TRITTON R.A.T. M User Manual [en, de, es, fr, it]

:: WIRELESS MOBILE GAMING
:: KABELLOSE MOBILE GAMING-MAUS
:: SOURIS DE JEU MOBILE SANS FIL
multiplatform :: multi-plateforme
PC
®
MAC
FOR POUR FÜR *
®
via Bluetooth Smart technology
* Toutes les entrées de la souris au-dessus de dispositif de support Bluetooth 4.0
AA
5 21
PACKAGE INCLUDES
ENGLISH
M
Wireless Mouse
A
R.A.T. Dongle
B
Pouch
C
2 x AAA Battery
D
FRANÇAIS
M
Souris Sans Fil
A
R.A.T. Dongle
B
Housse
C
2 piles AAA
D
DEUTSCH
M
Funkmaus
A
R.A.T. Dongle
B
Hülle
C
2 Mikrobatterien
D
ITALIANO
M
Mouse wireless
A
R.A.T. Adattatore
B
Borsa
C
2 batterie ministilo
D
ESPAÑOL
R.A.T.
A
Llave electrónica
B
Bolsa
C
2 x batería AAA
D
SWEDISH DANISH PORTUGUÊS
R.A.T.
A
Dongle
B
Fodral
C
2 x AAA-batterier
D
M
Ratón inalámbrico
M
Trådlös mus
.A
.C
M
A
R.A.T. Dongle
B
Lomme
C
2 x AAA-batterier
D
Trådløs mus
.2
R.A.T.
A
Dongle
B
Bolsa
C
2x pilhas AAA
D
.D
.B
M
Rato Sem Fios
CONTENTS
ENGLISH
Mouse Overview Mouse Status LEDs Setup Instructions
DEUTSCH
Mausübersicht LED-Anzeigen Installationsanleitung
FRANÇAIS
Présentation de la souris Témoins lumineux (DEL) Instructions d’installation
ITALIANO
Panoramica del mouse Spie LED di indicazione Istruzioni di configurazione
ESPAÑOL
Descrição geral do rato Indicadores LED Instruções de configuração
SWEDISH
Musöversikt LED-indikatorer Istallationsanvisningar
DANISH
Oversigt over mus Lysdioder Opsætningsvejledning
PORTUGUÊS
Descrição geral do rato Indicadores LED Instruções de configuração
4 6 7
9 11 12
14 16 17
19 21 22
24 26 27
29 31 32
34 36 37
39 41 42
.3
MOUSE OVERVIEW
MIDDLE MOUSE BUTTON VERTICAL SCROLL
WING BUTTON
DPI CYCLE
INTERNET FORWARD
BLUETOOTH INDICATOR
5D™ BUTTON
DPI INDICATOR
INTERNET BACKWARD
BATTERY RELEASE BUTTON
ADJUSTABLE PALM REST
.4
5 21
LASER
ON/ OFF
DONGLE STORAGE
BATTERY COMPARTMENT
.5
MOUSE STATUS LEDS
5 2
21
LED indication will remain active for one minute upon any change of status, after which it will extinguish in order to conserve battery.
LED COLOR INDICATORS
Red LED - DPI indicator Blue LED - Bluetooth indicator
PAIRING MODE
PAIRED AND OPERATING
BATTERY LOW
DPI LED
Blue LED flashes once every second
Blue LED pulses every 5 seconds
(5%) - Blue LED pulses every 2 seconds
Red LED Low Brightness = DPI Setting 1 Red LED Full Brightness = DPI Setting 2
.6
1
5
2
SETUP INSTRUCTIONS
CONNECTING THE MOUSE USING THE DONGLE
1. Insert 2 x AAA batteries into the mouse
2. Plug the USB dongle into an available port
3. Turn the mouse ON
®
CONNECTING TO DEVICES WITH BUILT-IN BLUETOOTH
SMART
TECHNOLOGY (DONGLE NOT REQUIRED)
BLUETOOTH SMART TECHNOLOGY
Bluetooth Smart is a new, power-efficient version of Bluetooth wireless technology and is already being used in many devices. Check with your manufacturer to see if it is Bluetooth Smart ready. Check with your device manufacturer for support for Bluetooth Smart mice and then follow their instructions for pairing.
