Tripp Lite TLP76MSG User Manual

Eco-Surge 7-Outlet Surge Protector, 6 ft. (1.83 m)
Cord, 1080 Joules, Individually-Controlled

MODEL NUMBER: TLP76MSG

Description

Tripp Lite's TLP76MSG offers reliable, GREEN surge technology that protects your computer and
peripherals as well as the environment and your wallet. Energy-saving outlet configuration reduces energy
waste (phantom loads) by cutting AC power to unused peripherals. The TLP76MSG has one always on
outlet for those peripherals that need constant power like a fax machine, DVR or router. It also offer
convenient, individual outlet switches that allow users to select which device is turned on and off. The
TLP76MSG has 7 total outlets, 6-ft. (1.83 m) cord and diagnostic LEDs to warn of wiring problems and
suppressor damage. Network-grade AC suppression rated at 1080 joules shields equipment from surges
and line noise. Designed with an attractive cool gray suppressor housing, the TLP76MSG can
accommodate up to 4 transformer plug outlets offering convenient protection of desktop computer
equipment and accessories. $25,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only).

Highlights

●

Individual outlet control

●

1080 joules

●

7 outlet / 6-ft cord

●

Diagnostic LEDs

Package Includes

●

TLP76MSG ECO-SURGE
Home/Business Theater Surge
Suppressor

●

Instruction manual with warranty
information

Features

●

Energy-saving green outlets allow individual outlet control using illuminated power switches for cutting
power to peripherals not in use.

●

Six green outlets have their own illuminated ON/OFF switch for cutting power to peripherals when they
are not in use. One "Always On" outlet provides continuous power for devices such as DVRs (TiVo),
cable and satellite boxes, modems, routers and fax machines.

●

In addition to the individual illuminated outlet switches, an illuminated Master Switch controls power to
all outlets (except the Always On outlet) at once. It can override other "ON" settings to cut power to all
switched outlets at once.

●

Protected (Green) LED assures protection is present & Always On (Red) LED indicates that the Always
On outlet is receiving power.

●

1080 joules surge suppression rating with EMI/RFI line noise filtering help components perform at their
peak (sharper, crisper video; deeper, fuller audio and longer component life spans).

1 / 4

●

Automatic shutoff permanently cuts power to outlets if protection circuit is incapacitated, preventing
equipment damage and indicating replacement is required

Specifications

OVERVIEW

UPC Code 037332166074

INPUT

Nominal Input Voltage(s) Supported 120V AC
Recommended Electrical Service 120V (110-125V)
Input Cord Gauge Type 14 gauge; SJT
Voltage Compatibility (VAC) 120
Maximum Surge Amps 72000
Input Plug Type NEMA 5-15P
Input Cord Length (ft.) 6
Right-Angle Plug No
Input Cord Length (m) 1.83
Integrated Cord Clip No

OUTPUT

Output Volt Amp Capacity (VA) 120
Output Watt Capacity (Watts) 1800
Frequency Compatibility 60 Hz
Output (Watts) 1800
Output Receptacles (7) 5-15R
Transformer Accommodation (4) Yes
Right-Angle Outlets Yes
Individually Controllable Load Banks Yes

USER INTERFACE, ALERTS & CONTROLS

Diagnostic LED(s) Yes
Switches 1 x Lighted Master Switch & 6 x Lighted Receptacle Switches
LED Indicators Protected (Green)" & Always On Receptacle (Red)

SURGE / NOISE SUPPRESSION
