Tripp-Lite U444-000-VGA Data Sheet

USB-C to VGA Vertical Adapter (M/F) - USB 3.1,
Gen 1, Thunderbolt 3, 1920 x 1200 (1080p), 5
Gbps, Black

MODEL NUMBER: U444-000-VGA

USB Type-C to VGA converter connects a VGA monitor to your tablet, phone, MacBook, Chromebook or
Ultrabook’s USB-C or Thunderbolt 3 port.

Features

USB Type-C to VGA Adapter Connects to Your Laptop or Tablet’s USB-C or Thunderbolt 3 PortThis

USB Type-C to VGA adapter connects a VGA monitor to the USB Type-C or Thunderbolt 3 port on your
computer, tablet, laptop, notebook, MacBook, Chromebook, Ultrabook or smartphone. It’s an ideal
connector for multitasking, presenting video at trade shows and conferences, editing documents, playing
online games and watching movies on a larger screen. It saves you money by allowing you to use your
existing VGA display instead of buying a new monitor.
Supports USB Type-C DisplayPort Alternate Mode for Converting Video SignalsBy connecting the
USB Type-C plug to a source device that supports USB DisplayPort Alt Mode, you can output 1080p
video to a VGA monitor, television or projector without the hassle of installing special software drivers.
Transmits Crystal-Clear 1080p Video to a VGA DisplayTo send high-definition video to a VGA
television, projector or monitor, connect the VGA port to the display using a VGA cable (such as Tripp
Lite’s P500-Series, sold separately). The VGA port supports HD video resolutions up to 1920 x 1200
(1080p) at 60 Hz.
Vertical Molding Prevents Blockage of Adjacent PortsThe USB Type-C input’s vertical orientation
results in a slimmer adapter that maximizes space around the device’s ports and prevents them from
being blocked. Unlike traditional USB cables that connect in only one direction, the reversible USB Type-C
male connector plugs into a USB Type-C or Thunderbolt 3 port in either direction for a fumble-free
connection every time.
Ready to Use Right from the Package, So You Can Plug and Play ImmediatelyThe plug-and-play
USB Type-C to VGA adapter is specifically designed for use with the MacBook, Google Chromebook Pixel
and other laptops, tablets and devices equipped with a USB Type-C or Thunderbolt 3 port. It requires no
software, drivers or external power. The palm-sized one-piece molding fits into your pocket, briefcase or
laptop bag for connecting to VGA displays anywhere.

Highlights

●

Vertical USB Type-C plug
orientation prevents adjacent
ports from being blocked

●

Converts video signals from
sources supporting USB Type-C
DisplayPort Alt Mode

●

Delivers HD picture quality at
resolutions up to 1920 x 1200
(1080p) @ 60 Hz

●

Reversible USB Type-C plug
connects in either direction for
immediate no-fuss use

●

Plug-and-play operation with no
software required for easy,
immediate installation

Applications

●

Connect your laptop to a VGA
monitor in a lecture hall or
conference room for a video
presentation

●

Add a secondary monitor to the
MacBook, Chromebook or
laptop in your office or home
workspace

●

Stream online video or games
from your computer on a larger
VGA display

System Requirements

●

Source device with USB Type-C
or Thunderbolt 3 port that
supports USB DisplayPort
Alternate Mode

●

Display device with VGA input

1 / 3

Package Includes

Specifications

OVERVIEW

UPC Code 037332238115

INPUT

Bus Powered Yes
Product Length (in.) 2.53
Product Length (cm.) 6.5

USER INTERFACE, ALERTS & CONTROLS

LED Indicators N/A

●

U444-000-VGA USB-C to VGA
Vertical Adapter, M/F, Black

●

Owner’s manual

CHARGING

USB Power Delivery (PD) Charging
Support

PHYSICAL

Color Black
Material of Construction PBT, ABS
Unit Dimensions (hwd / in.) 0.56 x 0.08 x 2.53
Unit Packaging Type Polybag
Unit Weight (kg) 0.01
Unit Weight (lbs.) 0.020

ENVIRONMENTAL

Operating Temperature Range 32 ~ 104F (0 ~ 40C)
Storage Temperature Range 5 ~ 122F (-15 ~ 50C)
Relative Humidity 0 ~ 85% RH, Non-Condensing

CONNECTIONS

Side A - Connector 1 USB C (MALE)

No

Side B - Connector 1 HD15 (FEMALE)
