICAL-COMPONENTS.COM

18

TUNING SELECTION

SWITCH BETWEEN RED, GREEN AND BLUE BANKS

START TO TUNE

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

BAT

e B G D

MENU

PRESS ”ON”. The MULTISTRING MODE activates with the last completed
tuning.

Now PRESS ”BACK” on the tuner controller for TUNING SELECTION.
The MENU LED will switch OFF.

PRESS ”UP/DOWN“ to navigate between the RED (Standard),

GREEN (Major) and BLUE (User) Banks. Each bank holds 6 tunings.

PRESS ”LEFT/RIGHT“ to select any Tuning (E-e)

SINGLECLICK ON ”ENTER“ to activate selected tuning in MULTISTRING

MODE or PRESS AND HOLD “ENTER“ for SINGLESTRING MODE.

The MENU LED will light up BLUE.

ON/BACK

DOWN

BANK

TUNINGS

LEFT / RIGHT

UP

E

E

A

ENTER

WWW.TRONICAL-COMPONENTS.COM

19

TUNING SELECTION

EXAMPLE: “OPEN G“ MAJOR CHORD

START TO TUNE

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

PUSH “ON“ button, the system will come up with the last complete
tuning.
PUSH “BACK“ to enter TUNING SELECTION MODE. The MENU LED
switches OFF.

BAT

e B G

MENU

PUSH ”UP“ or ”DOWN“ to navigate to the GREEN (Major) Bank.

THE RESPECTIVE COLOR IS INDICATED
BY THE COLOR OF THE STRING LEDS

PUSH “LEFT/RIGHT“ until GLED is shining GREEN.

SINGLECLICK ”ENTER” for MULTISTRING MODE or
PUSH & HOLD ”ENTER” for SINGLESTRING MODE

Once the tuning is activated the RoboHeads start immediately in order to
change the pitch. Keep your hands away from RoboHeads and strings during
this automatic move phase (0.5 to 2 seconds).

AFTER ALL ROBOHEADS HAVE STOPPED:

MUTE ALL STRINGS & PICK THE INDICATED OUT OF TUNE STRING RED

or STRUM ALL OUT OF TUNE STRINGS MULTI STRING MODE to start fine
tune phase.

MUTING THE IN TUNE STRINGS (GREEN) while tuning is also recommended
for improved accuracy. When all strings are in tune the system switches off
automatically.

DOWN

BANK

TUNINGS

LEFT / RIGHT

UP

E

E

A

D

G

ENTER

OPEN G

ON/BACK

i

WWW.TRONICAL-COMPONENTS.COM

20

TUNING SELECTION

BANK OVERVIEW

START TO TUNE

BAT

e B G D A

MENU

BAT

e B G D A

MENU

THE RED BANK

“STANDARD“ E2 A2 D3 G3 B3 E4
“DADGAD“ D2 A2 D3 G3 A3 D4
“WHOLE STEP“ D2 G2 C3 F3 A3 D4
“DROPD“ D2 A2 D3 G3 B3 E4
“EFLAT“ Eb2 Ab2 Db3 Gb3 Bb3 Eb4
“DOUBLE DROPD“ D2 A2 D3 G3 B3 D4

BAT

e B G D A

MENU

THE GREEN BANK

“OPEN E“ E2 B2 E3 G#3 B3 E4
“OPEN A“ E2 A2 E3 A3 C#4 E4
“OPEN D“ D2 A2 D3 F#3 A3 D4
“OPEN G“ D2 G2 D3 G3 B3 D4
“DOBRO“ G2 B2 D3 G3 B3 D4
“ALL 4TH“ E2 A2 D3 G3 C4 F4

THE BLUE BANK

“USERDEFINED 01“ E2 A2 D3 G3 B3 E4
“USERDEFINED 02“ E2 A2 D3 G3 B3 E4
“USERDEFINED 03“ E2 A2 D3 G3 B3 E4
“USERDEFINED 04“ E2 A2 D3 G3 B3 E4
“USERDEFINED 05“ E2 A2 D3 G3 B3 E4
“USERDEFINED 06“ E2 A2 D3 G3 B3 E4