®
WINDOWS
8
1. Ensure the USB dongle is unplugged and power the R.A.T.
2. Press and hold the 5D™ and Wing buttons for 5 seconds until the Blue LED starts flashing
3. Move mouse to bottom right corner of the screen to open the Charms bar
4. Click Settings
5. Click Change PC Settings
6. Click Devices
7. Click Add a device
8. Select R.A.T.
M
.7
M
on
SETUP INSTRUCTIONS
SOFTWARE INSTALLATION
SOFTWARE FOR WINDOWS AND MAC
1. Go to www.madcatz.com/downloads to download and install the Mad Catz software application
2. Use the drag-and-drop interface to customize your mouse
3. Go to the Support section of the software for full programming instructions
TROUBLESHOOTING
•
If your R.A.T. M does not appear to be working with your device then, with it powered on, press and hold the Wing and 5D™ buttons for 5 seconds until the Blue LED starts flashing. If you wish to connect to the USB dongle then ensure that it is connected to your computer. If you wish to connect to another device then follow the Bluetooth pairing procedure for that device to rediscover the R.A.T .
• Information for Customers in the United States
• FCC & IC Warning
• This device complies with part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard (s).
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
• Any Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
•
• FCC Radiation Exposure Statement:
• This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
• This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
•
• IC RF Exposure Statement:
• The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance
with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
•
• Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio inter­ference to other users, the antenna type and its gain should be so chosen that, the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
.8
M
MAUSÜBERSICHT
MITTLERE MAUSTASTE VERTIKALER BILDLAUF
FLÜGELTASTE
DPI-ZYKLUS
INTERNET WEITER
BLUETOOTH-ANZEIGE
5D™-TASTE
DPI-ANZEIGE
INTERNET ZURÜCK
BATTERIEFREIGABETASTE
ANPASSBARE HANDBALLENAUFLAGE
.9
MAUSÜBERSICHT
5 21
LASER
EIN/AUS
DONGLE-FACH
BATTERIEFACH
.10
LED-ANZEIGEN
5 2
21
Die LED-Anzeige bleibt bei jeder Statusänderung eine Minute lang eingeschaltet. Anschließend erlischt sie, um Energie zu sparen.
LED-FARBANZEIGEN
“ Rote LED – DPI-Anzeige Blaue LED – Bluetooth-Anzeige
KOPPLUNGSMODUS
GEKOPPELT UND IN BETRIEB
GERINGER BATTERIESTAND
DPI-LED
Blaue LED blinkt einmal pro Sekunde
Blaue LED blinkt alle 5 Sekunden
(5 %) - Blaue LED blinkt alle 2 Sekunden
Rote LED geringe Helligkeit = DPI-Einstellung 1 Volle Helligkeit = DPI-Einstellung 2
.11
1
5
2
INSTALLATIONSANLEITUNG
VERBINDUNG DER MAUS MIT DEM DONGLE
1. Legen Sie zwei Mikrobatterien in die Maus ein
2. Schließen Sie den USB-Dongle an einen freien Anschluss an
3. Schalten Sie die Maus ein
®
VERBINDUNG MIT GERÄTEN MIT INTEGRIERTER BLUETOOTH SMART-TECHNOLOGIE (KEIN DONGLE ERFORDERLICH)
BLUETOOTH SMART-TECHNOLOGIE
Bluetooth Smart ist eine neue energiesparende Version der Bluetooth-Funktechnologie, die bereits in vielen Geräten genutzt wird. Prüfen Sie, ob Ihr Gerätehersteller Bluetooth Smart unterstützt. Überprüfen Sie beim Hersteller Ihres Geräts Unterstützung für Bluetooth Smart-Mäusen und dann folgen Sie den Anweisungen für das Pairing.
®
WINDOWS
8
1. Stellen Sie sicher, dass der USB-Dongle getrennt ist, und schalten Sie R.A.T.
2. Halten Sie die Flügeltaste- und 5D™-Tasten 5 Sekunden lang gedrückt, bis die blaue LED blinkt
3. Bewegen Sie die Maus in die untere rechte Ecke des Bildschirms, um die Charms- Leiste zu öffnen
4. Klicken Sie auf „Einstellungen“
5. Klicken Sie auf „PC-Einstellungen ändern“
6. Klicken Sie auf „Geräte“
7. Klicken Sie auf „Gerät hinzufügen“
8. Wählen Sie R.A.T. M aus
M
.12
ein
INSTALLATIONSANLEITUNG
SOFTWAREDOWNLOAD
SOFTWARE FÜR WINDOWS UND MAC
1. Besuchen Sie www.madcatz.com/downloads, um die Mad Catz-Softwareanwendung herunterzuladen und zu installieren
2. Passen Sie Ihre Maus über die Drag-and-Drop-Oberfläche an
3. Eine vollständige Programmieranleitungen finden Sie im Supportbereich der Software
PROBLEMBEHANDLUNG
•
Wenn R.A.T. M mit Ihrem Gerät anscheinend nicht funktioniert, während es einge­schaltet ist, halten Sie die Flügeltaste- und 5D™ Tasten 5 Sekunden lang gedrückt, bis die blaue LED blinkt. Wenn Sie eine Verbindung mit dem USB-Dongle herstellen möchten, stellen Sie sicher, dass er an den Computer angeschlossen ist. Wenn Sie eine Verbindung mit einem anderen Gerät herstellen möchten, führen Sie das Bluetooth-Kopplungsverfahren für das jeweilige Gerät aus, damit R.A.T. gesucht wird.
