Tripp Lite SR4POST13 User Manual

13U SmartRack 4-Post Open Frame Rack ­Organize and Secure Network Rack Equipment

MODEL NUMBER: SR4POST13

Description

Tripp Lite's 13U 4-Post Open Frame Rack helps IT managers organize their equipment array and provides
fast, easy access to installed IT equipment. The SR4POST13 is a simple solution for housing IT
equipment in secure environments and other areas that don't require a lockable rack solution. This 13U
rack features heavy-duty cold-rolled steel construction with a black powder-coated finish for durability. It
supports stationary loads up to 1000 lbs (453.6 kgs). The SR4POST13 comes with all the hardware
required for assembly and has a self-squaring design with bolt-down provisions. For high-density
applications, multiple units can be bolted together side by side.

Highlights

●

13U 4-post open frame rack

●

Black steel with square,
numbered mounting holes

●

Toolless button holes to accept
PDUs or cable managers

Package Includes

●

SR4POST13

●

Installation hardware

●

16x M6 cagenuts, screws,
washers

●

6x Cable management hooks

●

Owner's manual with warranty
information

The open design of the SR4POST13 provides unobstructed airflow and easy access to equipment and
cabling. It has numbered, square-hole mounting positions for easy installation of standard 19-inch rack
equipment. The SR4POST13 supports equipment depths from 22 to 36 inches. This rack also
accommodates toolless button-hole mounting for vertical PDUs and cable managers.

Features

●

Supports 1000 lbs (453.6 kgs) of rackmount equipment

●

Adjustable mounting depth (22 to 36 inches)

●

Textured powder coat finish

●

Heavy-duty cold-rolled steel construction

●

Numbered mounting positions

●

Bolt down provisions

●

Self squaring design

●

Black finish

●

Easy assembly

1 / 3

Specifications

OVERVIEW

UPC Code 037332144041
Device Compatibility Patch Panel; Network Switch; UPS; Server
Rack Type Open-Frame

PHYSICAL

Color Black
Maximum Device Depth (cm) 91.44
Maximum Device Depth (in.) 36
Maximum Device Depth (mm) 914
Minimum Device Depth (cm) 55.88
Minimum Device Depth (in.) 22
Minimum Device Depth (mm) 559
Rack Height 13U
Shipping Dimensions (hwd / cm) 16.51 x 11.51 x 141.00
Shipping Dimensions (hwd / in.) 6.50 x 4.53 x 55.51
Shipping Weight (kg) 19.69
Shipping Weight (lbs.) 43.40
Unit Dimensions (hwd / cm) 71.12 x 51.3 x 55.9~91.44 (depth adjustable)
Unit Dimensions (hwd / in.) 28 x 20.20 x 22-36
Unit Weight (kg) 17.69
Unit Weight (lbs.) 39
Weight Capacity - Stationary (kg) 454
Weight Capacity - Stationary (lbs.) 1000
Rack Depth Standard
Number of Vertical Mounting Rails 4

SPECIAL FEATURES

Grounding Lug Includes nuts, bolts, and washers to attach to user-supplied ground wire

STANDARDS & COMPLIANCE

Approvals EIA-310-D, IEC 60297-3-100, RoHS

WARRANTY