RED BANK TUNINGS

GREEN BANK TUNINGS

BLUE BANK TUNINGS

E

E

E

E

E6

th

E6

th

E6

th

A5

th

A5

th

A5

th

D4

th

D4

th

D4

th

G3

rd

G3

rd

G3

rd

B2

nd

B2

nd

B2

nd

e1

st

e1

st

e1

st

E

E

A

A

A

D

D

D

G

G

G

B

B

B

e

e

e

THE DEFAULT FOR ANY TUNING IN THE BLUE BANK IS STANDARD TUNING.
TO SAVE USERDEFINED TUNINGS, SEE “FUNCTION MENU  CUSTOM TUNING“

i

WWW.TRONICAL-COMPONENTS.COM

21

STRING UP AND DOWN MODE / CUSTOM TUNING /
REFERENCE TUNING / FIRMWARE VERSION / BATTERY LEVEL

FUNCTION OVERVIEW

FUNCTION MENU

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

BAT

e B G D A

MENU

PUSH “ON“ button. The system activates with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.

TO ENTER FUNCTION MENU:

PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.

PRESS “LEFT/RIGHT“ to navigate through the FUNCTION MENU (E, A, D, G, B).

PRESS “ENTER“ to confirm or PRESS “BACK“ for TUNING SELECTION MODE.

FUNCTION MENU OVERVIEW

STRING UP AND DOWN MODE PG. 11

CUSTOM TUNING MODE PG. 2021
REFERENCE TUNING PG. 22
FIRMWARE VERSION PG 23
BATTERY LEVEL PG. 24

ON/BACK

BACK

LEFT / RIGHT

UP

E

E

ENTER

FUNCTION MENU

E
A
D
G
B

WWW.TRONICAL-COMPONENTS.COM

22

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

TUNE YOUR GUITAR MANUALLY TO ANY TUNING THAT
YOU WISH TO SAVE ON A PRESET POSITION BLUE BANK

PICK THE STRING INDICATED BY THE RED BLINKING LED starting
with low “E “. Measurement begins indicated by quick

YELLOW FLASHING “E“LED. Upon completion the “E“LED will

light up solid GREEN.

MUTE THE “E“ STRING and PROCEED WITH THE “A“ STRING
in the same manner and so forth until all strings are measuredGREEN.

CONTINUED ON NEXT PAGE...

PUSH “ON“ BUTTON the system comes up with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE . MENU LED is OFF.

TO ENTER FUNCTION MENU:

PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.
PRESS “LEFT/RIGHT“ button to SELECT WHITE “A“LED and PRESS “ ENTER“.

ETC.

E

A

ENTER

BAT

e B G D A E

MENU

D

A E

BAT

e B G D A E

MENU

D

A E

BAT

e B G D A E

MENU

D

AGE

EXAMPLE:

CUSTOM TUNING

A

FUNCTION MENU

i

WWW.TRONICAL-COMPONENTS.COM

23

BAT

e B G D A E

MENU

BAT

e B G D A E

MENU

Upon completion of measurement the system
switches to the BLUE (User) bank automatically indicated
by the BLUE FLASHING LED.

PUSH “LEFT/RIGHT“ to select one of six preset positions (E-e)
PUSH “ENTER“ to save your tuning.

ALL STRING LEDS WILL FLASH GREEN TWO TIMES FOR
CONFIRMATION.

The system switches back to FUNCTION MENU automatically.
The MENU LED lights up WHITE.

PUSH “BACK“ for TUNING SELECTION MENU or
PUSH AND HOLD “ BACK“ to SWITCH THE SYSTEM OFF.

YOU CAN SAVE CUSTOM TUNINGS IN THE BLUE BANK ONLY.
YOU CAN SELECT YOUR CUSTOM TUNING IN THE SAME MANNER
AS ANY OTHER TUNING.

E

E

ENTER

SELECT PRESET TO SAVE

LEFT / RIGHT

BACK

BACK

CUSTOM TUNING | SAVING

A

FUNCTION MENU

!

THE ACTUAL FREQUENCY RANGE LIMITS ARE AS FOLLOWS:

E 60 
A 80 
D 115 
G 150 
B 200 
e 250 -

i

102 HERTZ
135 HERTZ
180 HERTZ
240 HERTZ
310 HERTZ
375 HERTZ

WWW.TRONICAL-COMPONENTS.COM

24

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

SEQUENCE
1 TUNE THE GUITAR TO THE DESIRED TUNING PRESET.
2 CHANGE THE PITCH OF ONE STRING REFERENCE STRING

BY MANUALLY TURNING THE KEY.

3 ENTER AND EXECUTE REFERENCE MODE

TO ENTER REFERENCE TUNING MODE

:

PUSH “ON“ button. The system activates with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter T UNING SELECTION MODE. MENU LED is OFF.

PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.
PRESS “LEFT/RIGHT“ button to SELECT WHITE “D“LED.

PRESS “ENTER“ for REFERENCE TUNING MODE. The MENU LED switches OFF

ELED FLASHES RED.

PRESS “LEFT/RIGHT“ button to SELECT THE REFERENCE STRING.

PLUCK YOUR REFERENCE STRING measurement begins indicated by

quick FLASHING YELLOW LED of respective string. Upon completion,
the respective led lights up GREEN and all others are shining RED.

STRUM ALL STRINGS MULTISTRING MODE.

The system will tune your guitar to the selected tuning preset in relation
to the measured reference pitch.

E

D

ENTER

BAT

e B G D A E

MENU

MOVE TO RETUNED STRING

THE LATEST COMPLETED REFERENCE TUNING IS AVAILABLE ON
STARTUP UNTIL YOU COMPLETE ANY OTHER TUNING.

SHOULD YOU WISH TO STORE YOUR REFERENCE TUNING REFER TO
“CUSTOM TUNING“ PAGE 2324.

REFERENCE TUNING

D

FUNCTION MENU

i

WWW.TRONICAL-COMPONENTS.COM

25

BAT

e B G D A E

MENU

PUSH “ON“ button. The system activates with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED IS OFF.

TO ENTER FUNCTION MENU:

PRESS AND HOLD “UP“ until MENU LED lights up WHITE.

PRESS “LEFT/RIGHT“ button to SELECT WHITE “G“LED and PRESS “ENTER“.

LEDS START FLASHING THREE TIMES, ONE TIME FOR EACH OF THE THREE
FIRMWARE VERSION DIGITS. THE FIRST DIGIT NUMBER IS GREEN, THE
SECOND BLUE AND THIRD RED. EACH COLOR SYMBOLIZES VALUES FROM
16 ACCORDING TO THE DIGITS.

G

BAT

MENU

EADGBe

BAT

MENU

EADGBe

BAT

MENU

EADGBe

ENTER

EXAMPLE: LEDS FLASH THREE TIMES

FLASH: 1 FLASH: 2 FLASH: 3

1 6

0

VERSION:

ZERO IS SYMBOLIZED IF ALL LEDS ARE WHITE.

FIRMWARE VERSION

G

FUNCTION MENU

LEFT / RIGHT

UP

i

WWW.TRONICAL-COMPONENTS.COM

26

BAT

e B G D A E

MENU

PUSH “ON“ button. The system activates with the last completed tuning
in MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.

PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.

PRESS “LEFT/RIGHT“ button to SELECT WHITE LEDB and PRESS “ENTER“.

B

ENTER

BAT

MENU

A FULLY CHARGED BATTERY DISPLAYS ALL LEDS AS SHOWN LEFT.

IF THE BATTERY IS LOW YELLOW, THE ROBOHEADS WILL LOSE
PERFORMANCE. IF ONLY TWO RED LEDS A & E ARE DISPLAYED,
CHARGE THE BATTERY IMMEDIATELLY.

EADGBe

HIGH

LOW

BATTERY LEVEL

B

i

FUNCTION MENU

WWW.TRONICAL-COMPONENTS.COM

27

ACCURACY LEVEL / ROBOHEAD DELAY /
RESET / ROBOHEAD SPEED / INTERFERENCE LEVEL

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

BAT

e B G D A

MENU

PUSH “ON“ button. The system comes up with the last
completed tuning in MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE.
MENU LED is OFF.

TO ENTER CONFIGURATION MENU:

PRESS AND HOLD THE “DOWN“button until MENU LED and “ E“ TURNS LIGHT

BLUE.

PRESS “LEFT/RIGHT“ BUTTON TO SELECT THE DESIRED FUNCTION BELOW.

BACK

LEFT / RIGHT

E

E

ENTER

FUNCTION MENU

OVERVIEW

CONFIGURATION MENU

ENTER

DOWN

LEFT / RIGHT

ON/BACK

CONFIGURATION MENU OVERVIEW

ACCURACY LEVEL PG. 29
ROBOHEAD DELAY PG. 30
RESET PG. 31
ROBOHEAD SPEED PG. 32
INTERFERENCE LEVEL PG. 33

A
D
G
B
e

WWW.TRONICAL-COMPONENTS.COM

28

BAT

e B G D A E

MENU

BAT

e B G

MENU

BAT

MENU

PUSH “ON“ button. The system comes up with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED IS OFF.

