Tripp Lite RV1012ULHW User Manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +[phone]

E-mail: [e-mail]

Model #: RV1012ULHW

PowerVerter RV Inverter/Charger - Quiet Mobile Power for RV, Camping & Boating Applications

Highlights

12V DC or 120V AC input; 120V AC output (hardwired)

1000 watts continuous, 1500 watts OverPower and 2000 watts

DoubleBoost inverter output

3 stage, 14/55 amp selectable wet/dry cell battery charger

Built-in Isobar® premium AC surge protection and Auto Transfer Switching

option for battery backup / UPS operation

Tested to power inverter standards UL458 (USA) and CSA (Canada)

High reliability large-transformer design with protected DC and AC wiring

terminals

Description

Tripp Lite's RV1012ULHW Inverter/Charger is the quiet alternative to gas generatorswith no fumes, fuel or noise to deal with! It provides equipment

with utility- or generator-supplied AC electricity filtered through premium ISOBAR surge protection. This DC-to-AC inverter with automatic

line-to-battery tranfser and integrated charging system serves as an extended run UPS, a standalone power source or an automative inverter

suitable for rugged RV applications. Supplies up to 1000 watts of continuous 120V AC power from any 12V DC battery or automotive DC source.

OverPower TM inverter output feature temporarily provides up to 150% of the continuous output for 1-60 minutes, and DoubleBoost TM inverter

output feature delivers up to 200% of the continuous output for up to 10 seconds, providing the extra power needed to cold start heavy-duty tools

and motorized equipment. When hardwire AC input is energized, commercial power passes through to connected equipment and the battery set is

recharged via 3 stage, selectable 14/55 amp charging system. In UPS mode, the APS system responds to blackouts and voltage fluctuations with a

near instantaneous automatic transfer to battery-derived AC output. Includes a set of high current DC input terminals for simple installation (user

supplies batteries and cabling - see owner's manual for recommendations). Passes sine wave utilty or generator power during battery charging and

UPS line power operation, plus efficient PWM sine wave AC output in inverter and UPS backup modes. Reliable large transformer design, with

frequency control powers resistive electronic loads or large inductive motors, compressors and other items with high current needs on startup.

Optional APSRM4 wired remote power switch with full status LEDs provides remote power inverter on/off switching and continuous status

information (APSRM4 sold separately). Supports an unlimited amount of runtime with any number of user-supplied batteries connected. Highly

adaptable to a variety of applications and site conditions with adjustable charger settings for wet/gel battery types and selectable line to battery

power transfer voltages.

Applications

Versatile inverter/charger system with auto-transfer switching serves as an automotive inverter for RVs, over-the-road trucking, conversion

vans and fleet service vehicles; a standalone alternative power source for off-grid, alternative energy or export applications and as an

uninterruptible power supply (UPS) for items compatible with a 16.6 millisecond transfer time.

Package Includes

RV1012ULHW Inverter/Charger

Instruction manual with warranty information

Features

RV1012ULHW serves as an automotive or stationary DC-to-AC inverter with automatic line-to-battery transfer and integrated battery charger

Supports 120V AC output from a 120V AC line power source or 12V DC battery source

16.6 millisecond automatic transfer between line and battery power supports UPS protection during blackouts and voltage fluctuations for

equipment compatible with a one cycle transfer time

1000 watts continuous AC output in inverter mode, 1440 watts continuous AC output in AC mode

Double Boost inverter output supports momentary startup loads up to 200% of the continuous rating for up to 10 seconds

OverPower inverter output supports longer duration overloads to 150% for 1-60 minutes under ideal battery and temperature conditions.

(For best results, utilize OverPower usage for as short of a duration as possible, ensure battery bank and cabling is able to provide full

nominal DC voltage under load and allow inverter/charger to fully cool before and after OverPower usage.)

3 stage, selectable 14/55 amp battery charger with adjustable settings for wet/gel battery types offers fast, reliable battery recharging

Protected hardwire bolt-down input lugs safely accept heavy gauge input wiring from attached battery bank

Protected hardwire output passes 120V line power or inverter output through to connected equipment

Reliability enhanced large-transformer design tested to UL (USA) and CSA (Canada) standards

Moisture-resistant construction enables vehicular or marine operation in high humidity environments

3 position operating mode switch supports "AUTO" mode to enable automatic transfer between DC and AC modes, CHARGE-ONLY to

maintain a full battery charge when AC is present without auto transfer and SYSTEM OFF settings

Set of six front panel LEDs display AC/DC operational modes, overload status, DC voltage level, shutdown status and system fault status

Set of 4 configuration dipswitches support wet/gel battery charging profiles, adjustable 135/145V high voltage auto transfer during

overvoltages and selectable 75/85/95/105V AC low voltage auto transfer during brownouts

Set of 4 additional configuration dipswitches support 4 levels of charger limiting relative to output load size, a battery equalization program

and battery charger low/high settings

Resettable 12A charger AC input breaker and resettable 12A AC output breaker and automatic 2 speed cooling fan protect the inverter from

load and temperature related failures

Grounding lug properly connects the inverter/charger system to earth ground or vehicle grounding system

Automatic overload and thermal shutoff safely turns off inverter as excessive loads or overheating conditions develop

Front panel remote control connector enables remote off/on switching (requires APSRM4 switch accessory). Optional APSRM4 accessory

also includes user configurable jacks to support inverter shutoff or startup as a vehicle ignition is engaged

Load sensing control dial enables adjustable load threshold required to automatically turn the inverter on and off in DC mode as load

conditions change

Includes battery temperature sensor with 20 foot cable to prolong battery life by adjusting the charge level based on battery temperature

Automatic Generator Starter jack enables user configuration of automatic generator startup as inverter batteries drop to 11.5VDC and

generator shutoff as inverter batteries are recharged to 14.1VDC

Specifications

OVERVIEW

Intended
Application

RV/Marine

SYSTEM OVERVIEW

Voltage
compatibility

12V DC / 120V AC

Frequency
compatibility

60 Hz

OUTPUT

Output watts 1000W (continuous) / 2000W (peak)

Output nominal
voltage

120V

Output voltage
regulation

LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC):
Maintains PWM sine wave output voltage of 120 V AC (+/-5%).

Output frequency
regulation

60 Hz (+/- 0.3 Hz)

Outlet quantity /
type

Hardwire

Overload
protection

Includes 12A input breaker dedicated to the charging system and 12A output breaker for AC output loads

Continuous output
capacity (watts)

1000
