1. Important Safety Instructions
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the
installation of the product described in this manual. Read ALL instructions before
attempting to install this product. Failure to comply may invalidate any warranty
and cause serious property damage and/or personal injury.
2. Parts and Features
The PSCLAMP mounting kit includes:
• 2 Clamps
• 2 Cord Wraps
• 1 Drip Shield
• 5 Screws
• (3) M4 6 mm Pan Head Machine
Screws with Lockwashers for Power
Strip and Drip Shield
• (2) M6 12 mm Socket Head Cap
Screws for Cord Wraps
Clamps
The PSCLAMP is designed to be used
with Tripp Lite’s Medical-Grade Power
Strips. To accommodate a wide variety
of applications, the clamps include
small-tube adapters
that allow them
A
Cord Wraps Drip Shield
to t tubes from ¾” up to 2 ¼”.
The clamps also include lock nuts
that can be tightened depending on
mounting location and equipment.
• For units meeting UL1363a
B
M6 12 mm Socket Head
Cap Screws
M4 6 mm Pan Head
Machine Screws with
Lockwashers
standards, the lock nuts MUST be
tightened and secure when mounting
on mobile cart, IV pole or other
certied usages.
Tripp Lite Models: PS-410-HGOEMCC,
PS-415-HG-OEM and
PS-615-HG-OEM.
• For units meeting UL 60601-1
standards, the lock nuts MAY be
tightened to user preference.
Tripp Lite Models: PS-415-HGULTRA
A
B
and SPS415HGULTRA.
2
201205001_M-93-3155.indb 2 5/4/2012 10:05:35 AM
3. Installation
Before beginning installation, verify that all necessary package contents are present
and that the power strip to be mounted conforms to the standards necessitated by
its mounting location.
1
Secure clamps
end of the power strip
of the M4 screws provided.
Note: If attaching drip shield in next step,
mount power strip with power cord down
according to the diagram.
2
Depending on your application and
mounting location, you may wish to
attach the drip shield
clamp. Secure the drip shield using
one M4 screw. To ensure proper t,
the top edge of the drip shield will
rest on top of the clamp.
Note: Attaching the drip shield is optional.
loosely to each
A
using two
B
to the top
C
A
B
1
C
2
3
Attach the cord wraps
D
to the
clamps using the provided M6
screws. Make sure that the arms
face away from the power strip.
D
3
3
201205001_M-93-3155.indb 3 5/4/2012 10:05:37 AM
