Sirius Kit 7 LED x 3W RGB 3in1 + Stand
MANUAL DE USUARIO/ USER MANUAL
User Manual | Sirius Kit 7 LED x 3W RGB 3in1 + Stand | Triton Blue | Rev.Jan. 2014 | www.triton-blue.com
For your own safety, please read this user manual carefully before
you initially start-up.
Every person involved with the installation, operation and maintenance of this device has to:
• Be qualied.
• Follow the instructions of this manual.
• Consider this manual to be part of the total product.
• Keep this manual for the entire service life of the product.
• Pass this manual on to every further owner or use of the product
• Download the last version of the user manual from the internet in www.triton-blue.com
Unpacking:
Thank you for purchasing the TS105. Every TS105 has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the ship¬ping carton for damage that
may have occurred during shipping. If the carton appears to be damaged, carefully inspect your
xture for any damage and be sure all equipment necessary to operate the unit has arrived
intact. In the event damage has been found or parts are miss¬ing, please contact our toll free
customer support number for further instructions. Please do not return this unit to your dealer
without con¬tacting customer support rst.
Introduction:
The Product is a three channel or ve channel or fourteen channel The xture can operate in
three different oper¬ating modes; DMX control, sound-active, or in a Master/Slave congu¬ration. The TS105 comes with several built in programs that can be used, while operating as a
dimmer unit or when used in multiples linked in a master/slave conguration. For best results
use fog or special effects smoke to enhance the beams projections.
Warning:
To prevent or reduce the risk of electrical hock or re, do not expose this unit to rain or moisture.
This may cause severe eye damage. Avoid looking directly into the light source at all times.
User Manual | Sirius Kit 7 LED x 3W RGB 3in1 + Stand | Triton Blue | Rev.Jan. 2014 | www.triton-blue.com
2
On-Board System Menu
The TS105 comes with an easy to navigate system menu. This next section will detail the functions of each command in the system menu. Please read the next section thoroughly!
To access the main menu press the ESC button. Press the UP or DOWN buttons until you reach
function you wish to change. When you reach the function you wish to change press the ENTER button. When a func¬tion is selected use the UP or Down buttons to change the function
settings. Once your changes are made press the ENTER button,
Addr - DMX Address Setting via control board and mother sting
1. Press the ESC button and UP button or
DOWN button until “Addr” is displayed, press
ENTER.
2. “Axxx” will now be displayed “x” represents the displayed address. Press the UP or
DOWN buttons to nd your desired address.
Auto - This menu will let you select
your desired auto mode
1. Press the ESC button and UP button or
DOWN button until “Auto” is displayed, press
ENTER.
2. “Autx” will now be displayed You can conrm auto modes by UP or DOWN.
3. Then press ENTER, “sp x” will be displayed “x” representing a number between 1-9.
Press the UP or DOWN buttons to set the
auto speed. That soun.
SoUn - This menu will let you select your desired sound mode
1. Press the MENU button until “Soun” is displayed, press ENTER.
2. “Soux” will now be displayed, You can conrm three modes by UP or DOWN for sound
mode. “ x” representing a number between 1-3. Then press the ENTER.
3. “sp x” will be displayed , “x” representing a number between 1-9. Press the UP or DOWN
buttons to set the sound speed that,
ChAS - This menu will let you select your desired chase mode
1. Press the ESC button and UP button or DOWN button until “ChAS” is displayed, press ENTER.
2. “C x” will now be displayed You can conrm chase modes by UP or DOWN. ENTER.
3. Then press ENTER, “sp x“ will be displayed, “x“ representing a number between 1-9. Press the
UP or DOWN buttons to set the chase speed.
User Manual | Sirius Kit 7 LED x 3W RGB 3in1 + Stand | Triton Blue | Rev.Jan. 2014 | www.triton-blue.com
3
Colo - This menu will let you select your desired colour mode
1. Press the ESC button and UP button or DOWN button until “CoLo” is displayed, press ENTER.
2. Either “CoL X”, “X” representing a number between 1-9 or “AtF ” will be displayed. Press the
UP or DOWN buttons to select either a static color or “AtF ” mode. If you select “AtF ”,and press
ENTER and it will be set the Red brightness., the green brightness and blue brightness.
Chnd - This menu will let you select your desired DMX Channel mode.
1. Press the ESC button and UP button or DOWN button until “Chnd” is displayed, press
2. “X Ch” will now be displayed “X” represents the displayed DMX channel mode. Press the UP
or DOWN buttons to nd your desired Channel mode.
DMX Value and function ve channels
User Manual | Sirius Kit 7 LED x 3W RGB 3in1 + Stand | Triton Blue | Rev.Jan. 2014 | www.triton-blue.com
4
DMX Value and function fourteen channels
User Manual | Sirius Kit 7 LED x 3W RGB 3in1 + Stand | Triton Blue | Rev.Jan. 2014 | www.triton-blue.com
5
SLav- This menu will let you select your desired Master/slave mode
Press the MENU button until “SLav” is displayed, press ENTER.
VER - This will display the software version
Press the MENU button until “VER” is displayed. Press the ENTER button and the software version will be displayed.
On – Foot controller System Menu
The TS105 comes with an easy to navigate system menu for foot controller. This next section will
detail the functions of each command in the system menu. Please read the next section thoroughly!
To access the auto mode press the “AUTO” button. Press the “SOUND” button set your function
for sound mode. Press the COLOR button set your function for color mode. Press the BLACKOUT
button the LED is all dark, and then press it more , the xture will run;
BUTTON F UNC T I ON
AUTO Press it to auto mode,then press to change auto mode
SOUND Press it to sound mode,then press to change sound mode
COLOR Press it to color mode,then press to change color mode
BLACKOUT Press it all LED dark,then press to restore the current state
Control mode:
This function will allow you to control each individual xtures traits with a standard DMX-512 controller such as the Elation Show Designer.
Universal DMX Control:
This function allows you to use a uni¬versal DMX-512 controller such as the Elation DMX Operator or Elation Show Designer to control head movement, A DMX controller allows you to create
unique programs tailored to your individual needs.
1. The TS105 uses two DMX channel modes. See next for detailed description of the DMX traits.
2. This will allow you to create your own programs.
User Manual | Sirius Kit 7 LED x 3W RGB 3in1 + Stand | Triton Blue | Rev.Jan. 2014 | www.triton-blue.com
6
Features of TS105
• Model: TS105
• Voltage: 100~240V/ 50~60Hz
• Power Consumption: 90W
• LED Qty: 4 X 7 3W (3 in 1)LEDs total have 28 pcs LED
• Beam angle: 25°
• Weight: 12kgs
• Fuse: 1A(250V)
• DMX: 5 channels/14 channels
• Sound Active: Yes
• RGB Color Mixing
• Color Strobe Effect
• Color Mix Effect
• LED Chases (Adjustable Speeds)
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3 Operating Modes - Sound Active, Show Mode, or DMX Control
• DMX-512 Protocol Compatible (Uses ve, fourteen, DMX Channels)
• Digital Display for Address and Function Setting
• Each xture can be operate independently.