.13
M
erneut
PRÉSENTATION DE LA SOURIS
MOLETTE DE LA SOURIS DÉFILEMENT VERTICAL
BOUTON À AILES
CYCLE DPI
INTERNET (SUIVANT)
INDICATEUR BLUETOOTH
BOUTON 5D™
INDICATEUR DPI
INTERNET (PRÉCÉDENT)
BOUTON DE LIBÉRATION DE PILES
REPOSE-PAUME RÉGLABLE
.14
LASER
5 21
MARCHE/ARRÊT
RANGEMENT DE DONGLE
COMPARTIMENT DES PILES
.15
TÉMOINS LUMINEUX (DEL)
5 2
21
Un témoin lumineux reste allumé pendant 1 minute en cas de changement d’état, après quoi il s’éteint pour économiser les piles.
TÉMOINS LUMINEUX COULEUR
Témoin rouge - Indicateur DPI Témoin bleu - Indicateur Bluetooth
MODE DE COUPLAGE
Le témoin bleu clignote toutes les secondes
COUPLAGE EFFECTUÉ ET FONCTIONNEMENT
PILES FAIBLES
TÉMOIN DPI
(5 %) - Le témoin bleu clignote toutes les 2 secondes
Témoin rouge Faible luminosité = Réglage DPI 1 Luminosité totale = Réglage DPI 2
.16
Le témoin bleu clignote toutes les 5 secondes
1
5
2
INSTRUCTIONS D’INSTALLATION
CONNEXION DE LA SOURIS AVEC LE DONGLE
1. Installez les 2 piles AAA dans la souris
2. Branchez le dongle USB sur le port disponible
3. Activez la souris
CONNEXION AUX APPAREILS INTÉGRANT LA TECHNOLOGIE BLUETOOTH
®
SMART (DONGLE NON REQUIS)
TECHNOLOGIE BLUETOOTH SMART
Bluetooth Smart est une nouvelle version économe en énergie de la technologie sans fil Bluetooth déjà utilisée dans de nombreux appareils. Renseignez-vous auprès du fab­ricant de votre périphérique pour savoir si celui-ci est compatible avec la technologie Bluetooth Smart. Renseignez-vous auprès du fabricant de votre périphérique pour obtenir des souris Bluetooth Smart et puis suivez les instructions pour le jumelage.
®
WINDOWS
8
1. Assurez-vous que le dongle USB est débranché, puis allumez le R.A.T.
2. Puis maintenez les boutons Bouton 5D™ et Bouton à ailes enfoncés pendant 5 secondes jusqu’à ce que le voyant bleu se mette à clignoter
3. Déplacez la souris dans l’angle inférieur droit de l’écran pour ouvrir la barre des icônes
4. Cliquez sur Settings (Paramètres)
5. Cliquez sur Change PC Settings (Modifier les par amètres du PC)
6. Cliquez sur Devices (Périphériques)
7. Cliquez sur Add a device (Ajouter un périphérique)
8. Sélectionnez R.A.T.
M
M
TÉLÉCHARGEMENT LOGICIEL
LOGICIEL POUR WINDOWS ET MAC
1. Accédez à l’adresse www.madcatz.com/downloads pour télécharger et installer l’application logicielle de Mad Catz
2. Utilisez l’interface glisser-déposer pour personnaliser votre souris
3. Accédez à la section Support du logiciel pour obtenir les instructions de program mation complètes
.17
INSTRUCTIONS D’INSTALLATION
RÉSOLUTION DES PROBLÈMES
•
Si votre R.A.T.M ne semble pas fonctionner avec votre appareil, allumez-le, puis main­tenez les boutons Bouton à ailes et Bouton 5D™ enfoncés pendant 5 secondes jusqu’à ce que le voyant bleu se mette à clignoter. Si vous souhaitez établir la liaison avec le dongle USB, assurez-vous qu’il est bien branché sur votre ordinateur. Si vous souhaitez établir la liaison avec un autre appareil, suivez la procédure d’appariement Bluetooth pour que cet appareil relance la découverte de R.A.T.
