Tripp Lite SRSWITCH User Manual
WARRANTY
REGISTRATION:
register online today for a
chance to win a FREE Tripp Lite
product—www.tripplite.com/warranty
SmartRack™ Accessories
1 – Introduction 0
Owner’s Manual
Model: SRSWITCH
2
1-1 Parts List
1-2 Tools Required
2 – Important Safety Instructions
3 – SRSWITCH Installation
3-1 Mounting the Switch and Magnet to the Rack Enclosure
3-2 Wiring the Switch
4 – Connection to SNMPWEBCARD and ENVIROSENSE
5 – Warranty and Warranty Registration
2
2
2
3
3
3
4
4
1111 W. 35th Street, Chicago, IL 60609 USA
(773) 869-1234 • www.tripplite.com
Copyright © 2008 Tripp Lite. All rights reserved.
1 – Introduction
The SRSWITCH is designed to monitor rackmount enclosure door access and notify users when a door has been opened. The SRSWITCH must be used
together with the following Tripp Lite accessories: SNMPWEBCARD and ENVIROSENSE (both available separately).
1-1 Parts List
A1
Switch (1)
A2
Magnet (1)
A3
#22 AWG cable - 6 ft. (1.8 m) (1)
A4
Cable ties (6)
A5
Adhesive cable tie holders (3)
1-2 Tools Required
Wire Cutters
Wire Strippers
2 – Important Safety Instructions
A1
A4
A2
A5
A3
Screwdriver
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the installation and operation of the products
described in this manual. Read all instructions and warnings thoroughly before attempting installation. Failure to comply may
invalidate the warranty and cause property damage and/or personal injury.
Install in a controlled indoor environment, away from moisture, temperature extremes, ammable liquids and gasses, conductive contaminants, dust and •
direct sunlight.
Provide suitable grounding in accordance with all applicable electrical wiring regulations.•
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support •
equipment or to signicantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a ammable anesthetic
mixture with air, oxygen or nitrous oxide.
2
