Tritton Technologies TRI-BH200, AX Micro User Manual
Volume Down (-)
LED status indicator light
Volume Up (+)
Multi-Function Button
Pairing mode lasts for 3 minutes, after this period the AX Micro
returns to standby mode.
Introduction
Thank you for purchasing the Tritton Bluetooth Headset TRI-BH200,
the AX Micro. The AX Micro is a high-tech wireless headset for
handsfree operations at its best. The AX Micro can be connected to
any Bluetooth device that supports either headset or handsfree
Bluetooth profiles. The AX Micro features a revolutionary finger-like
rubber gripping mechanism that holds the headset firmly against
the auricle (Outer flap of the ear, also called the pinna), making it
convenient to wear and comfortable even when used for extended
hours. Additionally, the symmetrical design is one that can be
easily switched from one ear to the other
Safety Instructions
Know the law: Make sure to check to local laws and regulations
on the use of mobile phones and handsfree equipment in the
areas you intend to use them.
Extended use of headset devices at high volume levels may
cause hearing damage.
When cleaning the device, do not use any type of scouring pad,
abrasive powder or solvents as these may permanently dull the
finish.
Charge the battery for at least 2 hours before first use.
Do not use in prohibited areas such as hospitals or on airplanes.
Do not expose components to extreme temperatures,
prolonged sunlight, moisture or vibrations.
Keep headset and charger cradle away from reach of children.
Do not place metal objects, such as coins or jewelry, on charger
cradle contacts. This may cause a short circuit with the risk of
fire or explosion.
The warranty is valid only if the original receipt issued to the
original purchaser by the dealer is presented with the product
to be repaired or replaced.
The warranty is void if the serial number, date of purchase and
product label had been removed.
The warranty does not cover any failure or damage of the
product due to normal wear and tear, physical abuse, improper
installation, misuse, modification or repairs by unauthorized
third parties.
Tritton Technologies does not assume responsibility for any loss
or damage incurred during shipment and as a result of force of
nature.
Tritton Technologies is not liable for any incidental or
consequential damages arising from the use or misuse of the
product.
All warranty claims are limited to repair or replacement of the
defective product at the sole discretion of Tritton Technologies.
If Tritton Technologies repairs or replaces the product, the
repaired or replaced product shall be warranted for the
remaining time of the original warranty p eriod. Repair or
replacement may involve the use of functionally equivalent
reconditioned units. Replaced part or product becomes the
property of Tritton Technologies.
Consumable components, such as batteries, are not included in
the warranty obligation.
Bluetooth V1.2, 2.0 compliant
Supports headset and handsfree profiles for hands free function
with Bluetooth phones
Unique finger-like rubber grippers to secure the headset on
your ear
High performance built-in speaker and microphone
Red and blue LED status indicator light
More than 4 hours of talk time and 150 hours of standby time
Convenient charging via cradle using standard Mini-USB
(not provided) or AC/DC Adapter
CONTENTS
Introduction..........................................................................................................2
Safety Instructions..............................................................................................3
Product Features..................................................................................................4
Package Contents................................................................................................5
Description of Parts............................................................................................6
Charging the AX Micro Battery........................................................................7
Switching the TRI-BH200 ON/OFF..................................................................7
Pairing the AX Micro ..........................................................................................8
Wearing the AX Micro.........................................................................................8
Basic Handsfree Operations for the AX Micro............................................9
Product Specifications....................................................................................11
Product Warranty..............................................................................................12
1.
2.
3.
4.
5.
6.
Tritton Bluetooth Headset TRI-BH200, AX Micro
Charger Cradle
AC/DC Charger Adapter
Rubber Grippers (2 sizes)
Lanyard and clip
User Manual
Charge the battery for at least 2.5 hours prior to first use.
During charging the headset LED status indicator light will
be red.
When fully charged, the headset LED status indicator light will
be blue.
To connect charger
1. Connect the charger cradle with the AC/DC Adapter.
2. Plug cord into power supply
3. Mount headset onto cradle
Product Features
Package Contents
Select one of the two rubber grippers that fits most comfortable
and securely.
Place the headset in the ear so that the rubber grippers hold the
headset snugly against the ear wall.
Pairing the AX Micro
Wearing the AX Micro
An alert sound will output from both phone and headset.
Short click Multi-Function Button to answer call.
Dial and place a call from phone and automatically be transferred
to headset.
Short click Multi-Function Button to switch the call to the headset.