• Avertissement de la FCC & IC (Industry Canada)
• Cet appareil répond aux exigences de la section 15 de la réglementation FCC et aux normes RSS sans
licence d’Industry Canada. Son fonctionnement est soumis aux deux conditions suivantes : (1) Ce périphérique ne doit pas provoquer d’interférences nuisibles et (2) il doit accepter toute interférence reçue, y compris les interférences susceptibles de causer un dysfonctionnement.
• Tout changement ou toute modification n’ayant pas été expressément approuvé(e) par l’entité respon-
sable de la conformité peut annuler le droit de l’utilisateur à se servir de cet équipement.
•
• Déclaration de la FCC relative à l’exposition au rayonnement électromagnétique :
• Ce matériel est conforme aux exigences de la FCC relatives aux limites d’exposition au rayonnement
établies dans le cadre d’un environnement non contrôlé.
• Cet émetteur ne doit pas être combiné à ou fonctionner simultanément avec une autre antenne ou un
autre émetteur.
•
• Déclaration d’IC relativement aux radiofréquences :
• Cet appareil répond aux exigences lui permettant d’être exempté des limites de l’évaluation de routine
exposées à la section 2.5 de la norme RSS 102 et est conforme aux limites d’exposition aux RF établies par la norme RSS-102. Les utilisateurs peuvent obtenir des informations du gouvernement canadien relatives à l’exposition aux RF et à la conformité.
•
• Conformément à la réglementation d’Industry Canada, cet émetteur radio doit uniquement fonctionner
• à l’aide d’une antenne dont le type et le gain maximum (ou moindre) ont été jugés aptes au
• fonctionnement avec l’émetteur par Industry Canada. Pour réduire le risque d’interférence radio pour
• les autres utilisateurs, le type d’antenne et son gain doivent être choisis de façon à ce que la puissance
• isotrope rayonnée équivalente (PIRE) ne dépasse pas celle nécessaire pour une bonne communication.
M
.18
PANORAMICA DEL MOUSE
PULSANTE CENTRALE DEL MOUSE SCORRIMENTO VERTICALE
PULSANTE LATERALE
CICLO DPI
INTERNET AVANTI
INDICATORE BLUETOOTH
PULSANTE 5D
INDICATORE DPI
INTERNET INDIETRO
PULSANTE DI SBLOCCO BATTERIA
POGGIAPOLSI REGOLABILE
.19
PANORAMICA DEL MOUSE
5 21
LASER
ON/ OFF
COMPARTIMENTO ADATTATORE
VANO BATTERIA
.20
INDICADORES LED
5 2
21
Gli indicatori LED rimarranno attivi per un minuto dopo qualsiasi cambiamento dello stato, quindi si spegneranno per risparmiare la batteria.
INDICATORI COLORATI LED
“ LED rosso – Indicatore DPI LED blu – Indicatore Bluetooth
MODALITÀ DI ABBINAMENTO
ABBINATO E FUNZIONANTE
BATTERIA IN ESAURIMENTO
LED DP
Il LED blu lampeggia ogni secondo
Il LED blu lampeggia ogni 5 secondi
(5%) – Il LED blu lampeggia ogni 2 secondi
Scarsa luminosità del LED rosso = Impostazione DPI 1 Luminosità al massimo = Impostazione DPI 2
1
5
2
.21
ISTRUZIONI DI CONFIGURAZIONE
COLLEGAMENTO DEL MOUSE CON L’ADATTATORE
1. Inserire nel mouse 2 batterie ministilo
2. Collegare l’adattatore USB a una porta disponibile
3. Accendere il mouse
CONNESSIONE A DISPOSITIVI CON TECNOLOGIA BLUETOOTH
®
SMART
INTEGRATA (ADATTATORE NON RICHIESTO)
TECNOLOGIA BLUETOOTH SMART
Bluetooth Smart è una nuova versione a risparmio energetico della tecnologia wireless Bluetooth già usata in molti dispositivi. Chiedere al produttore se il dispositivo supporta la tecnologia Bluetooth Smart. Verificare con il produttore del dispositivo per il supporto per i mouse Bluetooth intelligenti e poi seguire le istruzioni per l’accoppiamento.
