USB-C Memory Card Reader, 2-in-1 USB-A/USBC, USB 3.1 Gen 1
MODEL NUMBER: U452-000-SD-A
Highlights
●
Built-in USB-A and USB-C male
connectors are compatible with
most devices
●
USB 3.1 Gen 1 data transfer
speeds up to 5 Gbps for fast file
sharing
●
Supports latest SD and Micro
SD formats, including SDXC
and SDHC
●
Easy plug-and-play
operation—no new software or
drivers required
●
Fits easily into camera bag or
laptop sleeve for use anywhere
Transfers memory card data to your MacBook, PC, phone or laptop via your device’s USB-A, USB-C or
Thunderbolt 3 port.
Features
High-Speed Data Transfer to Almost Any Desktop or Mobile Device
If your MacBook, Chromebook, PC, tablet, smartphone or laptop has no built-in memory card reader, but
does have a USB-A, USB-C or Thunderbolt 3 port, this USB 3.1 memory card reader is an essential data
storage tool. It easily transfers photos, documents, HD video and other files from a wide variety of memory
cards to your device. Because this unit has both USB-A and USB-C plugs, you save the expense of
buying multiple memory card readers.
USB Connectors Built Into Either End Connect to Almost Any Device
Just insert an SD or Micro SD card into the USB card reader’s slot, and then plug the built-in USB-A or
USB-C male connector into your MacBook, Chromebook, PC, tablet, smartphone or laptop to begin
reading files. Removable caps protect the connectors from damage and debris.
Immediate Read/Write Access to Almost Any SD or Micro SD Card
The two built-in memory card slots supports all the latest formats, including SDXC (Secure Digital
Extended Capacity) and SDHC (Secure Digital High Capacity). An LED next to the slots let you know data
is being transferred. The slots are hot-swappable, so you can exchange cards while the unit remains
connected to your MacBook, Chromebook, PC, tablet, smartphone or laptop.
Transfers Data at Rapid Speeds Up to 5 Gbps
If your MacBook, Chromebook, PC, tablet, smartphone or laptop has a USB 3.0 port, this memory card
reader transfers digital photos and other files at speeds up to 5 Gbps, which is 10 times faster than USB
2.0 card readers. It’s backward compatible with previous USB generations, including 2.0 and 1.1, so data
can transfer regardless of your device.
Versatile Tool for Use at Home, the Office or on the Go
The compact USB 3.1 memory card reader fits easily into your camera bag or laptop sleeve, so you can
access files at a moment’s notice. Its plug-and-play technology requires no new software, drivers or
external power supply. It’s compatible with all USB-enabled operating systems, including Windows and
Mac.
3-Year Warranty and Environmentally Responsible Design
The U452-000-SD-A comes with a 3-year warranty. It’s manufactured in compliance with strict RoHS
Applications
●
Transferring videos, images and
other data between an SD or
Micro SD memory card and your
MacBook, Chromebook, PC,
tablet, smartphone or laptop
●
Loading a PowerPoint file onto a
memory card at the office for
presenting on a different
computer on the road
●
Storing digital photographs for
later upload to your work
computer
System Requirements
●
MacBook, Chromebook, PC,
tablet, smartphone or laptop
with USB port (USB 3.0 port
required for maximum speeds)
●
Compatible with the following
memory cards:
●
SD Cards: Secure Digital (SD),
Elite Pro SD, Extreme III SD,
1 / 3
Page 2
specifications, reflecting Tripp Lite’s commitment to environmental responsibility.
Gaming Edition SD, Platinum II
SD, SD Pro, SDHC, SDXC, SDMax, SD-Pleomax, SD-Pro C,
Super SD, Turbo SD, Ultima I
SD, Ultima II SD, Ultimate SD,
Ultra High Speed SD, Ultra II
SD, Ultra II SD Plus, Ultra SD,
Ultra-X SD, DV-RS MMC, High
Speed MMC/RS-MMC,
MCCmobile, MMC Pro,
MMCplus, MMCplus Turbo, RSMMC
●
Micro SD Cards: MicroSD
(TransFlash), microSDHC
Package Includes
●
U452-000-SD-A USB-C Memory
Card Reader, 2-in-1 USBA/USB-C, USB 3.1 Gen 1
Specifications
INPUT
Cable Length (ft.) 0
Cable Length (m) 0
Bus Powered Yes
Product Length (in.) 3.00
Product Length (cm.) 7
Product Length (ft.) 0
Product Length (m.) 0
USER INTERFACE, ALERTS & CONTROLS
LED Indicators Blue (Power/Data)
PHYSICAL
Unit Packaging Type Box
Unit Dimensions (hwd / in.) 0.43 x 2.9 x 0.79
2 / 3
Page 3
Unit Weight (lbs.) 0.03
Unit Weight (kg) 0.01
Material of Construction ABS
Color Black
ENVIRONMENTAL
Operating Temperature Range 32 to 104 F (0 to 40 C)
Storage Temperature Range -4 to 140 F (-20 to 60 C)
Relative Humidity 0% to 80% RH, Non-Condensing
CONNECTIONS
Ports 4
Side A - Connector 1 USB 3.0 A (MALE)
Side A - Connector 2 USB C (MALE)
Side B - Connector 1 SD (FEMALE)
Side B - Connector 2 MICRO SD (FEMALE)
Connector Plating Nickel
Contact Plating Gold
FEATURES & SPECIFICATIONS
USB Specification USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps)
Driver Required No
CERTIFICATIONS
Certifications Tested to CE, FCC, RoHS, REACH, ICES
WARRANTY
Product Warranty Period
(Worldwide)
3-year limited warranty
