Tripp-Lite U236-MMF-LC Data Sheet
USB 2.0 Ethernet NIC Adapter - 10/100 Mbps,
100Base-FX, LC, Multimode Fiber, White
MODEL NUMBER: U236-MMF-LC
Connects your USB-enabled computer or laptop to a 10/100 Mbps fiber optic network without installing an
internal Ethernet card.
Highlights
●
Connects you to a wired
Ethernet network when Wi-Fi is
weak or unavailable
●
Provides 10/100 Mbps
throughput up to 2 km (1.2 mi.)
via multimode fiber cabling
●
Supports USB 2.0 speeds up to
480 Mbps to ensure efficient
data transfers
●
Hot-swappable interface lets
you install and uninstall without
shutting down computer
●
USB 2.0 Ethernet adapter
powered via USB, so no
external power supply is
required
Features
Connects Your USB Device to a Wired Ethernet Network without an Internet Card InstalledThis
USB to Ethernet adapter allows you to instantly connect your computer, laptop, tablet or other USBcompatible device to a wired 10/100 Mbps fiber optic network, even if your device has no NIC (Network
Interface Controller) installed. The adapter offers access to an Ethernet network when Wi-Fi is unavailable
or when a wired connection offers faster speeds. It transmits data up to 2 kilometers (1.2 miles) from your
fiber network using a 1310 nm wavelength.
Hot-Swappable for Installation Without Network InterruptionThis USB 2.0 Ethernet adapter is fully
hot-swappable, so you can install it without a potentially costly network shutdown or device reboot. Just
connect the built-in USB cable to your device’s USB port (which also powers the adapter), and wait for the
installation process to finish (you may have to reboot your computer). Then, connect the LC duplex port
using existing or newly run multimode fiber cable (such as Tripp Lite’s N820-Series, sold separately).
Delivers Full Ethernet Performance with Audio and Video StreamingThe compact USB to Ethernet
adapter supports full 10/100 Mbps network speeds and USB 2.0 speeds, allowing you to transfer data
efficiently and stream audio and video. The direct fiber connection minimizes the risk of data leaks and
electromagnetic interference (EMI). A blue LED indicates successful Ethernet connection and data
transfer. The adapter works with Windows operating systems and is backward compatible with USB 1.1
devices.
Applications
●
Install an LC duplex port on your
laptop or PC for the purpose of
connecting a multimode
Ethernet network cable
●
Upload data from your notebook
or download data from the
Ethernet at true 10/100 Mbps
speeds
●
Replace a malfunctioning
Ethernet card on your laptop or
computer
System Requirements
●
Computer or laptop with USB-A
port (USB 2.0 or USB 3.0)
●
Windows (through Win 10)
operating system
1 / 3
Package Includes
●
U236-MMF-LC USB 2.0
Specifications
OVERVIEW
UPC Code 037332248473
INPUT
Built-In Cable Length (m) 0.155
Built-In Cable Length (in.) 6.1
Bus Powered Yes
USER INTERFACE, ALERTS & CONTROLS
LED Indicators Blue (Power/Data)
PHYSICAL
Ethernet NIC Adapter
●
Driver CD
●
Quick Start Guide
Cable Jacket Rating VW-1
Color White
Material of Construction ABS, PVC
Unit Dimensions (hwd / in.) 0.71 x 2.2 x 1.61
Unit Packaging Type Box
Unit Weight (kg) 0.05
Unit Weight (lbs.) 0.12
ENVIRONMENTAL
Operating Temperature Range 32 to 131°F (0 to 55°C)
Storage Temperature Range 32 to 140°F (0 to 60°C)
Relative Humidity 5% to 90 % RH, Non-Condensing
COMMUNICATIONS
Network Speed 10/100 Mbps
CONNECTIONS
Side A - Connector 1 USB A (MALE)
Side B - Connector 1 LC DUPLEX (FEMALE); RJ45 (FEMALE)
2 / 3