®
WINDOWS
8
1. Assicurarsi che l’adattatore USB sia scollegato e accendere la R.A.T.
2. Premere e tenere premuta la Pulsante 5D™ e i pulsanti laterale per 5 secondi fino a quando il LED blu non inizia a lampeggiare
3. Spostare il mouse sull’angolo inferiore destro dello schermo per aprire la barra degli accessi
4. Fare clic su Impostazioni
5. Fare clic su Modifica impostazioni PC
6. Fare clic su Dispositivi
7. Fare clic su Aggiungi un dispositivo
8. Selezionare R.A.T.
M
M
.22
ISTRUZIONI DI CONFIGURAZIONE
DESCARGA DE SOFTWARE
SOFTWARE PER WINDOWS E MAC
1. Visitare il sito www.madcatz.com/downloads per scaricare e installare l’applicazione del software Mad Catz
2. Usare l’interfaccia di trascinamento della selezione per personalizzare il mouse
3. Visitare la sezione Supporto del software per istruzioni di programmazione complete
RISOLUZIONE PROBLEMI
•
M
Se la R.A.T. premere e tenere premuta la Pulsante laterale e i pulsanti Pulsante 5D™ per 5 secondi fino a quando il LED blu non inizia a lampeggiare. Se si desidera collegare all’adattatore USB assicurarsi che sia collegato al computer. Se si desidera collegare a un altro dispositivo, seguire la procedura di abbinamento Bluetooth per il dispositivo per ritrovare la R.A.T.
sembra non funzionare con il proprio dispositivo, tenendola accesa,
M
.23
DESCRIPCIÓN GENERAL DEL RATÓN
BOTÓN MEDIO DEL RATÓN DESLIZAMIENTO VERTICAL
BOTÓN ALA
CICLO DPI
VERSIONES POSTERIORES DE INTERNET
INDICADOR DE BLUETOOTH
BOTÓN 5D
INDICADOR DPI
VERSIONES ANTERIORES DE INTERNET
BOTÓN PARA LIBERAR LA BATERÍA
APOYAMANOS AJUSTABLE
.24
LASER
5 21
ENCENDIDO APAGADO
ALMACENAMIENTO DE LLAVE ELÉCTRICA
COMPARTIMIENTO DE LAS BATERÍAS
.25
INDICADORES LED
5 2
21
El indicador LED permanecerá activo durante un minuto al momento de un cambio de estado, luego de lo cual se apagará para preservar la batería.
INDICADORES DE COLOR LED
“ LED roja – indicador DPI LED azul – indicador de Bluetooth
MODO DE EMPAREJAMIENTO
SINCRONIZADO Y FUNCIONANDO
BATERÍA BAJA
LED DPI
El LED azul parpadea una vez por segundo
El LED azul parpadea cada 5 segundos
(5%) - El LED azul parpadea cada 2 segundos
Brillo bajo del LED rojo = Configuración DPI 1 Brillo total = Configuración DPI 2
.26
1
5
2
INSTRUCCIONES DE CONFIGURACIÓN
CONECTAR EL RATÓN USANDO LA LLAVE ELECTRÓNICA
1. Insertar las 2 x baterías AAA en el ratón
2. Enchufar la llave electrónica USB en el puerto disponible
3. Encender el ratón
CONECTARSE A DISPOSITIVOS CON TECNOLOGÍA BLUETOOTH
®
SMART
INCORPORADO (NO SE REQUIERE LLAVE ELECTRÓNICA)
TECNOLOGÍA BLUETOOTH SMART
El Bluetooth Smart es una nueva versión que ahorra energía de tecnología inalámbrica Bluetooth y ya se usa en muchos dispositivos. Consulte con el fabricante para ver si es Bluetooth Smart ready. Consulte con el fabricante del dispositivo de apoyo para los ratones Bluetooth inteligentes y siga sus instrucciones para el emparejamiento.
®
WINDOWS
8
M
1. Asegúrese de que la llave USB esté desconectada y encienda el R.A.T.
2. Presione y mantenga apretados los botones 5D™ y Botón ala durante 5 segundos hasta que el LED azul comience a titilar.
3. Mueva el ratón a la esquina inferior derecha de la pantalla para abrir la barra Charms
4. Haga clic en configuraciones
5. Haga clic en Cambiar configuraciones de PC
6. Haga clic en Dispositivos
7. Haga clic en Agregar un dispositivo
8. Seleccione R.A.T.
M
.27
INSTRUCCIONES DE CONFIGURACIÓN
DESCARGA DE SOFTWARE
SOFTWARE PARA WINDOWS Y MAC
1. Visite www.madcatz.com/downloads para descargar e instalar la aplicación del software Mad Catz
2. Use la interfaz de arrastrar y soltar para personalizar su ratón
3. Visite la sección Soporte del software para recibir instrucciones completas de programación
SOLUCIÓN DE PROBLEMAS
•
Si el R.A.T.M no parece funcionar con el dispositivo entonces, encendido, presione y mantenga apretados los botones Botón ala y Botón 5D™ durante 5 segundos hasta que el LED azul comience a titilar. Si desea conectar la llave USB asegúrese de que esté conectada a su computadora. Si desea conectar otro dispositivo, siga el procedimiento para emparejamiento de Bluetooth para que dicho dispositivo vuelva a detectar el R.A.T.M.
