Tripp-Lite U444-06N-H4UBC2 Data Sheet

USB-C Multiport Adapter - HDMI 4K @ 60 Hz, 4:4:4, HDR, USB-A, USB-C PD 3.0 Charging (100W), Black

MODEL NUMBER: U444-06N-H4UBC2

4K USB-C adapter adds HDMI, USB-A and USB-C PD charging ports to the USB-C or Thunderbolt 3 port on your MacBook or Chromebook.

Features

USB-C Adapter Turns Your USB-C or Thunderbolt 3 Device into a Multiport WorkstationThis 4K adapter turns the USB-C or Thunderbolt 3 port on your tablet, laptop, Chromebook, MacBook, smartphone or PC into multiple ports. It’s ideal for transmitting digital audio and 4K video to a large display, adding a thumb drive or other USB peripheral, and powering and charging a PD Chargingcompliant mobile device—all at the same time. It’s an ideal tool for working in high-definition photography, videography or cinematography, as well as streaming video for digital signage in crystal-clear 4K.

Supports USB DisplayPort Alternate Mode for Converting Audio/Video SignalsBy connecting the built-in USB-C cable to a source device that supports USB DisplayPort Alt Mode, you can output 4K video and digital audio to an HDMI monitor, television or projector without installing special software drivers.

Transmits Crystal-Clear 4K HDMI Video with HDR and 4:4:4 ColorThe U444-06N-H4UBC2 supports Ultra HD video resolutions up to 4K x 2K (4096 x 2160) at 60 Hz, as specified in HDMI 2.0. It is capable of carrying HDR signals, which provides a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks. HDCP 2.2 compliance allows you to stream iTunes and Netflix content with no complications. This adapter supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor.

Connects USB Peripherals and Transfers Data at Fast USB 3.1 Gen 1 SpeedsThe USB-A port accepts USB peripherals, such as a flash drive, mouse, keyboard or printer, and supports charging up to

5V 1.5A (7.5W) for mobile devices. It transfers data at speeds up to 5 Gbps, which is 10 times faster than USB 2.0.

PD 3.0 Charging Port Charges High-Powered Devices via AC Wall ChargerThe USB-C Power Delivery port provides power output up to 20V 5A (100W), which is more than sufficient for charging and powering the connected source device, such as a MacBook or Chromebook. Connect the port to the device’s AC wall charger. Like the USB-A port, the USB-C port also transfers data at USB 3.1 Gen 1 speeds up to 5 Gbps.

Built-In USB-C Cable Attaches in Either DirectionUnlike traditional USB cables that connect in only one direction, the reversible USB-C male connector plugs into a USB-C or Thunderbolt 3 port in either direction for a fumble-free connection every time.

Ready to Use Right Out of the PackageThe plug-and-play USB 3.1 Type-C adapter is specifically designed for the MacBook, Google Chromebook Pixel and other laptops, tablets and devices equipped with a USB-C or Thunderbolt 3 port. It requires no software, drivers or external power. About the size of a credit card, the U444-06N-H4UBC2 fits easily into a pocket, purse or laptop bag for convenient connections on the go.

Highlights

●Delivers UHD picture quality at resolutions up to 4K x 2K (4096 x 2160) @ 60 Hz, as specified in HDMI 2.0

●Converts audio/video signals from sources supporting USB DisplayPort Alt Mode

●USB-C PD 3.0 port provides 20V 5A (100W) power output for charging connected device

●USB-A port supports USB 3.1 Gen 1 speeds up to 5 Gbps for fast data transfers

●Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy

Applications

●Watch 4K video content from a Blu-ray player, game console, laptop or tablet on an Ultra HD television or projector

●Connect a Chromebook or MacBook to a conference table’s A/V box to give a video presentation on a large screen

●Edit HDR video or digital photos using a 4K monitor

●Charge and power a USB-C or Thunderbolt 3 device with its AC wall charger

●Connect a USB peripheral, such as an external hard drive, printer or hub

System Requirements

●Source device with USB-C or

Thunderbolt 3 port that supports

1 / 4

USB DisplayPort Alternate Mode (DP 1.4 required for 4K @ 60 Hz)

● Display device with HDMI input

Package Includes

● U444-06N-H4UBC2 USB-C

Multiport Adapter

● Owner’s manual

Specifications

OVERVIEW

UPC Code	037332251282
Product Type	Multiport Adapter
Host Connector	USB C (MALE)
VIDEO
Extended Mode	No
Mirror Mode	No
Number of Monitors Supported	1
Resolutions Supported	HDMI: 4K 60Hz (4096 x 2160)
Video Ports	HDMI (FEMALE)
Video Ports Detail	HDMI 2.0; HDCP 2.2
DATA
Data Ports	USB A (FEMALE); USB C (FEMALE)
Data Ports Detail	USB-A - USB 3.2 Gen 1 (5 Gbps); USB-C - USB 3.2 Gen 1 (5 Gbps)
INPUT
Built-In Cable Length (in.)	6
Built-In Cable Length (cm)	15.24
Bus Powered	Yes
USER INTERFACE, ALERTS & CONTROLS
LED Indicators	N/A

2 / 4
