Pro Flight Headset

Saitek

®

USER MANUAL

BEDIENUNGSANLEITUNG

GUIDE D’UTILISATION

MANUALE D’USO

MANUAL DEL USUARIO

Pro_Flight_headset.qxd 28/08/2008 08:59 Page 1

volume

Saitek

SERIES

PRO FLIGHT

2

SAITEK PRO FLIGHT HEADSET

Congratulations on buying the Saitek Pro Flight Headset. Constructed using high grade materials
and closely modeled on professional pilot headsets, the Saitek Pro Flight Headset heightens the
realism of your flight simulation experience.

Features

Installing the headset

Plug the green mini jackplug into your PC’s green sound out
socket and the pink mini jackplug into your PC’s sound in
socket.

Adjust the width of your headphones by pulling or pushing the
earpiece stalks in or out of the headband cushion.

Ensure your PC’s sound settings are not muted or at zero by clicking on Windows Start, Settings,
Control Panel, Sounds and Audio Devices. Device volume should be around the mid point on the
slider and the Mute box unchecked.

Make sure the volume control on your headphones is set to zero and, with a sound source or
game playing, gradually increase headphone volume to the desired level.

To mute the microphone, press the red button on the outside of the microphone unit.

WARNING: Prolonged use at high volume may damage your hearing.
Technical Support

Nearly all the products that are returned to us as faulty are not faulty at all - they have just not
been installed properly.

If you experience any difficulty with this product, please first visit our website www.saitek.com. The
technical support area will provide you with all the information you need to get the most out of your
product and should solve any problems you might have.

If you do not have access to the internet, or if the website cannot answer your question, please
contact your local Saitek Technical Support Team. We aim to offer quick, comprehensive and
thorough technical support to all our users so, before you call, please make sure you have all the
relevant information at hand.

To find your local Saitek Technical Support Center, please see the separate Technical Support
Center sheet that came packaged with this product.

Conditions of Warranty

1. Warranty period is 2 years from date of purchase with proof of purchase submitted.

2. Operating instructions must be followed.

3. Specifically excludes any damages associated with leakage of batteries.
Note: Batteries can leak when left unused in a product for a period of time, so it is advisable to

inspect batteries regularly.

Saitek

volume

PRO FLIGHT

SE

RIES

Saitek

volume

PRO FLIGHT

SERIES

Cushioned headband prevents
'hotspots

Comfortable cushions provide
passive noise cancelling

Responsive microphone
including mute switch

Integrated volume control

Pink

Green

3

Pro_Flight_headset.qxd 28/08/2008 08:59 Page 2

FCC Compliance and Advisory Statement

Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:

1. This device may not cause harmful interference, and;

2. This device must accept any interference received, including interference that may cause
undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:

- Reorient or relocate the receiving antenna;

- Increase the separation between the equipment and receiver;

- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected;

- Consult the dealer or an experienced radio/TV technician for help.

Mad Catz, Inc, 7480 Mission Valley Rd, Suite 101, San Diego, CA92108-4406

Canada ICES-003

Operation is subject to the following two conditions:

1. This device may not cause interference, and;

2. This device must accept any interference, including interference that may cause undesired
operation of the device.

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

54

4. Product must not have been damaged as a result of defacement, misuse, abuse, neglect,
accident, destruction or alteration of the serial number, improper electrical voltages or currents,
repair, alteration or maintenance by any person or party other than our own service facility or
an authorized service center, use or installation of non-Saitek replacement parts in the product
or the modification of this product in any way, or the incorporation of this product into any other
products, or damage to the product caused by accident, fire, floods, lightning, or acts of God, or
any use violative of instructions furnished by Saitek plc.

5. Obligations of Saitek shall be limited to repair or replacement with the same or similar unit, at
our option. To obtain repairs under this warranty, present the product and proof of purchase
(eg, bill or invoice) to the authorized Saitek Technical Support Center (listed on the separate
sheet packaged with this product) transportation charges prepaid. Any requirements that
conflict with any state or Federal laws, rules and/or obligations shall not be enforceable in that
particular territory and Saitek will adhere to those laws, rules, and/or obligations.

6. When returning the product for repair, please pack it very carefully, preferably using the original
packaging materials. Please also include an explanatory note.

