Tripp-Lite P582-003-V2-ACT Data Sheet

DisplayPort 1.2 to HDMI Active Adapter Cable,
DP with Latches to HDMI (M/M), UHD 4K, 3 ft.

MODEL NUMBER: P582-003-V2-ACT

Converts a DisplayPort v1.2 audio/video signal for display on an HDMI monitor, projector or television.

Description

The P582-003-V2-ACT DisplayPort 1.2 to HDMI Active Adapter Cable connects a DisplayPort computer to
the HDMI port on a monitor, projector or television. With a latching DisplayPort male connector on one
end and an HDMI male connector on the other, this cable requires no separate adapter. It lets you use
your existing HDMI display instead of buying a new DisplayPort monitor.

Highlights

●

Active adapter cable for use with
any DisplayPort

●

Supports UHD video resolutions
up to 3840 x 2160 (4K x 2K) @
24/25/30Hz

●

Supports audio and HDCP

●

No separate adapter required

●

Gold-plated connectors and
contacts

Package Includes

●

P582-003-V2-ACT DisplayPort

1.2 to HDMI Active Adapter
Cable, 3 ft.

Ideal for displaying crystal-clear video on a large monitor or digital sign, this cable supports Ultra High
Definition (UHD) video resolutions up to 3840 x 2160 (4K x 2K) @ 24/25/30Hz, as well as rich, full audio (if
your DisplayPort card supports audio passthrough) and HDCP (High-Definition Content Protection).
Because it’s an active adapter, the P582-003-V2-ACT converts both Single-Mode and Dual-Mode (DP++)
DisplayPort output. It’s perfect for use with graphics cards, such as AMD Eyefinity, that do not output
DP++ signals.

Gold-plated connectors and contacts ensure excellent conductivity. The DisplayPort plug latches to the
port to provide a secure connection. Integral strain relief ensures the cable and molded connectors last a
long time.

Features

Send High-Quality DisplayPort v1.2 Audio/Video Signals to an HDMI Display

●

Connects DisplayPort computer to HDMI-enabled monitor, projector or TV

●

Ideal for displaying video on large monitor or digital sign

●

HDMI and latching DisplayPort male connectors

●

No separate adapter required

Vibrant, Superior Video Quality

1 / 3

●

Supports UHD video resolutions up to 3840 x 2160 (4K x 2K) @ 24/25/30Hz

●

Supports audio and HDCP

●

Active adapter converts Single-Mode and Dual-Mode (DP++) DisplayPort output

●

Perfect for use with graphics cards, such as AMD Eyefinity, that do not output DP++ signals

Superior Materials for Superior Performance

●

Gold-plated connectors and contacts for excellent conductivity

●

Latching DisplayPort plug for secure connection

●

Integral strain relief for long life

Specifications

OVERVIEW

UPC Code 037332192059

INPUT

Cable Length (ft.) 3
Cable Length (m) 0.9

PHYSICAL

Color Black
Shipping Dimensions (hwd / cm) 22.86 x 17.78 x 1.27
Shipping Dimensions (hwd / in.) 9.00 x 7.00 x 0.50
Shipping Weight (kg) 0.09
Shipping Weight (lbs.) 0.19

CONNECTIONS

Side A - Connector 1 DISPLAYPORT (MALE)
Side B - Connector 1 HDMI (MALE)

FEATURES & SPECIFICATIONS

Technology HDMI; DisplayPort

WARRANTY

Product Warranty Period
(Worldwide)

3-year limited warranty
