Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: TLM406NC
Power It! Power Strip with 4 Outlets and 6-ft. Cord
Highlights
4 outlets
Illuminated on/off switch with cover
15-amp circuit breaker
6 ft. power cord
Rugged metal case
Keyhole mounting slots
Description
Tripp Lite's Power It! TLM406NC power strip offers reliable, convenient and cost-effective power distribution for appliances, power tools, lighting and
other electrical equipment. Includes 4 NEMA 5-15R outlets, 6-foot AC power cord and keyhole mounting slots. Multi-outlet strip reduces cable clutter
and enables the connection of multiple electrical devices to a single AC wall socket. Features rugged metal case to stand up to the most demanding
environments, illuminated power switch with transparent cover to prevent accidental shutoff and 15A integrated circuit breaker to prevent dangerous
overloads.
INPUT/OUTPUT: Input: NEMA 5-15P/Output: 4 NEMA 5-15R
ELECTRICAL: 120V AC, 50/60Hz, 15A
FORMAT: Corded power distribution strip
Applications
Offers a reliable, convenient and cost-effective method of power distribution for appliances, power tools, lighting and other electrical
equipment in home, office or worksite.
Unfiltered electrical pass-through makes the power strip ideal for distributing alternate waveform UPS or generator power to connected
equipment.
Package Includes
TLM406NC power strip
Warranty information
Instruction manual
Features
Multi-outlet power strip offers reliable, convenient and cost-effective power distribution for appliances, power tools, lighting and other
electrical equipment
Includes 4 NEMA 5-15R outlets
Illuminated on/off switch provides one-touch power control for connected equipment
Transparent switch cover snaps tight to prevent accidental shutoff
Convenient keyhole slots provide secure mounting options for a wide variety of surfaces and applications
Page 2
15A power handling capacity with integrated circuit breaker
120V AC, 50/60Hz electrical compatibility
6-foot AC power cord
Rugged metal case provides extra safety and durability
UL certification
Specifications
OUTPUT
Frequency compatibility 50 / 60 Hz
Output watts 1800
Circuit Breaker (amps) 15
Overload protection 15A circuit breaker
Outlet quantity / type 4 NEMA 5-15R
Outlet orientation Single row of 4
INPUT
Recommended Electrical
Service
15A 120V
Input connection type NEMA 5-15P
Input cord length (ft.) 6
Input cord length (m) 1.8
Input cord gauge, type SJT 14AWG
Voltage compatibility (VAC) 120
LEDS ALARMS & SWITCHES
Switches Illuminated on/off switch controls power to all outlets
Locking switch cover Transparent switch cover snaps tight to prevent accidental shutoff
PHYSICAL
Shipping weight (lbs) 1.6
Shipping weight (kg) .7
Unit Dimensions (HWD/in) 8.75 x 2.5 x 2
Unit Dimensions (HWD/cm) 22.2 x 6.4 x 5.1
Shipping Dimensions
(HWD/in)
10 x 5.5 x 2.25
Shipping Dimensions
(HWD/cm)
25.4 x 14 x 5.7
Unit weight (lbs) 1.4
Unit weight (kg) .6
Material of construction Metal case
Integrated keyhole mounting
tabs
Keyhole slots enable mounting to a variety of surfaces
Receptacle Color Light Gray
Page 3
AC line cord color Light Gray
Outlets center to center
measurement
30mm
Keyhole slot center to center
measurement
Distance between keyhole tabs = 127mm; Distance between end tabs = 207.45mm
CERTIFICATIONS
Additional International
Approvals
Complies with RoHS (Restriction of Hazardous Substances Directive)
UL1363 (Power Tap) UL1363
cUL / CSA (Canada) cUL
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3464.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