IMPORTANT: To save yourself unnecessary cost and inconvenience, please check carefully
that you have read and followed the instructions in this manual.

This warranty is in Lieu of all other expressed warranties, obligations or liabilities. ANY
IMPLIED WARRANTIES, OBLIGATIONS, OR LIABILITIES, INCLUDING BUT NOT LIMITED
TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALLBE LIMITED IN DURATION TO THE DURATION OF THIS
WRITTEN LIMITED WARRANTY. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitations may not apply to you. IN NO EVENT SHALL WE BE
LIABLE FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER Some states do not allow
the exclusion or limitation of special, incidental or consequential damages, so the above
limitation may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.

This symbol on the product or in the instructions means that your electrical and electronic
equipment should be disposed at the end of its life separately from your
household waste. There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where
you purchased the product.

Pro_Flight_headset.qxd 28/08/2008 08:59 Page 4

Installation des Headsets

Stecken Sie den grünen Ministecker in die grüne Sound­Ausgangsbuchse Ihres PCs und den pinkfarbenen Ministecker
in die Sound-Eingangsbuchse Ihres PCs.

Stellen Sie die Weite Ihrer Kopfhörer durch Ziehen oder
Drücken der Ohrhörerträger in das oder aus dem
Kopfbandpolster.

Stellen Sie sicher, dass die Soundeinstellungen Ihres PCs nicht stummgeschaltet sind oder auf
Null stehen, indem Sie auf Windows Start, Einstellungen, Systemsteuerung, Sounds und
Audiogeräte klicken. Die Lautstärke des Geräts sollte sich etwa in der Mitte des Schiebereglers
befinden und das Stumm-Kästchen nicht markiert sein.

Stellen Sie sicher, dass die Lautstärkeregelung Ihrer Kopfhörer auf Null gestellt ist und erhöhen Sie
die Kopfhörerlautstärke bei einer laufenden Tonquelle oder einem Spiel stufenweise bis zum
gewünschten Pegel.

Um das Mikrofon stumm zu schalten, drücken Sie den roten Knopf auf der Außenseite der
Mikrofoneinheit.

WARNUNG: Ein anhaltender Gebrauch bei hoher Lautstärke könnte Ihr Gehör schädigen.

Technischer Support
Probleme - keine Angst, wir lassen Sie nicht im Stich!

Wussten Sie, dass fast alle Produkte, die als fehlerhaft an uns zurückgeschickt werden, überhaupt
nicht defekt sind? Sie wurden einfach nicht richtig installiert!

Sollten Sie Probleme mit diesem Produkt haben, besuchen Sie bitte zuerst unsere Website
www.saitek.de. Unsere Website, speziell der Bereich Technischer Support, wurde erstellt, damit
Sie von Ihrem Saitek-Produkt die bestmögliche Leistung erhalten.

Sollten Sie trotzdem noch Probleme haben oder kein Internetanschluss haben, dann stehen Ihnen
unsere Produktspezialisten im Saitek Technical Support Team zur Verfügung, die Sie telefonisch
um Rat und Hilfe bitten können.

Wir möchten, dass Sie viel Freude an Ihrem Gerät haben. Bitte rufen Sie uns an, falls Sie
Probleme oder Fragen haben. Bitte stellen Sie auch sicher, dass Sie alle relevanten Informationen
zu Hand haben, bevor Sie anrufen.

Rufnummern und Adressen finden Sie auf der mit dem Produkt gelieferten Liste der Zentren für
Technischen Support.

7

SAITEK PRO FLIGHT HEADSET

Herzlichen Glückwunsch zum Kauf des Saitek Pro Flight Headset. Das aus hochgradigen
Materialien und in enger Anlehnung an professionelle Piloten-Headsets konstruierte Saitek Pro
Flight Headset steigert den Realismus Ihrer Flugsimulatorerfahrung.

Eigenschaften

6

Saitek

volume

PRO FLIGHT

SERIES

Saitek

volume

PRO FLIGHT

SERIES

Gepolstertes Kopfband
verhindet Druckstellen

Komfortable Polster gewähren
passive Geräuschunterdrückung

Reaktionsfreudiges Mikrofon
inklusive Stummschaltung

Integrierter Lautstärkeregler

Pink

Grün
