TRIPPLITE U040-C2M-C-5A Product Data Sheet

USB-C to USB-C Cable (M/M) - 2.0, 5A Rating,
USB-IF Certified, Thunderbolt 3 Compatible, 2 m

MODEL NUMBER: U040-C2M-C-5A

Provides up to 20V 5A (100W) for powering and charging your MacBook Pro or other mobile device
through a USB-C charger or power bank.

Features

USB-C to USB-C Cable Connects 2 USB-C Devices, Including MacBooks and Smartphones

This two-meter USB Type-C to Type-C cable allows you to connect one USB-C device to another. For
instance, a laptop to a docking station, your smartphone to a wall charger, or a hard drive or flash drive to
a computer or tablet. The USB-C to C cable is compatible with any device with a USB-C or Thunderbolt 3
port, including MacBooks, Ultrabooks and Chromebooks.

PD Charging Cable Produces up to 100W for Rapid Syncing and Charging

The Power Delivery cable provides power output up to 5 amps (100 watts), which is sufficient for fast­charging, syncing and powering most large-capacity devices, including the MacBook Pro. It also supports
USB 2.0 data transfer rates up to 480 Mbps. The USB Type-C to USB Type-C cable is backward
compatible with previous USB generations, allowing you to use it with older equipment.

Reversible USB-C Connectors Attach in Either Direction

Unlike traditional USB cables that connect in only one direction, the reversible USB-C male connectors
plug into a USB-C or Thunderbolt 3 port in either direction for a fumble-free connection every time.

USB-IF Certification Ensures Rigorous Testing and Top-of-the-Line Performance

This cable meets the high standards of USB-IF (USB Implementers Forum, Inc.), a non-profit organization
consisting of companies that developed the USB specification. Receiving USB-IF certification means the
U040-C2M-C-5A meets the industry’s highest environmental, mechanical and electrical standards. It
operates with your USB peripherals, adapters and cables with top efficiency and safety.

Highlights

●

Certified by USB-IF to ensure
highest-grade construction and
performance

●

Supports USB 2.0 speeds up to
480 Mbps to ensure efficient
data transfers

●

Power Delivery cable provides
5A (100W) for fast-charging
large-capacity devices

●

Reversible USB-C plugs
connect in either direction for
immediate no-fuss use

●

USB-C to USB-C cable is
compatible with all USB-C and
Thunderbolt 3 devices

Applications

●

Charge and sync a USB-C or
Thunderbolt 3 mobile device
from a USB-C wall charger up to
2 m away

●

Transfer data between an
external hard drive or flash drive
and your laptop or computer

●

Connect your laptop to a
docking station or hub with a
USB-C or Thunderbolt 3 port

System Requirements

●

Devices with USB-C or
Thunderbolt 3 ports

Specifications

1 / 3

Package Includes

●

U040-C2M-C-5A USB-C to
USB-C Cable, USB-IF, M/M, 2
m

OVERVIEW

UPC Code 037332241306

INPUT

Cable Length (ft.) 6.6
Cable Length (m) 2
Cable Length (in.) 78.7
Cable Length (cm) 200

PHYSICAL

Cable Jacket Rating VW-1
Cable Outer Diameter (OD) 4.0MM
Color Black
Material of Construction PVC
Unit Packaging Type Polybag
Wire Gauge (AWG) 30/23

ENVIRONMENTAL

Operating Temperature Range 14 TO 140 F (-10 TO 60 C)
Storage Temperature Range -4 TO 185 F (-20 TO 85 C)
Relative Humidity 10% to 85%, Non-Condensing

CONNECTIONS

Side A - Connector 1 USB Type-C (MALE)
Side B - Connector 1 USB Type-C (MALE)
Connector Plating Nickel
Contact Plating Gold

FEATURES & SPECIFICATIONS

USB Specification USB 2.0 (up to 480 Mbps)
Technology USB 2.0 (High Speed); USB

CERTIFICATIONS

Certifications Tested to CE, FCC, RoHS, REACH, USB-IF

WARRANTY

Product Warranty Period
(Worldwide)

3-year limited warranty

2 / 3
