Model #: SMART5000RT3U

SmartPro Expandable Rack/Tower UPS System - Line-interactive, sine wave power management system for
networks

Highlights

5000VA / 5kVA line interactive, extended-run 6U rack / tower UPS (3U Power

Module + 3U Battery Pack)

Maintains sine-wave 208V and simultaneous 120V nominal output during

brownouts to 151 and overvoltages to 260V

Network communications supported via 2 USB ports, 2 serial ports,

SNMP/Web card slot and EPO interface

Current monitoring and switched PDU control via 8 single-outlet load banks

Input: L6-30P (208V 30A) / Output: 1 L6-30R (208V), 1 L14-30R (208/120V

split phase), 2 NEMA 5-20R (120V), 10 NEMA 5-15R (120V)

2 year product warranty / $250,000 Ultimate Lifetime Insurance (USA, Puerto

Rico & Canada only)

Description

Tripp Lite's line-interactive SMART5000RT3U UPS System protects server, networking or telecommunications equipment from blackouts, voltage

fluctuations and surges in a compact tower/rackmount housing. In rack configuration, the power module and battery pack occupy only 3 rack spaces

(3U) each. Large capacity 5000VA/4000W power module converts raw 208V AC input to fully regulated dual output 208/120 voltage for simultaneous

protection of both high- and low-voltage equipment loads. True sine wave output at all times offers guaranteed compatibility with all equipment

types. Includes 14 outlets, 8 of which can be individually reset via software interface to selectively reboot remote equipment or shed less critical

loads to extend battery runtime for more critical equipment. Battery support can be extended indefinitely with additional external 3U rackmount

battery packs. Includes slot for internal SNMP/web card, plus two DB9 and two USB enhanced monitoring ports for unattended shutdown, remote

control and monitoring of UPS system and power data.

Applications

Ideal for centralized UPS protection of critical 208V and 120V equipment in server rooms, internetworking closets and telecommunications
systems in rackmount or tower applications. Common applications include any mix of servers, workstations, hubs, routers, concentrators,
IP telephony and traditional PBX switching system

Package Includes

SMART5000RT3U UPS System
BP48V60RT3U battery pack
PowerAlert Software and cabling
Mounting hardware
Instruction manual with warranty information

Features

Large 5000VA/4000W output capacity with full-time sine wave output offers guaranteed compatibility with all equipment types
High power density 5kVA power module and battery pack occupy only 3 rack spaces (3U) each (UPS and battery pack require 6U total
installed)
38 min. half load runtime, expandable with multiple external battery packs (part# BP48V60RT3U)

Line-interactive voltage regulation corrects severe brownouts and overvoltages without using battery power
Dual voltage output is simultaneously compatible with both 208V and 120V equipment
14 total outlets (120V: 10 x 5-15R, 2 x 5-20R/208V: 1 x L6-30R, 1 x L14-30R)
Diagnostic LEDs provide visual indication of 17 separate performance conditions
Included PowerAlert Software provides e-mail notification of power problems and simultaneous automatic unattended shutdown of multiple
servers
4 built-in communications ports (2 x DB9, 2 x USB) for remote monitoring and unattended shutdown
Slot for SNMP/web card SNMPWEBCARD and environmental sensor ENVIROSENSE for remote communications in large IP environments
8 customized load management receptacles can be individually powered off and back on again via software interface to reboot remote
equipment or perform "load shedding" of less critical loads to extend battery runtime for the most critical equipment
Emergency Power Off (EPO) interface for emergency shutoff in large facilities
Hot-swappable/user replaceable batteries allow on-site battery replacement through the front panel without powering off connected
equipment or removing the UPS from the rack
UPS battery set ships fully assembled and ready for connection to the power module, no time consuming, connection of individual internal
batteries by user is necessary
$250,000 Ultimate Lifetime Insurance (USA & Canada Only). No warranty cards required for coverage!
NAFTA compliant
2-year manufacturer's product warranty

Specifications

SYSTEM OVERVIEW

Voltage
compatibility

208V AC

Frequency
compatibility

60 Hz

OUTPUT

Output VA 5000

Output watts 4000

Output nominal
voltage

208/120V AC

Output voltage
regulation

LINE MODE: Sine wave line voltage 208V (-10% +20%) plus 120V nominal
BATTERY MODE: Sine wave output within +/-5% of 208V / 120V nominal

Output frequency
regulation

LINE MODE: Passes line frequency of 60Hz +/-10%
BATTERY MODE: Inverter output regulated to 60Hz +/-0.5Hz

Outlet quantity /
type

10 x NEMA 5-15R, 2 x NEMA 5-20R, 1 x NEMA L6-30R, 1 x NEMA L14-30R

Customized load
management
receptacles

"8 individually controllable outlets support load shedding and remote reboot on demand of locked network devices.
Controllable via PowerAlert software to switch off optional loads, like monitors, to increase available runtime for servers and
other critical devices. "

Overload
protection

Resettable circuit breaker (3 total, 15A each)

INPUT

Maximum input
amps

4560 watts

Input connection
type

NEMA L6-30P

Input cord length 10 ft., 10 gauge

Recommended
Electrical Service

30A 208V

BATTERY

Full load runtime 16 min. (5000VA), add 1 BP48V60RT3U for 38 min.

Half load runtime 38 min. (2500VA), add 1 BP48V60RT3U for 86 min.

Expandable
battery runtime

Supports extended runtime with optional external battery packs BP48V242U (limit 1) and BP48V60RT3U (multi-pack
compatible)
