Tripp Lite RV750ULHW User Manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +[phone]

E-mail: [e-mail]

Model #: RV750ULHW

PowerVerter RV Inverter/Charger - Quiet Mobile Power for RV, Camping & Boating Applications

Highlights

12V DC or 120V AC input; 120V AC output (hardwired)

750 watts continuous, 1125 watts OverPower and 1500 watts DoubleBoost

inverter output

3 stage, 11/45 amp selectable wet/dry cell battery charger

Built-in Isobar® premium AC surge protection and Auto Transfer Switching

option for battery backup / UPS operation

Tested to power inverter standards UL458 (USA) and CSA (Canada)

High reliability large-transformer design with protected DC and AC wiring

terminals

Description

Tripp Lite's RV750ULHW Inverter/Charger is the quiet alternative to gas generatorswith no fumes, fuel or noise to deal with! It provides equipment

with utility- or generator-supplied AC electricity filtered through premium ISOBAR surge protection. This DC-to-AC inverter with automatic

line-to-battery tranfser and integrated charging system serves as an extended run UPS, a standalone power source or an automative inverter

suitable for rugged RV applications. Supplies up to 750 watts of continuous 120V AC power from any 12V DC battery or automotive DC source.

OverPower TM inverter output feature temporariliy provides up to 150% of the continuous output for 1-60 minutes and DoubleBoost TM inverter

output feature delivers up to 200% of the continuous output for up to 10 seconds, providing the extra power needed to cold start heavy-duty tools

and motorized equipment. When hardwire AC input is energized, commercial power passes through to connected equipment and the battery set is

recharged via 3 stage, selectable 11/45 amp charging system. In UPS mode, the APS system responds to blackouts and voltage fluctuations with a

near instantaneous automatic transfer to battery-derived AC output. Includes a set of high current DC input terminals for simple installation (user

supplies batteries and cabling - see owner's manual for recommendations). Passes sine wave utilty or generator power during battery charging and

UPS line power operation, plus efficient PWM sine wave AC output in inverter and UPS backup modes. Reliable large transformer design, with

frequency control powers resistive electronic loads or large inductive motors, compressors and other items with high current needs on startup.

Optional APSRM4 wired remote power switch with full status LEDs provides remote power inverter on/off switching and continuous status

information (APSRM4 sold separately). Supports an unlimited amount of runtime with any number of user-supplied batteries connected. Highly

adaptable to a variety of applications and site conditions with adjustable charger settings for wet/gel battery types and selectable line to battery

power transfer voltages.

Applications

Versatile inverter/charger system with auto-transfer switching serves as an automotive inverter for RVs, over-the-road trucking, conversion

vans and fleet service vehicles; a standalone alternative power source for off-grid, alternative energy or export applications and as an

uninterruptible power supply (UPS) for items compatible with a 16.6 millisecond transfer time.

Package Includes

RV750ULHW Inverter/Charger

Instruction manual with warranty information

Features

RV750ULHW serves as an automotive or stationary DC-to-AC inverter with automatic line-to-battery transfer and integrated battery charger

Supports 120V AC output from a 120V AC line power source or 12V DC battery source

16.6 millisecond automatic transfer between line and battery power supports UPS protection during blackouts and voltage fluctuations for

equipment compatible with a one cycle transfer time

750 watts continuous AC output in inverter mode, 750 watts continuous AC output in AC mode

Double Boost inverter output supports momentary startup loads up to 200% of the continuous rating for up to 10 seconds

OverPower inverter output supports longer duration overloads to 150% for 1-60 minutes under ideal battery and temperature conditions.

(For best results, utilize OverPower usage for as short of a duration as possible, ensure battery bank and cabling is able to provide full

nominal DC voltage under load and allow inverter/charger to fully cool before and after OverPower usage.)

3 stage, selectable 11/45 amp battery charger with adjustable settings for wet/gel battery types offers fast, reliable battery recharging

Protected hardwire bolt-down input lugs safely accept heavy gauge input wiring from attached battery bank

Protected hardwire output passes 120V line power or inverter output through to connected equipment

Reliability enhanced large-transformer design tested to UL (USA) and CSA (Canada) standards

Moisture-resistant construction enables vehicular or marine operation in high humidity environments

3 position operating mode switch supports "AUTO" mode to enable automatic transfer between DC and AC modes, CHARGE-ONLY to

maintain a full battery charge when AC is present without auto transfer and SYSTEM OFF settings

Set of six front panel LEDs display AC/DC operational modes, overload status, DC voltage level, shutdown status and system fault status

Set of 4 configuration dipswitches support wet/gel battery charging profiles, adjustable 135/145V high voltage auto transfer during

overvoltages and selectable 75/85/95/105V AC low voltage auto transfer during brownouts

Set of 4 additional configuration dipswitches support 4 levels of charger limiting relative to output load size, a battery equalization program

and battery charger low/high/off settings

Resettable 10A charger AC input breaker and automatic 2 speed cooling fan protect the inverter from load and temperature related failures

Grounding lug properly connects the inverter/charger system to earth ground or vehicle grounding system

Automatic overload and thermal shutoff safely turns off inverter as excessive loads or overheating conditions develop

Front panel remote control connector enables remote off/on switching (requires APSRM4 switch accessory). Optional APSRM4 accessory

also includes user configurable jacks to support inverter shutoff or startup as a vehicle ignition is engaged

Load sensing control dial enables adjustable load threshold required to automatically turn the inverter on and off in DC mode as load

conditions change

Specifications

OVERVIEW

Intended Application RV/Marine

SYSTEM OVERVIEW

Voltage compatibility 12V DC / 120V AC

Frequency
compatibility

60 Hz

OUTPUT

Output watts 750W (continuous) / 1500W (peak)

Output nominal
voltage

120V

Output voltage
regulation

LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC):
Maintains PWM sine wave output voltage of 120 V AC (+/-5%).

Output frequency
regulation

60 Hz (+/- 0.3 Hz)

Outlet quantity / type Hardwire

Overload protection Includes 10A input breaker dedicated to the charging system

Continuous output
capacity (watts)

750

Peak output capacity
(watts)

1500

INPUT

Input connection
type

DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: hardwire

Input cord length DC INPUT: User supplies cabling. 6 gauge or larger (see manual). AC INPUT: hardwire
