Tripp Lite TLM1015NC User Manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +[phone]

E-mail: [e-mail]

Model #: TLM1015NC

Power It! Power Strip - Convenient multiple outlets for every application

Highlights

10 outlets spaced to accommodate transformers

Illuminated on/off switch with cover

15-amp circuit breaker

15 ft. power cord

Heavy-duty metal case

Keyhole slots on removable mounting brackets

Description

Tripp Lite's Power It! TLM1015NC power strip offers reliable, convenient and cost-effective power distribution for appliances, power tools, lighting

and other electrical equipment. Includes 10 NEMA 5-15R outlets spaced to accommodate transformers, 15-foot AC power cord and keyhole slots on

removable mounting brackets. Multi-outlet strip reduces cable clutter and enables the connection of multiple electrical devices to a single AC wall

socket. Features heavy-duty metal case to stand up to the most demanding environments, illuminated power switch with transparent cover to

prevent accidental shutoff and 15A integrated circuit breaker to prevent dangerous overloads. Lifetime warranty.

INPUT/OUTPUT: Input: NEMA 5-15P/Output: 10 NEMA 5-15R

ELECTRICAL: 120V AC, 50/60Hz, 15A

FORMAT: Corded power distribution strip

Applications

Offers a reliable, convenient and cost-effective method of power distribution for appliances, power tools, lighting and other electrical

equipment in home, office or worksite.

Unfiltered electrical pass-through makes the power strip ideal for distributing alternate waveform UPS or generator power to connected

equipment.

Package Includes

TLM1015NC power strip

Warranty information

Instruction manual

Features

Multi-outlet power strip offers reliable, convenient and cost-effective power distribution for appliances, power tools, lighting and other

electrical equipment

Includes 10 NEMA 5-15R outlets spaced to accommodate transformers

Illuminated on/off switch provides one-touch power control for connected equipment

Transparent switch cover snaps tight to prevent accidental shutoff

Convenient keyhole slots on removable brackets provide secure mounting options for a wide variety of surfaces and applications

15A power handling capacity with integrated circuit breaker

120V AC, 50/60Hz electrical compatibility

15-foot AC power cord

Heavy-duty metal case provides maximum safety and durability

UL certification

Lifetime warranty

Specifications

SYSTEM OVERVIEW

Voltage compatibility 120V AC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp capacity
(amps)

15A

Output watts 1800

Outlet quantity / type 10 NEMA 5-15R

Outlet orientation 10 outlets arranged in 2 rows and spaced to accommodate transformers

Overload protection 15A circuit breaker

Transformer accommodation Outlets spaced to accommodate transformers

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type SJT 14AWG

Input cord length (ft.) 15

Input cord length (m) 4.5

Recommended Electrical
Service

15A 120V

LEDS ALARMS & SWITCHES

Switches Illuminated on/off switch controls power to all outlets

Locking switch cover Transparent switch cover snaps tight to prevent accidental shutoff

PHYSICAL

Shipping weight (lbs) 5.2

Shipping weight (kg) 2.4

Shipping Dimensions
(HWD/in)

2.25 x 20.5 x 11

Shipping Dimensions
(HWD/cm)

5.7 x 52.1 x 28

Unit weight (lbs) 4.6

Unit weight (kg) 2.1

Unit Dimensions (HWD/in) 17.5 x 4 x 2.25

Unit Dimensions (HWD/cm) 44.5 x 10.2 x 5.7

Material of construction Metal case

Integrated keyhole mounting
tabs

Keyhole slots on removable brackets enable secure mounting to a variety of surfaces

Receptacle Color Light Gray

AC line cord color Light Gray

CERTIFICATIONS
