USB-C Multiport Adapter, VGA, USB-A Port, SelfStoring Cable and 100W PD 3.0, Black
MODEL NUMBER: U444-T6N-VUBC
USB-C to VGA adapter adds VGA, USB-A and USB-C Power Delivery ports to your laptop, MacBook or
other compatible device.
Highlights
●
Transmits video signals from
sources supporting USB-C
DisplayPort Alt Mode
●
Delivers HD picture quality at
resolutions up to 1920 x 1200
(1080p) @ 60 Hz
●
Power Delivery port provides 5A
(100W) power output for
charging connected device
●
USB-A & USB-C ports support
USB 3.1 Gen 1 speeds up to 5
Gbps for fast data transfers
●
Reversible USB-C plug
connects in either direction for
immediate no-fuss use
Features
USB 3.1 Type-C Adapter Connects a VGA Monitor to Your USB-C or Thunderbolt 3 DeviceThis USB
3.1 C adapter helps you transmit 1080p video from your tablet, laptop, Chromebook, MacBook,
smartphone or PC to a VGA-enabled television, monitor or projector. It’s an ideal tool for giving video
presentations in conference rooms and classrooms, editing multiple documents on a larger screen, or
streaming video for digital signage in crystal-clear 1080p.
Supports USB-C DisplayPort Alternate Mode for Transmitting Video SignalsBy connecting the selfstoring USB-C cable to a source device that supports USB DisplayPort Alt Mode, you can output video to
a compatible monitor, television or projector without installing special software drivers.
Transmits Crystal-Clear 1080p Video to a VGA DisplayTo send high-definition video to a VGA
television, projector or monitor, connect the VGA port to the display using a VGA cable (such as Tripp
Lite’s P502-Series VGA cables, sold separately). The USB to VGA adapter supports video resolutions up
to 1920 x 1200 (1080p) at 60 Hz.
Connects USB Peripherals and Transfers Data at Fast USB 3.1 Gen 1 SpeedsThe USB-A 3.0 port
accepts USB peripherals, such as a flash drive, mouse, keyboard or printer, and provides up to 1.5 amps
(7.5 watts) for charging and powering mobile devices. Like the USB-C port, it transfers data at speeds up
to 5 Gbps, which is 10 times faster than USB 2.0. The USB Type-C adapter is backward compatible with
previous USB generations, so you can continue using older peripherals while getting high-speed
performance from new devices.
PD Charging Port Charges Connected Device via AC Wall ChargerThe USB-C Power Delivery 3.0
port provides power output up to 5 amps (100 watts), which is more than sufficient for charging and
powering the connected source device, such as a MacBook or Chromebook. Just connect the device’s AC
wall charger to the USB-C PD port and enjoy fast USB 3.1 Gen 1 data transfer speeds up to 5 Gbps. Like
the USB-A port, it is backward compatible with previous USB generations.
Self-Storing USB-C Cable Connects in Either DirectionConnect the reversible USB-C plug to your
source device’s USB-C or Thunderbolt 3 port. The fumble-free USB-C plug connects in either direction to
ensure fast, easy connection every time. The six-inch cable wraps into the adapter when not in use,
making the unit easy to carry in a briefcase or laptop bag for connecting on the go.
Ready to Use Right Out of the PackageThe plug-and-play USB 3.1 Type-C adapter is specifically
designed for the MacBook, Google Chromebook Pixel and other laptops, tablets and devices equipped
with a USB-C or Thunderbolt 3 port. It requires no software, drivers or external power.
Applications
●
Play video from your MacBook
or Chromebook on a largescreen display
●
Give a video presentation at a
meeting, training session or
conference
●
Write and edit multiple
documents on a bigger monitor
●
Stream 1080p video for digital
signage at a trade show
●
Charge and power a USB-C or
Thunderbolt 3 device
●
Connect a USB peripheral, such
as an external hard drive, printer
or hub
System Requirements
●
Source device with USB-C or
Thunderbolt 3 output that
1 / 4
Specifications
OVERVIEW
UPC Code 037332232786
Product Type Multiport Adapter
Host Connector USB C (MALE)
supports USB DisplayPort
Alternate Mode
●
Display device with VGA input
Package Includes
●
U444-T6N-VUBC USB 3.1 C
Adapter with PD Charging,
Black
●
Owner’s manual
VIDEO
Extended Mode No
Mirror Mode No
Number of Monitors Supported 1
Resolutions Supported VGA: 1920 x 1200 60Hz
Video Ports HD15 (FEMALE)
DATA
Data Ports USB A (FEMALE); USB C (FEMALE)
Data Ports Detail USB-A - USB 3.2 Gen 1 (5 Gbps); USB-C - USB 3.2 Gen 1 (5 Gbps)
INPUT
Built-In Cable Length (in.) 6
Bus Powered Yes
Product Length (in.) 6
Product Length (cm.) 15.24
Product Length (ft.) 0.5
Product Length (m.) 0.15
2 / 4
BATTERY
Battery Charging (5V/1.5A Port) Yes
CHARGING
Charging Ports / Amps 1.5A; 5A
Charging Ports USB-C: 100W (20V 5A) Power Delivery (PD 3.0); USB-A: 5V 1.5A (7.5W)
USB Power Delivery (PD) Charging
Support
Yes
Total Charging Watts 100
USB Power Delivery (PD) Charging
Specification
3.0
PHYSICAL
Cable Jacket Rating VW-1
Color Black
Material of Construction ABS, TPE
Unit Packaging Type Box
ENVIRONMENTAL
Operating Temperature Range 32 TO 113 F (0 TO 45 C)
Storage Temperature Range 14 TO 158 F (-10 TO 70 C)
Operating Humidity Range 10% TO 85% RH, NON-CONDENSING
Storage Humidity Range 5% TO 90% RH, NON-CONDENSING
Power Provided to Connected
Device(s)
100W (20V 5A)
CONNECTIONS
Ports 3
Side A - Connector 1 USB C (MALE)
Side B - Connector 1 HD15 (FEMALE)
Side B - Connector 2 USB 3.0 A (FEMALE)
Side B - Connector 3 USB Type-C (FEMALE)
Connector Plating Nickel
FEATURES & SPECIFICATIONS
Max Supported Video Resolution DP/VGA: 1920 X 1200 (1080P) @ 60HZ
USB Specification USB 1.1 (up to 12 Mbps); USB 2.0 (up to 480 Mbps); USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps)
Driver Required No
3 / 4
Technology USB; USB 2.0 (High Speed); USB 3.0 (SuperSpeed); USB 3.1 (Gen 1); VGA/SVGA; PD Charging
STANDARDS & COMPLIANCE
Certifications Tested to RoHS, CE, FCC
WARRANTY
Product Warranty Period
(Worldwide)
3-year limited warranty
© 2020 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https:// products/product-certification-agencies