.28
MUSÖVERSIKT
MITTERSTA MUSKNAPPEN VERTIKAL RULLNING
VINGKNAPP
DPI CYCLE
INTERNET FRAMÅT
BLUETOOTH-INDIKATOR
5D™-KNAPP
DPI-INDIKATOR
INTERNET BAKÅT
BATTERIFRIGÖRINGSKNAPP
JUSTERBART HANDSTÖD
.29
MUSÖVERSIKT
5 21
LASER
PÅ/AV
DONGLEFÖRVARING
BATTERIFACK
.30
LED-INDIKATORER
5 2
21
LED-indikatorn förblir aktiv i en minut efter statusändring, sedan slocknar den för att spara på batteriet.
LED-FÄRGIN DIKATORER
“ Röd LED - DPI-indikator Blå LED - Bluetooth-indikator
KOPPLINGSLÄGE
LÄNKAD OCH IGÅNG
LÅGT BATTERI
DPI LED
Blå LED blinkar en gång i sekunden
Blå LED pulserar var femte sekund
(5 %) Blå LED pulserar varannan sekund
Röd LED svag ljusstyrka = DPI-inställning 1 Full ljusstyrka = DPI-inställning 2
.31
1
5
2
ISTALLATIONSANVISNINGAR
ANSLUT MUSEN MED HJÄLP AV DONGLE
1. Sätt i 2 x AAA-batterier i musen
2. Sätt i USB-dongle i en tillgänglig port
3. Slå på musen
®
ANSLUTNING TILL APPARATER MED INBYGGD BLUETOOTH SMART-TEKNOLOGI (DONGLE BEHÖVS INTE)
BLUETOOTH SMART TEKNOLOGI
Bluetooth Smart är en ny energisnål version av trådlös Bluetooth-teknologi och används redan i måna apparater. Kontrollera hos tillverkaren av din apparat om den är redo för Bluetooth Smart. Kontrollera med din enhet för support för Bluetooth Smart möss och följ deras anvisningar för att koppla ihop.
®
WINDOWS
8
1. Kontrollera att USB-dongle kopplats ur och slå på R.A.T.
2. Tryck sedan in och håll inne 5D™- och Ving-knapparna i 5 sekunder tills den blå LED-lampan börjar blinka.För markören till nedre högra hörnet på skärmen för att öppna snabbknappsfältet
3. För markören till nedre högra hörnet på skärmen för att öppna snabbknappsfältet
4. Klicka på Inställningar
5. Klicka på Ändra datorinställningar
6. Klicka på Enheter
7. Klicka på Lägg till en enhet
8. Välj R.A.T.
M
M
.32
ISTALLATIONSANVISNINGAR
HÄMTNING AV PROGRAMVARA
PROGRAMVARA FÖR WINDOWS OCH MAC
1. Gå till www.madcatz.com/downloads för att hämta och installera Mad Catz programvara
2. Använd gränssnittet med dra och släpp och att anpassa din mus
3. Gå till Support i programvaran för fullständiga programmeringsanvisningar
PROBLEMLÖSNING
•
Om din R.A.T.M inte verkar fungera med din enhet, slå på den och tryck sedan in och håll inne Vingknapp- och 5D™-knapparna i 5 sekunder tills den blå LED-lampan börjar blinka. Om du vill ansluta till USB-dongle ska du kontrollera att den är ansluten till din dator. Om du vill ansluta till en annan enhet ska du följa Bluetooth-pairingproceduren för den enheten för att återupptäcka R.A.T.
M
.33
OVERSIGT OVER MUS
MELLEMSTE MUSEKNAP LODRET RULLETAST
VINGEKNAP
DPI CYKLUS
INTERNET FREMAD
BLUETOOTH-INDIKATOR
-KNAP
5D
DPI-INDIKATOR
INTERNET BAGUD
BATTERIUDLØSNINGSKNAP
JUSTERBAR HÅNDLEDSSTØTTE
.34
LASER
5 21
TÆND/SLUK
OPBEVARING AF DONGLE
BATTERIBEHOLDER
.35
LYSDIODER
5 2
21
LED-indikationen vil aktiveres i et minut efter hvert statusskifte, og derefter slukkes for at spare på batteriet.
