Tripp Lite SRCOOL18K User Manual
Portable AC Unit for Server Rooms - 18,000 BTU, 208/240V
MODEL NUMBER: SRCOOL18K
Portable, self-contained 18,000 BTU server rack cooling system perfect for supplemental or backup cooling in server rooms and data centers, and as primary cooling in wiring closets and other IT environments without facility air conditioning.
Description
The SRCOOL18K SmartRack 18,000 BTU 208/240V Portable Rack Air Conditioner cools, dehumidifies and filters the air in your server room, data center or other environment with heat-sensitive equipment.
The compact, portable unit fits into just 4 square feet of floor space. It is designed for supplemental or backup cooling of IT equipment to prevent shutdowns, malfunctions and costly downtime caused by overheating or fluctuating temperatures.
The self-contained SRCOOL18K packs 18,000 BTU/h (5.275 kW) of cooling capacity into a rack-width chassis. A built-in evaporator expels condensation through a directional exhaust duct, eliminating the need for a floor drain or water collection tank. The SRCOOL18K also dehumidifies and filters the air, providing better air quality that can enhance equipment performance. Efficient close-coupled cooling reduces energy use and operating costs.
Installation is quick and easy and does not require disruptive construction or the costly expense of hiring a plumber or HVAC specialist. The SRCOOL18K rolls into place on durable built-in casters. The NEMA L620P plug connects to a standard 208/240V 20A outlet. The unit restarts automatically after power failures, and a built-in timer supports unattended shutdown and startup.
By installing the optional SRCOOLNET2LX network management card (sold separately), you can monitor temperatures, receive alerts, review logs, automate operation and control settings from anywhere via
SNMP, web browser, SSH or telnet. The SRCOOLNET2LX includes the ENVIROSENSE remote sensor, which lets you monitor temperature and humidity up to 12-ft. (3.66 m) away from the SRCOOL18K.
Features
Portable, High-Capacity Cooling PowerProduces 18,000 BTU/h (5.275 kW) of cooling capacity in a portable, rack-width chassisPrevents equipment shutdowns, malfunctions and failures caused by overheating and temperature fluctuationsFilters and dehumidifies air to enhance equipment performanceUses environmentally friendly R410A refrigerant, which complies with worldwide standardsEfficient close-coupled cooling reduces energy use and operating costs
Convenient OperationAdjustable louvers support area cooling applicationsFlexible output duct aims cold air where it's needed, such as an overheated rack enclosure or equipment hot spotSupports unattended shutdown and startup, including automatic restarts after power failuresEasy-to-read control panel with digital display and diagnostic LEDs for local managementSystem-lock function disables all other buttons to prevent accidental input
Advanced Network MonitoringOptional SRCOOLNET2LX accessory (sold separately) allows remote monitoring of temperatures, alerts, logs and control settings from anywhere via SNMP, web browser, SSH or telnetSRCOOLNET2LX includes ENVIROSENSE remote sensor, which monitors temperature and
Highlights
●18,000 BTU/h (5.275 kW) of cooling capacity in 2 x 2-ft. (0.61 m) footprint
●NEMA L6-20P plug connects to standard 208/240V 20A outlet
●Directs cooling through adjustable louvers or duct
●Restarts automatically after power failures
●Supports network management via optional SRCOOLNET2
Package Includes
●SRCOOL18K SmartRack Portable Server Rack Cooling Unit - 18,000 BTU, 208/240V
●(2) Gray exhaust ducts
●Black cooling duct
●(2) Exhaust duct adapters
●(2) Adjustable exhaust panels
●(4) Self-tapping screws
●Cooling duct adapter
●Louvered vent insert (preinstalled)
●(2) Drainage plugs (preinstalled)
●Owner’s manual
1 / 3
humidity up to 12-ft. (3.66 m) away
Easy to InstallRolls into place on built-in castersFits into 2 x 2-ft. (0.61 m) section of floor space6.5-ft. (1.98 m) power cord with NEMA L6-20P plug connects to standard 208/240V 20A AC outletNo external condenser, refrigerant piping or professional maintenance requiredBuilt-in evaporator expels condensation through exhaust tube—no floor drain or water collection tank neededExhaust kit removes hot air from room through drop ceiling, window or return ductIncludes all parts required for setup
Specifications
OVERVIEW
UPC Code |
037332188090 |
|
|
INPUT |
|
Nominal Input Voltage(s) Supported |
208V AC; 240V AC |
|
|
Electrical Consumption |
1985 Watts Max |
|
|
Input Connection Type |
NEMA L6-20P |
|
|
Input Frequency |
60 HZ |
|
|
Input Cord Length (ft.) |
6.56 |
|
|
Input Cord Length (m) |
2.00 |
|
|
COOLING |
|
Cooling Type |
Active |
|
|
Airflow |
Evaporator = 634 CFM / Condenser = 640 CFM |
|
|
Equivalent Room Size |
750 sq. ft. (70 sq. m) |
|
|
USER INTERFACE, ALERTS & CONTROLS |
|
Front Panel LEDs |
Touch sensitive control panel with multiple LEDs and numerical temperature readout |
|
|
PHYSICAL |
|
Color |
Black |
|
|
Form Factors Supported |
Tower |
|
|
Material of Construction |
ABS |
|
|
Shipping Dimensions (hwd / cm) |
117.35 x 65.02 x 75.69 |
|
|
Shipping Dimensions (hwd / in.) |
46.20 x 25.60 x 29.80 |
|
|
Shipping Weight (kg) |
92.99 |
|
|
Shipping Weight (lbs.) |
205.00 |
|
|
Unit Dimensions (hwd / cm) |
97.03 x 52.07 x 55.12 |
|
|
Unit Dimensions (hwd / in.) |
38.2 x 20.5 x 21.7 |
|
|
Unit Weight (kg) |
79.55 |
|
|
2 / 3
