USB-C to 3.5 mm Stereo Audio Adapter - USB
2.0, Silver
MODEL NUMBER: U437-002
Connects a microphone and stereo headphones to the USB-C or Thunderbolt 3 port on your smartphone,
MacBook, Chromebook or tablet.
Features
3.5 mm Audio Adapter Connects to Your Laptop’s USB-C or Thunderbolt 3 Port
This USB Type-C to Stereo Audio Adapter allows you to connect a microphone and stereo earbuds or
speakers to your computer, tablet, laptop, notebook, MacBook, Chromebook, Ultrabook or smartphone.
Not only does this adapter allow you to bypass a defective sound card or 3.5 mm headphone jack, it also
lets you connect to a device that offers only USB-C ports. The adapter features separate microphone (red)
and headphone (green) jacks, instead of combining them into a single 3.5 mm audio connector as many
notebooks do.
Built-In USB-C Cable Attaches in Either Direction
Unlike traditional USB cables that connect in only one direction, the reversible USB-C male connector
plugs into a USB-C or Thunderbolt 3 port in either direction for a fumble-free connection every time.
Ready to Use Right Out of the Package
The plug-and-play audio adapter requires no software, drivers or external power. The compact unit fits
easily into a pocket, briefcase or laptop bag for connecting on the go.
Highlights
●
Adds two 3.5 mm ports to a
device that comes with no more
than one stereo audio jack
●
Connecting to a USB-C port lets
you bypass a defective sound
card or audio jack
●
Compact aluminum housing fits
into a laptop bag for easy
listening anywhere
●
Reversible USB-C plug
connects in either direction for
immediate no-fuss use
●
Plug-and-play operation with no
software required for speedy
installation
Applications
●
Listen to streaming music or
sporting events through
headphones, earbuds or
speakers
●
Connect a microphone to chat
online via Skype or Facetime
●
Record a podcast on your
MacBook, Chromebook or other
notebook computer
System Requirements
●
PC, tablet, laptop, notebook,
MacBook, Chromebook,
Ultrabook or smartphone with
USB-C or Thunderbolt 3 port
●
Microphone, headphones,
earbuds and/or speakers with
3.5 mm plug
●
Windows or Mac operating
system
1 / 3
Package Includes
Specifications
OVERVIEW
UPC Code 037332213822
INPUT
Built-In Cable Length (ft.) 0.66
Built-In Cable Length (m) 0.2
Built-In Cable Length (in.) 7.87
Built-In Cable Length (cm) 20
Bus Powered Yes
Product Length (in.) 10.75
Product Length (cm.) 27.3
●
U437-002 USB-C to Stereo
Audio Adapter - USB 2.0, Silver
●
Quick Start Guide
Product Length (ft.) 0.9
Product Length (m.) 0.27
BATTERY
Battery Charging (1.2 Port) No
PHYSICAL
Unit Packaging Type Polybag
Unit Dimensions (hwd / in.) 0.51 x 1.10 x 1.81
Unit Dimensions (hwd / cm) 1.3 x 2.8 x 4.6
Unit Weight (lbs.) 0.082
Unit Weight (kg) 0.04
Material of Construction Aluminum
Color Silver
Cable Outer Diameter (OD) 4.4mm +/- 0.15mm
Cable Jacket Type PVC
ENVIRONMENTAL
Operating Temperature Range 32 ~ 158F (0 ~ 70C)
2 / 3
Storage Temperature Range -40 ~ 194F (-40 ~ 90C)
Relative Humidity 20 ~ 80% RH
CONNECTIONS
Side A - Connector 1 USB C (MALE)
Side B - Connector 1 (1) 3.5MM (FEMALE)
Side B - Connector 2 (1) 3.5MM (FEMALE)
FEATURES & SPECIFICATIONS
USB Specification USB 2.0 (up to 480 Mbps)
Audio Specification Stereo
Driver Required No
USB Power Delivery (PD) Charging
Support
Technology Stereo Audio; USB; USB 2.0 (High Speed)
CERTIFICATIONS
Certifications Tested to RoHS, REACH, FCC, CE
WARRANTY
Product Warranty Period
(Worldwide)
No
3-year limited warranty