LED-FARVEINDIKATORER
“ Rød LED - DPI-indikator Blå LED - Bluetooth-indikator
PARRINGSTILSTAND
PARRET OG I DRIFT
LAVT BATTERI
DPI-LED
Blå LED blinker en gang i sekunde
Blå LED pulserer hvert 5. sekund
(5 %) - Blå LED pulserer hvert 2. sekund
Rød LED lav lysstyrke = DPI-indstilling 1 Fuld lysstyrke = DPI-indstilling 2
.36
1
5
2
OPSÆTNINGSVEJLEDNING
TILSLUTNING AF MUSEN VHA. DONGLE
1. Sæt 2 x AAA-batterier i musen
2. Sæt USB-donglen i en åben port
3. Tænd for musen
TILSLUTNING TIL ENHEDER MED INDBYGGET BLUETOOTH
®
SMART-
TEKNOLOGI (KRÆVER DONGLE)
BLUETOOTH SMART-TEKNOLOGI
Bluetooth Smart er en ny, strømeffektiv version af den trådløse Bluetooth-teknologi, som allerede anvendes af mange enheder. Kontrollér hos din producent, om din enhed kan bruge Bluetooth Smart. Check med producenten af enheden for support til Blue­tooth Smart mus og derefter følge deres instrukser til parring.
®
WINDOWS
8
M
1. Sørg for, at USB-donglen ikke er sat i, og tænd for R.A.T.
2. Trykke og holde 5D™’et og Vinge-knapperne nede i 5 sekunder, indtil den blå LED begynder at blinke.
3. Flyt markøren til skærmens nederste højre hjørne for at åbne Amulet-baren
4. Klik på Indstillinger
5. Klik på Redigér PC-indstillinger
6. Klik på Enheder
7. Klik på Tilføj en enhed
8. Vælg R.A.T.
M
et
.37
OPSÆTNINGSVEJLEDNING
SOFTWARE INSTALLATION
SOFTWARE TIL WINDOWS OG MAC
1. Gå til www.madcatz.com/downloads for at downloade og installere Mad Catz-softwareapplikationen
2. Brug træk-og-slip-interfacet til at brugertilpasse din mus
3. Se softwarens Support-sektion for komplet programmeringsvejledning
FEJLFINDING
•
Hvis dit R.A.T.M ikke ser ud til at fungere sammen med din enhed, skal du, når enheden er tændt, trykke og holde Vingeknap’et og 5D™-knapperne nede i 5 sekunder, indtil den blå LED begynder at blinke. Hvis du ønsker at tilslutte USB-donglen, skal du sørge for, at den er tilsluttet til din computer. Hvis du ønsker at tilslutte til en anden enhed, skal du følge parringsproceduren for Bluetooth for denne enhed for at genopdage R.A.T.Met
.38
DESCRIÇÃO GERAL DO RATO
BOTÃO CENTRAL DO RATO DESLOCAMENTO VERTICAL
BOTÃO LATERAL
CICLO PPP
INTERNET SEGUINTE
INDICADOR BLUETOOTH
BOTÃO 5D
INDICADOR PPP
INTERNET ANTERIOR
BOTÃO DE LIBERTAÇÃO DAS PILHAS
APOIO DA PALMA AJUSTÁVEL
.39
DESCRIÇÃO GERAL DO RATO
5 21
LASER
LIGAR/ DESLIGAR
ARMAZENAMENTO DA DONGLE
COMPARTIMENTO DAS PILHAS
.40
INDICADORES LED
5 2
21
A indicação do LED permanecerá activa durante um minuto depois de qualquer alteração de estado, após o que se apagará para poupar as pilhas.