TO ENTER CONFIGURATION MENU:

PRESS AND HOLD “DOWN“ button until MENU and “E“ LED TURN LIGHT BLUE.

To access ACCURACY MODE SELECT “A“LED and PRESS ”ENTER”.

ACCURACY :

e B G D A E

+/



1.0 1.5 2.0 2.5 3.0 3.5

CENT

+/



+/



+/



+/+/



PRESS “LEFT/RIGHT“ for desired accuracy level

PUSH“ENTER“ to confrim

THE HIGHEST ACCURACY LEVEL ALL LEDS ON AS SHOWN LEFT WILL

INCREASE TUNING TIME.

A LOWER ACCURACY LEVEL WILL DECREASE TUNING TIME RESPECTIVELY.

E

E

A

A

D

DGBe

A

LEFT / RIGHT

ENTER

ACCURACY LEVEL

BACK

TUNING ACCURACY

TUNING SPEED

EXAMPLE: HIGHEST ACCURACY LEVEL

ACCURACY MODE

A

CONFIGURATION MENU

ENTER

DOWN

LEFT / RIGHT

ON/BACK

THE DEFAULT IS +/ 2.5 CENT 3 LEDS EAD.

i

WWW.TRONICAL-COMPONENTS.COM

29

BAT

e B G D A E

MENU

BAT

e B G

MENU

BAT

MENU

PRESS “LEFT/RIGHT“ to select desired delay level.
PRESS“ENTER“ to confirm.

All String LEDS FLASH GREEN TWICE to confirm SELECTED DELAY LEVEL has
been stored.

PUSH ”BACK” for CONFIGURATION MENU.

THE MAX DELAY LEVEL AS SHOWN LEFT WILL DELAY THE START OF
THE ROBOHEADS BY 2.5 SEC.

EACH ADDITIONAL LED DECREASES THE DELAY BY 0.5 SEC.

E

E

A

ADDGBBe

D

LEFT / RIGHT

ENTER

ROBOHEAD SPEED

BACK

LOW DELAY

NO DELAY

HIGH DELAY

(2,5 SEC)

EXAMPLE: MAX DELAY

ROBOHEAD DELAY

SET THE STARTDELAY OF THE ROBOHEADS.

D

CONFIGURATION MENU

PUSH “ON“ button. The system comes up with the last completed tuning in
MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.

TO ENTER CONFIGURATION MENU
PRESS AND HOLD “DOWN“ button until MENU and “LEDE“ LED TURN

LIGHT BLUE.

TO ACCESS ROBOHEAD DELAY SELECT “D“LED and PRESS ”ENTER”.

WHEN YOU CHANGE A TUNING THE ROBOHEADS WILL START
IMMEDIATELY IN ORDER TO CHANGE THE PITCH. WITH THIS
FUNCTION YOU CAN DELAY THE START UP TO 2.5 SECONDS.

ENTER

DOWN

LEFT / RIGHT

ON/BACK

THE DEFAULT IS NO DELAY ALL LEDS ON.

i

i

WWW.TRONICAL-COMPONENTS.COM

30

BAT

e B G D A E

MENU

G

BAT

e B G

MENU

SELECT “E“LED for reset of all CUSTOM TUNINGS.

SELECT “A“LED for FACTORY RESET (all data).

To confirm PRESS AND HOLD “UP“ and PRESS AND HOLD “ENTER“
at the same time by PUSHING IN BETWEEN BOTH BUTTONS.

E

A

D

LEFT / RIGHT

ENTER

UP

RESET STYLES

BACK

ENTER

DOWN

LEFT / RIGHT

ON/BACK

RESET

G

CONFIGURATION MENU

PUSH “ON“ button. The system comes up with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.

TO ENTER CONFIGURATION MENU
PRESS AND HOLD “DOWN“ button until MENU and “E“ LED TURNS LIGHT

BLUE.

TO ACCESS RESET SELECT “G“LED and PRESS ”ENTER”.

RESET STYLES OVERVIEW

RESET ALL CUSTOM TUNINGS

FACTORY RESET RESET ALL DATA EXCEPT CUSTOMER TUNING DATA

E
A

WWW.TRONICAL-COMPONENTS.COM

31

BAT

e B G D A E

MENU

BAT

e B G

MENU

BAT

MENU

SELECT ROBOHEAD SPEED BY PUSHING “LEFT/RIGHT“.
PRESS “ENTER“ to confirm.

