SmartRack 15U Low-Profile Switch-Depth Wall­Mount Rack Enclosure Cabinet, Hinged Back

MODEL NUMBER: SRW15US

Wall-mount cabinet secures and organizes 15U of 19-inch rack equipment in network closets, classrooms
and other locations with limited floor space. Houses network switches and patch panels up to 20.5 inches
deep.

Description

The SRW15US SmartRack 15U Low-Profile Switch-Depth Wall-Mount Rack Enclosure Cabinet is
designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations,
classrooms, back offices and other areas with limited floor space where you need equipment to be secure,
organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated
finish, the cabinet has a maximum load capacity of 200 pounds.

Highlights

●

Maximum load capacity of 200
lb.

●

Swings away from wall on hinge
for easy back-door access

●

Locking steel cabinet vented at
sides, front, top and bottom

●

Flow-through ventilation keeps
equipment cool

●

Secures 15U of 19 in. rack
equipment up to 20.5 in. deep

Package Includes

●

SRW15US SmartRack 15U
Low-Profile Switch-Depth Wall­Mount Rack Enclosure Cabinet

●

(20) M6 screws

●

(20) M6 cage nuts

●

(20) M6 washers

●

(20) 12-24 screws

●

(2) Keys

●

Owner’s manual

The cabinet swings away from the wall on a sturdy hinge, allowing easy back-door access to equipment
and cabling during installation and maintenance. The doors and side panels lock securely to help prevent
damage, tampering or theft. The front, top, bottom and removable side panels are vented, which allows air
to flow freely and keep equipment cool. The reversible doors can open left or right by rotating the cabinet
180° before mounting. Convenient top and bottom ports allow easy cable routing.

The SRW15US comes fully assembled and ready to mount to the wall, or use Tripp Lite’s optional
SRCASTER rolling caster kit to make it a mobile rack. Square and 12-24 threaded mounting holes and
numbered rack spaces make equipment installation easy. The vertical mounting rails adjust in 7/8-inch
increments to accommodate equipment up to 20.5 inches deep, such as network switches and patch
panels.

Features

Saves Valuable Workspace

●

Perfect for network wiring closets, retail locations, classrooms, back offices and other areas with limited
floor space where you need equipment to be secure, organized and out of the way

1 / 3

●

Houses EIA-standard 19 in. rack equipment in 15U of space

●

Maximum load capacity of 200 lb.

Hinged Cabinet for Convenient Access

●

Swings away from the wall to allow easy back-door access to equipment and cabling during installation
and maintenance

●

Rotate cabinet 180° before mounting to open reversible doors left or right

Keeps Important Equipment Secure

●

Side panels and doors lock securely to help prevent damage, tampering or theft

●

Vented panels allow generous airflow that keeps equipment cool

●

Convenient ports with removable covers allow cable routing through top and bottom

Easy Enclosure and Equipment Installation

●

Ships fully assembled for quick installation

●

Mounts to wall or rolls on floor with Tripp Lite’s optional SRCASTER caster kit

●

Wall-mounting holes spaced 16 in. apart for standard wall stud placement

●

Vertical mounting rails adjust in 7/8 in. increments to accommodate equipment up to 20.5 in. deep, such
as network switches and patch panels

●

Rails support square-hole or 12-24 threaded-hole mounting

●

Rack spaces numbered for easy reference

Meets Payment Card Industry Standards

●

Provides physical equipment and media security required for PCI DSS (Payment Card Industry Data
Security Standard) compliance

Specifications

OVERVIEW

UPC Code 037332183866

PHYSICAL

Rack Height 15U
Maximum Device Depth (in.) 20.5
Maximum Device Depth (cm) 52.07
Minimum Device Depth (in.) 3
Minimum Device Depth (cm) 7.62
Shipping Dimensions (hwd / in.) 24.10 x 33.07 x 26.38

2 / 3

Shipping Dimensions (hwd / cm) 61.21 x 84.00 x 67.01
Shipping Weight (lbs.) 73.00
Shipping Weight (kg) 33.11
Unit Dimensions (hwd / in.) 30.33 x 23.62 x 21.6
Unit Dimensions (hwd / cm) 77.04 x 59.99 x 54.86
Unit Weight (lbs.) 88.2
Unit Weight (kg) 40.01
Color Black
Weight Capacity - Stationary (lbs.) 200
Weight Capacity - Stationary (kg) 91
Factory Preset Rack Depth (in.) 10.42
Factory Preset Rack Depth (cm) 26.5
Cable Access Hole Measurement

(inches)
Factory Preset Rack Depth (mm) 265
Maximum Device Depth (mm) 521
Minimum Device Depth (mm) 76

SPECIAL FEATURES

Grounding Lug Front and Back door frames

CERTIFICATIONS

Approvals UL/CSA 60950-1, EIA-310-E, IEC 60297-3-100, IP20 Protection Rating, RoHS

WARRANTY

Product Warranty Period
(Worldwide)

9.812 x 2.35 (l x w)

5-year limited warranty
