Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
Model #: SUPER7
7 outlet, 7-ft cord, 2160 joule strip - Protect It! Surge Suppressor
Highlights
7 outlets/7 ft. cord
2160 joule rating
$75,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)
Description
The SUPER7 Surge Suppressor from Tripp Lite has 7 outlets, a 7-ft. cord with a space-saving right-angle plug, and diagnostic LEDs. The unit has a
surge suppression rating of 2160 joules to handle the strongest surges. $75,000 Ultimate Lifetime Insurance (USA & Canada Only).
Applications
Personal computers, CAD/CAM/CAE workstations, network nodes, fileservers, point-of-sale terminals, audio/visual devices, and more.
Package Includes
Super 7 Surge Suppressor
Instruction manual with warranty information
Features
7 outlets
7-ft. cord with space-saving right-angle plug
Surge suppression rating: 2160 joules
EMI/RFI noise filtering
Can accommodate up to 3 transformers without blocking remaining outlets
$75,000 Ultimate Lifetime Insurance (USA and Canada Only) covers connected equipment
Diagnostic LEDs indicate protection present & ground present
Keyhole supports for wall mounting
Specifications
OVERVIEW
Intended Application Home/Office
OUTPUT
Frequency compatibility 50 / 60 Hz
Output watts 1800
Circuit Breaker (amps) 15
Outlet quantity / type 7 NEMA 5-15R
Transformer accommodation Supports 3 large transformer plug accessories without covering remaining outlets, accepts up to 5
transformers total
Outlet orientation Single row of 5, plus 2 side mounted outlets
INPUT
Nominal Input Voltage(s)
Supported
120V AC
Recommended Electrical
Service
120V (110-125V)
Input connection type NEMA 5-15P
Input cord length (ft.) 7
Input cord length (m) 2.1
Input cord gauge, type 14 gauge, SJT
Voltage compatibility (VAC) 120
Maximum Surge Amps 144000
LEDS ALARMS & SWITCHES
Switches Two position on/off power switch
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
SURGE / NOISE SUPPRESSION
AC suppression joule rating 2160
AC suppression response
time
< 1 ns
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping voltage (RMS) 150
UL1449 let through rating 330 L-G, 400 L-N, 400 N-G
EMI / RFI filtering Up to 20 dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection No
Cable (Coax) Protection No
Network (Ethernet)
Protection
No
PHYSICAL
Shipping weight (lbs) 1.56
Shipping weight (kg) 0.71
Unit Dimensions (HWD/in) 1.54 x 2.72 x 10.30
Unit Dimensions (HWD/cm) 3.91 x 6.91 x 26.16
Shipping Dimensions
(HWD/in)
12.40 x 5.90 x 1.77
Shipping Dimensions
(HWD/cm)
31.50 x 14.99 x 4.50
Unit weight (lbs) 1.39
Unit weight (kg) 0.63
Material of construction Plastic
Integrated keyhole
mounting tabs
Keyhole mounting tabs enable wall mounting
Housing Color cool gray
AC line cord color Gray
Style Strip
Outlets center to center
measurement
Between Standard Outlets = 29mm; Between Transformer Outlets = 48mm
Keyhole slot center to center
measurement
Distance Between Slots = 78mm; Distance Between Slot Height = 24mm
SPECIAL FEATURES
Right-Angle Plug Yes
CERTIFICATIONS
UL1449 3rd Edition (AC
Suppression)
UL1449 3RD EDITION
UL1363 (Power Tap) UL1363
cUL / CSA (Canada) cUL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$75,000 Ultimate Lifetime Insurance
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=131.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