E

E

A

A

D

DGB

B

e

B

LEFT / RIGHT

ENTER

ROBOHEAD SPEED

BACK

FAST

SLOW

EXAMPLE: HIGHEST SPEED LEVEL

ROBOHEAD SPEED

B

CONFIGURATION MENU

PUSH “ON“ button. The system comes up with the last completed tuning in

MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.

TO ENTER CONFIGURATION MENU
PRESS AND HOLD “DOWN“ button until MENU and “E“ LED TURNS LIGHT

BLUE.

TO ACCESS ROBOHEAD SPEED SELECT “B“LED and PRESS ”ENTER”.

ENTER

DOWN

LEFT / RIGHT

ON/BACK

SETS THE SPEED OF THE ROBOHEADS FOR ALL TUNING MODES.

LESS ROBOHEAD SPEED CAN DECREASE STRESS TO THE STRINGS
AND TO THE GUITAR NECK.

IN CASE OF FREQUENT STRING SNAPPING OR NO STABLE TUNING
RESULTS AFTER LONG DISTANCE TUNINGS DUE TO NECK RELIEF, TRY
A LOWER SPEED LEVEL.

THE DEFAULT IS SET TO THE HIGHEST SPEED
LEVEL AS SHOWN LEFT ALL LEDS ON.

i

i

i

USE THIS FUNCTION TO SET THE SPEED AND ACCELERATION OF
THE ROBOHEADS. IF THE NECK OF YOUR GUITAR NEEDS MORE TIME
TO STABILIZE WHEN CHANGING TUNINGS, REDUCE THE SPEED.

WWW.TRONICAL-COMPONENTS.COM

32

BAT

e B G D A E

MENU

BAT

e B G

MENU

BAT

MENU

SETS THE GLOBAL INTERFERENCE LEVEL FOR ALL TUNING MODES.

DEFAULT IS 3LEDS

PUSH “LEFT/RIGHT“ to select between a high and low interference level to
prevent that the harmonic of a low string is recognized as a harmonic of a high
string.

E

E

A

A

D

DGBe

e

LEFT / RIGHT

ENTER

INTERFERENCE LEVEL

BACK

HIGH

LOW

EXAMPLE: HIGHEST INTERFERENCE LEVEL.

INTERFERENCE LEVEL

e

CONFIGURATION MENU

PUSH “ON“ button. The system comes up with the last completed

tuning in MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED IS OFF.

To enter CONFIGURATION MENU

PRESS AND HOLD “DOWN“ BUTTON until MENU and “E“ LED TURNS LIGHT

BLUE.

TO ACCESS INTERFERENCE LEVEL SELECT “e“LED and PRESS ”ENTER”.

ENTER

DOWN

LEFT / RIGHT

ON/BACK

i

i

A GUITAR STRING IS PRODUCING NOT ONLY THE FUNDAMENTAL
FREQUENCY BUT ALSO SEVERAL OVERTONES E.G. THE E STRING IS
PRODUCING 82.41 HERTZ AS FUNDAMENTAL AND OVERTONES AT

164.82, 247.23 AND SO FORTH.

THAT MEANS THAT THE ESTRING IS INTERFERING WITH THE BSTRING
BECAUSE THE SECOND OVERTONE OF THE ESTRING AND THE FUNDA
MENTAL OF THE BSTRING INTERFERE AROUND 247 HERTZ.

WHEN YOU RECOGNIZE THAT THE ROBOHEAD OF THE B STRING IS
TURNING WITHOUT PLUCKING THE BSTRING REDUCE THE INTERFE
RENCE LEVEL. IF YOUR GUITAR IS NOT PRODUCING PRONOUNCED
OVERTONES YOU CAN INCREASE THE INTERFERENCE LEVEL TO
IMPROVE PERFORMANCE.

WWW.TRONICAL-COMPONENTS.COM

33

OVERVIEW

SYSTEM CONFIGURATION

GAIN / GUITAR TYPE / PITCH WINDOW / DOUBLE CLICK

BAT

e B G D A E

MENU

BAT

e B G D A

MENU

BAT

e B G D A

MENU

BACK

LEFT / RIGHT

E

E

E

ENTER

SYSTEM CONFIGURATION

SYSTEM CONFIGURATION

PUSH “ON“ button. The system comes up with the last completed tuning in

MULTISTRING MODE.

PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED IS OFF.