Double click Multi-Function Button when in idle state
Make sure your phone supports voice dialing, that it is activated
and the voice tags have been recorded if needed.
Long-click Multi-Function Button when in idle state.
Follow the instruction message from phone to complete
voice dialing.
Double click Multi-Function Button once.
Short click (+) or (-) to adjust volume during handsfree mode.
Basic Handsfree Operations for the AX Micro
Answer Call
Make Call
Redial
Voice Dial
Volume Control
Long click Multi-Function Button while phone is ringing.
Short click Multi-Function Button during ‘Talk Mode’ to transfer
call from headset to phone or vise versa.
Long click Multi-Function Button during ‘Talk Mode’ to answer
an incoming call.
Short click Multi-Function Button twice to switch between calls.
Short click Multi-Function Button twice to reconnect headset
with phone
Long click the (+) and (-) buttons simultaneously during ‘Talk
Mode’ if you do not want to mute your voice for privacy .
Long click the (+) and (-) buttons simultaneously to cancel
mute function.
Long click Multi-Function Button during ‘Talk Mode’.
NOTE: If the other party ends the call first, the AX Micro will
automatically return to standby mode.
End Call
Reject Call
Call Transfer
Call Waiting
Microphone Mute
Reconnect
Product Specifications Product Warranty
Tritton Technologies warrants this product against all defects in
material and workmanship for a period of one year from the date of
purchase by end user. The conditions for warranty are as follows :
Disclaimer Notice
The manufacturer shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the fur nishing,
performance or use of this material. This document contains proprietary
information, which is protected by international patent applications and
copyright. All rights reserved. No par t of this document may be copied,
reproduced or translated without prior written consent of the manufacturer.
The manufacturer reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation to
notify any person of such revisions or changes. The manufacturer also
reserves the right to change the specifications without notice.
European CE notice to users and product statements
This product is C E marked according to the provisions of the R & TTE
Directive (99/5/EC). Hereby, Tritton Technologies Co., Ltd, declares that this
product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. For fur ther information, please contact
http://www.trittonusa.com
FCC notice to users and product statements
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is
subject to the following two conditions; (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the par ty
responsible for compliance could void the user’s authority to operate the
equipment.
WEEE Directive 2002/96/EC Art. 11(2)
The use of the symbol indicates that this product may not be
treated as household waste. By ensuring this product is disposed
of correctly, you will help prevent potential negative
consequences for the environment and human health, which
could other wise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this
product, please contact your local city office, your household
waste disposal service or the shop where you purchased the
product.
Standards
RF Frequency Range
Profiles Supported
Transmission Power
Distance
Battery Type
Battery Life
Charging Time
Weight
Operating Temp.
& Humidity
Certification
Bluetooth Specification V2.0
2402 ~ 2480 MHz
Headset, Handsfree V1.5
0.25 ~ 2.5mW (Class 2)
10m (in open space)
Li-Ion Polymer
Standby > 150 hrs,
Voice Connection : 4 hrs
< 3 hrs
9.5g
-10 ~ +50°C,
Rel. Humidity 0 ~ 95%
BQB, FCC, CE
1 2 3 4 5 6 7
8 9 10 11 12 13
Description of Parts
If the AX Micro is on, turn it OFF
Click and hold the Multi-function Button until LED status
indicator light starts flashing red and blue (appx 7 seconds).
If prompted for a pin number to establish a connection on the
paired Bluetooth device, enter 0000.
When connected, the AX Micro LED status indicator light will
turn off.
To Turn ON: Click and hold the Multi-Function Button until the
LED status indicator light turns blue and periodically flashes.
To Turn OFF: Click and hold the Multi-Function Button until the
LED status indicator light turns red and then off.
The AX Micro can be worn on the left or right ear. When the
headset is not in use, you can clip the headset onto the lanyard for
convenience and portability.
NOTE: Double click on some phones will display the number last
called or received. In this case, double click Multi-Function Button
again to redial.
NOTE: Beep tones will be heard at maximum or minimum volume.
NOTE: This function can only be used if user has subscribed for
such services.
TRI-BH200
Rev 1.0
! Improper battery charging can shorten usage times !
Many of the buttons perform multiple tasks, based upon if they are tapped, or held down.
We call this “Short Click” and “Long Click” respectively throughout the manual.
technologies
1
4
5
2 3
6
NOTE: Some phones will automatically transfer call.
Online Support: www.TRITTONUSA.com
Phone Support: 800-431-1176
