Tripp-Lite TLP366CUBEUSBB Data Sheet

Protect It! 3-Outlet Power Cube Surge Protector ­6 USB-A Ports (7.2A Shared), 6 ft. Cord, 540
Joules, Black

MODEL NUMBER: TLP366CUBEUSBB

Highlights

●

3 NEMA 5-15R outlets distribute
AC power to connected
home/office equipment

●

540 joules protect your valuable
electronics against dangerous
surges and spikes

●

6 USB-A ports provide charging
power for phones, tablets and
other mobile devices

●

6 ft. pivoting cord with right­angle NEMA 5-15P plug allows
flexibility in placing the cube

●

Green LED reassures you at a
glance that your connected
electronics are protected

Surge protector cube with removable USB charger safeguards your home/office electronics against
surges and provides fast USB charging.

Features

Compact Cube-Shaped 3-Outlet Surge Protector with USB Safeguards Your ElectronicsIdeal for

your home or office workstation, this Protect It!® three-outlet power cube features a surge protection
rating of 540 joules to defend your sensitive electronic components against strong power surges and
spikes. Because residential power outlets have three wires—hot line (H), neutral (N) and ground (G)—the
TLP366CUBEUSBB protects all three, covering the two protection modes: full normal mode (H-N) and
common mode (N-G/H-G). The three-inch cube is perfectly sized to fit inconspicuously into your
workspace or take with you to the office, dorm, hotel or conference room.
3 NEMA 5-15R Outlets Accept a Wide Range of Electronic DevicesThe power cube works as a
complete unit or can be split into two, so you can leave one portion at your desk and use the other for
travel. The bottom portion contains three NEMA 5-15R outlets for powering your PC, printer, wireless
router, game console, television or other home/office electronics. Each outlet is located apart from the
others to accommodate bulky power transformers.
6 USB-A Ports Keep Your Mobile Devices Charged to CapacityThe top portion features four USB
ports that share 4.8A for charging your smartphone, tablet and other USB mobile devices. The bottom
portion, in addition to three NEMA 5-15R outlets (see above), has two USB ports that share 2.4A. The
ability to charge up to six mobile devices at the same time makes the TLP366CUBEUSBB vital for busy
families. Plus, the ability to split the power cube into two separate units means you can take one with you
for instant charging on the road.
Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform BetterVarious
electromagnetic and radio sources found in virtually every home and business can cause disruptive
interference on the AC line. Known as EMI (electromagnetic interference) and RFI (radio frequency
interference), this line noise is a common cause of performance problems. This surge protector filters out
disruptive line noise that can disturb your electronics and inflict hardware damage or data loss. This
EMI/RFI filtering also helps your connected components perform better and last longer.
Includes the Latest Safety Features to Maintain Your Equipment’s Well-BeingAutomatic shutoff
permanently cuts power to outlets if the protection circuit is incapacitated, preventing equipment damage
and indicating replacement is required. A green LED confirms your connected equipment is protected.
Use the Power Cube as One Component or Split It into TwoThe removable top portion with four USB
ports includes a NEMA 1-15P plug, so you can take it on the road separately for charging mobile devices
at school, in the airport and at the hotel. The plug folds into the unit to shield it from damage and prevent it
from snagging or scratching your bag’s contents. The cube’s bottom portion has a six-foot pivoting power
cord and space-saving right-angle NEMA 5-15P plug, which helps you connect to a wall outlet located
behind furniture placed flush against the wall.

Applications

●

Protect computers, peripherals,
home theater equipment and
other valuable electronics
against AC power surges and
spikes

●

Charge smartphones, tablets or
other USB devices via USB
ports

Package Includes

●

TLP366CUBEUSBB Protect It!
3-Outlet Surge Protector Power
Cube, Black

●

Owner’s manual

1 / 4

Specifications

OVERVIEW

UPC Code 037332238528

INPUT

Nominal Input Voltage(s) Supported 120V AC
Recommended Electrical Service 120V
Voltage Compatibility (VAC) 120
Input Plug Type NEMA 5-15P
Input Cord Length (ft.) 6
Right-Angle Plug No
Input Cord Length (m) 1.83
Integrated Cord Clip No

OUTPUT

Frequency Compatibility 60 Hz
Output (Watts) 1800
Output Receptacles (3) 5-15R
Circuit Breaker (amps) 15
Transformer Accommodation No
Right-Angle Outlets No

USER INTERFACE, ALERTS & CONTROLS

Diagnostic LED(s) Yes

SURGE / NOISE SUPPRESSION

AC Suppression Joule Rating 540
AC Suppression Response Time < 1ns
Protection Modes Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
Clamping Voltage (RMS) 500
UL1449 Let Through Rating 500
EMI / RFI Filtering Yes
Immunity Conforms to IEE 587/ANSI C62.41
Automatic Shut-Off Yes