TO ENTER SYSTEM CONFIGURATION
PRESS AND HOLD “RIGHT“ and PRESS AND HOLD “ENTER“ at the same time

by PRESSING IN BETWEEN BOTH BUTTONS.

“MENU“LED and “E“LED LIGHT UP YELLOW.

PRESS “LEFT/RIGHT“ to navigate through the menu E, A, D.
PRESS “ENTER“ to confrim or PRESS “BACK“ for TUNING SELECTION MODE.

THE SYSTEM CONFIGURATION MENU IS USED TO CONFIGURE
SYSTEM RELEVANT PARAMETERS LIKE GUITARTYPE, GAIN AND
FREQUENCY SNAP. THE CLICKSTREAM TO ENTER THIS MENU IS
MORE COMPLICATED TO PREVENT UNINTENDED CHANGES. THESE
SETTINGS ARE AFFECTING SYSTEM PERFORMANCE AND ACCURACY.
PLEASE STEP GENTLY.

ENTER

DOWN

LEFT / RIGHT

ON/BACK

SYSTEM CONFIGURATION OVERVIEW

GAIN PG. 32

GUITAR TYPE PG. 33
PITCH WINDOW PG.34
SINGLE OR DOUBLE CLICK FOR TUNE PG. 35

E
A
D
G

i

WWW.TRONICAL-COMPONENTS.COM

34

BAT

e B G D A E

MENU

BAT

MENU

BAT

MENU

SELECT THE PIEZO SIGNAL LEVEL BY PUSHING “LEFT/ RIGHT“.

PUSH “ENTER“ to confirm.
PUSH ”BACK” for SYSTEM CONFIGURATION MENU.

E

GAIN SETTINGS

SYSTEM CONFIGURATION

E

EADG

B

e

EADGBe

HIGH SIGNAL

LOW SIGNAL

LEFT / RIGHT

ENTER

BACK

PUSH “ON“ button. The system comes up with the last completed tuning in
MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED IS OFF.

TO ENTER SYSTEM CONFIGURATION

PRESS AND HOLD “RIGHT“ and PRESS AND HOLD “ENTER“ at the same
time by PRESSING IN BETWEEN BOTH BUTTONS.

“MENU“LED AND “E“LED LIGHT UP YELLOW.

ENTER

DOWN

LEFT / RIGHT

ON/BACK

i

i

THE DEFAULT IS 3 LEDS AND WILL BE ADAPTED WHEN EXECUTING
CALIBRATION MODE. SELECTING A DIFFERENT LEVEL WILL AFFECT
SYSTEM PERFORMANCE OR CAN CAUSE MALFUNCTION.

TRONICAL TUNE HAS A SUPERIOR DYNAMIC RANGE TO SENSE THE
SOLIDBORNE SOUND OF YOUR INSTRUMENT >130DB. THIS IS
ACHIEVED BY A PIEZO TRANSDUCER, A DYNAMICAL ADJUSTABLE
AMPLIFIER AND A 24 ANALOG TO DIGITAL CONVERTER ADC. WITH
THE “GAIN SET TING” THE STARTING POINT OF THE AMPLIFIER IS SET.
FROM THIS STARTING POINT THE AMPLIFIER IS ADJUSTED DURING
THE TUNING PROCESS IN THE RANGE OF +9DB.

WHEN YOU PERFORM A “CALIBRATION” A GOOD STARTING POINT
FOR THE AMPLIFIER IS SET. YOU CAN OVERRIDE THE GAIN SETTING
WITH THIS FUNCTION. BE CAREFUL WHEN CHANGING THE GAIN!

INCREASE THE GAIN IF STRINGS ARE NOT RECOGNIZED WHEN PLU
CKED STRING LED IS NOT GETTING YELLOW, STRING IS NOT TUNED
OR SIGNAL IS FADING OUT TOO QUICK.
DECREASE THE GAIN IF THE GUITAR IS TOO SENSITIVE OR IF USED
IN LOUD ENVIRONMENTS WITH AMBIENT NOISE.
GAIN LEVEL : 2.5DB, 6DB, 9DB, 12DB, 15DB, 18DB

WWW.TRONICAL-COMPONENTS.COM

35

For GUITAR TYPE select “A“LED and press ”ENTER”.

The DEFAULT SETTING is LEDE for “ELECTRIC.“
Use the “LEFT/RIGHT“ button to change to the appropriate setting:

1. GREEN “E“ ELECTRIC

2. GREEN “E“ & BLUE “A“ ACOUSTIC

3. GREEN “E,“ BLUE “A,“ & RED “D“ TAYLOR GS MINI

Press “ENTER“ to CONFIRM.