INDICADORES LED COLORIDOS
LED vermelho - Indicador PPP LED azul - Indicador Bluetooth
MODO DE EMPARELHAMENTO
O LED azul pisca uma vez por segundo
EMPARELHADO E EM FUNCIONAMENTO
PILHAS FRACAS
LED PPP
(5%) - O LED azul pulsa de 2 x segundos
LED vermelho com intensidade reduzida = Definição PPP 1 Intensidade total = Definição PPP 2
O LED azul pulsa de 2x segundos
.41
1
5
2
INSTRUÇÕES DE CONFIGURAÇÃO
LIGAR O RATO UTILIZANDO A DONGLE
1. Insira 2 pilhas AAA no rato
2. Ligue a dongle USB a uma porta disponível
3. Ligue o rato
LIGAR A DISPOSITIVOS COM TECNOLOGIA BLUETOOTH
®
SMART
INCORPORADA (NÃO É NECESSÁRIA DONGLE)
TECNOLOGIA BLUETOOTH SMART
Bluetooth Smart é uma nova versão da tecnologia sem fios Bluetooth, eficiente em termos energéticos, que já é utilizada em muitos dispositivos. Verifique junto do fabricante do seu dispositivo o suporte de Bluetooth Smart. Verifique com o fabricante do dispositivo de apoio para os ratos Bluetooth inteligentes e siga as instruções para o emparelhamento.
®
WINDOWS
8
1. Certifique-se de que o dongle USB está desligado e ligue o R.A.T.
2. Mantenha premidos os botões Lateral e 5D™ durante 5 segundos, até o LED azul ficar intermitente.
3. Mova o rato para o canto inferior direito do ecrã para abrir a barra Atalhos
4. Clique em Definições
5. Clique em Alterar definições do PC
6. Clique em Dispositivos
7. Clique em Adicionar um dispositivo
8. Seleccione o R.A.T.
M
M
.42
INSTRUÇÕES DE CONFIGURAÇÃO
TRANSFERÊNCIA DE SOFTWARE
SOFTWARE PARA WINDOWS E MAC
1. Visite www.madcatz.com/downloads para transferir e instalar a aplicação Mad Catz
2. Utilize a interface de arrastar e largar para personalizar o seu rato
3. Consulte a secção Suporte do software para obter instruções completas de programação
RESOLUÇÃO DE PROBLEMAS
•
Se o R.A.T.M não estiver a funcionar com o seu dispositivo, com este ligado, mantenha premidos os botões Lateral Botão 5D™ durante 5 segundos, até o LED azul ficar intermitente. Se pretender ligar ao dongle USB, certifique-se de que está ligado ao seu computador. Se pretender ligar a outro dispositivo, siga o procedimento de emparelhamento Bluetooth desse dispositivo para detetar novamente o R.A.T.
.43
M
©2013 Mad Catz, Inc. 7480 Mission Valley Road, Suite 101, San Diego, CA 92108 U.S.A. Mad Catz, R.A.T., GameSmart, and the Mad Catz logo are trademarks or registered trademarks of Mad Catz Interactive, Inc., its subsidiaries and affiliates. Covered by U.S. Patent No. 6,157,370. The shape and design of this product are a trade dress of Mad Catz Interactive, Inc., its subsidiaries and affiliates. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Mad Catz Interactive Inc. is under license. All other trademarks or registered trademarks are the property of their respective owners. Made in China. All rights reserved. Product features, appearance and specifications may be subject to change without notice. Please retain this information for future reference.
©2013 Mad Catz Europe, Ltd. 1-2 Shenley Pavilions, Chalkdell Drive. Shenley Wood, Milton Keynes, Buckinghamshire MK5 6LB, Royaume-Uni (UK). Mad Catz, R.A.T., GameSmart, et le logo Mad Catz sont des marques de commerce ou des marques déposées de Mad Catz Interactive, Inc., de ses filiales et sociétés affiliées. Couvert par le Brevet Américain No. 6,157,370. La forme et le design de ce produit sont caractéristiques de la marque Mad Catz Interactive, Inc., de ses filiales et sociétés affiliées. Le mot, la marque et les logos Bluetooth® sont la propriété de Bluetooth SIG, Inc. et toute utilisation de ces marques par Mad Catz, Inc. est faite sous licence. Toutes les autres marques ou marques déposées sont la propriété de leurs propriétaires respectifs. Fabriqué en Chine. Tous droits réservés. L’aspect, les fonctionnalités et les spécifications du produit peuvent changer sans préavis. Veuillez conserver cette notice pour référence ultérieure.
Mad Catz is a publicly traded company on the TSX/NYSE MKT, symbol MCZ. Mad Catz ist ein börsennotiertes Unternehmen (TSX, NYSE MKT: MCZ). Les actions de Mad Catz sont cotées en bourse sur le TSX/NYSE MKT sous le symbole MCZ.
MOUSE
R 211-121005
FCC ID: P25R243710A4512C IC: 4633A-43710AC
KCC-CRM-MAD-43710C
DONGLE
R 211-121007
FCC ID: VHVBTVD1154 IC: 4633A-43710AR
KCC-CRM-MAD-43710R
R21-MCB43710
Loading...
