Tripp Lite PS7224 Product Description
PS7224
24 outlets 15 ft. cord
DESCRIPTION
outlet AC power distribution in a convenient 72 inch mountable housing. Offers
15R output receptacles with
center spacing, 15 ft AC line cord and lighted power switch with locking transparent cover to prevent accidental shutoff.
KEY BUYING POINTS
TYPICAL APPLICATIONS
PACKAGE INCLUDES
COMPLETE SPECIFICATIONS
Convenient and safe covered, on/off switch 72" length
15-amp circuit breaker
Tripp Lite's PS7224 power strip offers 15 amp, 120V multihorizontal or vertical power distribution in rackmount, raceway and workbench applications. Includes 24 NEMA 5-
2.795 inch center-toSturdy all-metal extruded aluminum housing stands up to demanding network, laboratory or factory environments.
INPUT / OUTPUT: Input: NEMA 5-15P / Output: 24 NEMA 5-15R
ELECTRICAL: 120V AC, 50/60Hz, 15A
FORMAT: 72 in. corded, mountable power strip
Sturdy all-metal 72 inch corded strip format with 2.795 inch center-to-center outlet spacing
Included mounting hardware supports vertical or horizontal mounting in rack enclosures, raceways and more
Includes 24 NEMA 5-15R output receptacles
Ideal for horizontal or vertical raceway style power distribution in office, workbench, industrial, networking and telecom applications
Lighted power switch with locking transparent cover prevents accidental shutoff
15 amp electrical capacity with circuit breaker
120VAC, 50/60Hz electrical compatibility
Lifetime warranty
Offers vertical or horizontal multi-outlet power distribution in rack enclosures, raceways, desktops and more.
PS7224
Mounting hardware
Instruction manual
SYSTEM OVERVIEW
System overview: 6 ft. vertical power strip, includes mounting clips
Voltage compatibility: 120VAC
Frequency compatibility: 50/60 Hz
OUTPUT
Output volt amp capacity (amps): 15A
Output watt capacity (watts): 1800
Outlet quantity / type: 24 Nema 5-15R
Outlet spacing: 2.795 in.
INPUT
Input connection type: Nema 5-15P
Input cord length (ft.): 15
Input cord length (m): 4.572
Input plug features: Black
Input cord gauge, type: 14/3 SJT
Recommended electrical service: 15A 120V
LEDS ALARMS & SWITCHES
Switches: Lighted 2 position switch controls power to all outlets
Locking switch cover: Transparent on/off switch cover prevents accidental turn-off
PHYSICAL
Unit weight (lbs): 5.5
Unit weight (kg): 2.497
Unit Dimensions (HWD/in): 1.5 x 1.5 x 72 in.
Unit Dimensions (HWD/cm): 3.8 x 3.8 x 183
Material of construction: Aluminum
Form factors supported: Supports vertical or horizontal mounting in rack enclosures, raceways and a variety of other
applications
Mounting accessories included: Includes mounting clips
Housing color: Silver
Receptacle color: Black
AC line cord color: Black
CERTIFICATIONS
UL1363 (Power Tap): UL1363
cUL / CSA (Canada): cUL
WARRANTY
Product warranty: Lifetime