GREEN “E“ & BLUE “A“ BLINKING LED‘S:

ACOUSTIC GUITAR

GREEN “E,“ BLUE “A,“ & RED “D“ BLINKING LEDS:

TAYLOR GS MINI

SYSTEM CONFIGURATION

BAT

e B G D A E

MENU

BAT

MENU

A

E

ADGBe

BAT

MENU

E

ADGBe

BAT

MENU

EA

D

GBe

LEFT / RIGHT

ENTER

BACK

GUITAR TYPES

A

GUITAR TYPE

A

Push “ ON“ button. The system comes up with the last completed tuning in
MULTISTRING MODE.

Push “ BACK“ button to enter TUNING SELECTION MODE. “MENU“ LED is OFF.

To enter SYSTEM CONFIGURATION:

PRESS and HOLD BOTH “RIGHT“ and “ ENTER“ AT THE SAME TIME.

“MENU“LED and “E“LED LIGHT UP YELLOW.

ENTER

DOWN

LEFT / RIGHT

ON/BACK

ii

i

IT IS IMPORTANT TO SETUP THE SYSTEM TO THE RIGHT GUITAR TYPE.
ACOUSTIC GUITARS ARE EQUIPPED WITH THICKER STRINGS AND
SHOW DIFFERENT ACOUSTIC CHARACTERISTICS.

WWW.TRONICAL-COMPONENTS.COM

36

SYSTEM CONFIGURATION

PITCH WINDOW

D

BAT

e B G D A E

MENU

BAT

e B G

MENU

BAT

MENU

Every time when a tuning is completed the system stores the actual
pitch for each string. On re-tune the system checks if the actual string
frequencies are within a certain PITCH WINDOW. If a string is outside its
Pitch Window the corresponding LED turns purple. If at least one string
is out of its Pitch Window the system turns automatically to SINGLE
TUNE MODE after the remaining strings are tuned.

The Pitch Window can be adjusted from 25 to 150 Cent.

PITCH WINDOW

e B G D A E

25 35 50 75 100 150

PRESS “LEFT/RIGHT“ for desired PITCH WINDOW.
PRESS “ENTER“ to confirm.

EXAMPLE:

THE PITCH WINDOW IS SET TO 100CENT=5LEDS. THE LAST
COMPLETED TUNING WAS A STANDARD EADGBE. NOW THE
SYSTEM IS STARTED AGAIN. IF THE PITCH OF THE LOW E STRING IS
MORE THAN 100CENT OFF, THE CORRESPONDING ELED WOULD
BECOME MAGENTA LOWER THAN EB OR HIGHER THAN F.

E

E

A

A

DG

DGB

e

D

LEFT / RIGHT

ENTER

PITCH WINDOW

BACK

HIGH

LOW

EXAMPLE:

ENTER

DOWN

LEFT / RIGHT

ON/BACK

DEFAULT IS 75 CENT = 4 LEDS.

i

CENT

WWW.TRONICAL-COMPONENTS.COM

37

SYSTEM CONFIGURATION

SINGLE OR DOUBLE CLICK FOR TUNE

G

BAT

e B G D A E

MENU

G

ENTER

DOWN

LEFT / RIGHT

ON/BACK

Push the “ON“ button. The system comes up with the last completed tuning in

MULTISTRING MODE.

Push the “ BACK“ button to enter TUNING SELECTION MODE. The “MENU“ LED
is off.

To enter SYSTEM CONFIGURATION
PRESS and HOLD both “RIGHT“ and “ENTER“ AT THE SAME TIME.

The “MENU“LED and “E“LED light up YELLOW.

For SINGLE OR DOUBLE CLICK TUNING, SELECT “G“LED and PRESS ”ENTER”

Select either LEDE for “SINGLE CLICK“ or LED “A“ for “DOUBLE CLICK.“
PRESS “ENTER“ to CONFIRM.

i

SELECT BETWEEN SINGLE CLICK OR DOUBLE CLICK TO ACTIVATE
TUNING.

SINGLE CLICK: PRESS ONCE TO CONFIRM SELECTED TUNING

DOUBLE CLICK: PRESS TWICE TO CONFIRM SELECTED TUNING

MORE TIME TO REMOVE HAND OUT OF THE SYSTEM / ROBOHEADS

BAT

MENU

E

ADGBe

LEFT / RIGHT

ENTER

BACK

CLICK OPTIONS

GREEN BLINKING “E“ LED :

SINGLE CLICK DEFAULT

GREEN “E“ & BLUE “A“ BLINKING LEDS:

DOUBLE CLICK

BAT

MENU

E

ADGBe

BAT

MENU

EA

DGB

e

A

ii

WWW.TRONICAL-COMPONENTS.COM

38

BATTERY PACK

3.7V 340mA h 1258mWh LIPOLYMER

A BATTERY THAT HAS BEEN INFREQUENTLY
USED, OR A NEW ONE, COULD HAVE REDUCED
CAPACITY. YOU MAY NEED TO RECHARGE IT A
NUMBER OF TIMES. WHEN THE BATTERY LEVEL IS
LOW, THE BAT LED FLASHES RED.

CAUTION:

1. DO NOT CONNECT IMPROPERLY.

2. DO NOT DISPOSE OF IN FIRE OR
EXPOSE TO EXCESS HEAT.

3. DO NOT CRUSH, PUNCTURE, INCINERATE
OR SHORT CIRCUIT EXTERNAL CONTACTS.

LIPOLYMER CHARGER

INPUT: AC100240V 50/60HZ
OUTPUT: 4.2V  300mA

...



+

CHARGING:

CHARGE THE BAT TERY LATEST WHEN LED

BAT IS SHINING RED.

CHARGING THE BATTERY

TRONICAL TUNE

BATTERY IS CHARGING BATTERY IS CHARGED

!

WWW.TRONICAL-COMPONENTS.COM

39

LEGAL INFORMATION

Guidelines for safe and efficient use.

Read this information before using Tronical Tune.

PRODUCT CARE:

Do not expose your product to liquid or moisture or to humidity.

Do not expose your product to extreme high or low temperatures.

Do not expose your product to lit candles, cigarettes, or cigars, or to open ames etc.

Do not drop, throw or try to bend the product as rough treatment could damage it.

Do not attempt to disassemble your product. The product does not contain

consumer serviceable or replaceable components. Only Tronical GmbH should perform
service.

If you will not be using the product for a while, store it in a place that is dry, free
from damp, dust and extreme temperatures.

DISPOSAL OF OLD ELECTRICAL & ELECTRONIC EQUIPMENT:

This symbol on the product indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point
for the recycling of electrical and electronic equipment. By ensuring this product is dis
posed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will help to conserve natural resources. For
more detailed information about recycling of this product, please contact your local city oce,
your household waste disposal service or the shop where you purchased the product.

POWER SUPPLY

Connect the AC power adapter only to designated power sources as marked on the product.
To reduce risk of damage to electric cord, remove it from the outlet by holding onto the AC
adapter rather than the cord. Make sure the cord is positioned so that it will not be stepped on,
tripped over or otherwise subjected to damage or stress. To reduce risk of electric shock, unplug
the unit from any power source before attempting to clean it. »

The AC power adapter must not be used outdoors or in damp areas. DANGER - Never alter the AC
cord or plug. If the plug will not t into the outlet, have a proper outlet installed by a qualied
electrician. Improper connection can result in risk of electric shock.

CHILDREN:

Do not allow children to play with Tronical Tune since it contains small parts that could become

detached and create a choking hazard.

BATTERY INFORMATION:

A rechargeable battery has long service life if treated properly. A new battery or one that has not
been used for a long period of time could have reduced capacity the rst few times it is used. Do
not expose the battery to extreme temperatures, never above +55° C (+131° F). For maximum bat­tery capacity , use the battery in room temperature. If the battery is used in low temperatures, the
battery capacity will be reduced. The battery can only be charged in temperatures between +10°C
(+50° F) and +45° C (+113° F).

RECYCLING THE BATTERY:

The battery in your Tronical Tune must be disposed of properly and should never be placed in
municipal waste.

CAUTION:

1. DO NOT CONNECT IMPROPERLY.

2. DO NOT DISPOSE OF IN FIRE OR EXPOSE TO EXCESS HEAT.

3. DO NOT CRUSH, PUNCTURE, INCINERATE OR SHORT CIRCUIT EXTERNAL CONTACTS.

!

!

WWW.TRONICAL-COMPONENTS.COM

40

Tronical Components GmbH • Heselstücken 18 •

D-22453 Hamburg Germany

Web: www.tronical.com • Mail: [e-mail]

HRB 94503

© Copyright 2012 Tronical-Components GmbH. All rights reserved.
