Tripp-Lite P581-010-VGA-V2 Data Sheet
DisplayPort 1.2 to VGA Active Adapter Cable, DP
with Latches to HD15 (M/M), 10 ft.
MODEL NUMBER: P581-010-VGA-V2
Converts a DisplayPort v1.2 video signal for display on a VGA monitor, projector or television.
Description
The P581-010-VGA-V2 DisplayPort 1.2 to VGA Active Adapter Cable with inline signal converter connects
a DisplayPort computer to the VGA port on a monitor, projector or television. With a latching DisplayPort
male connector on one end and an HD15 male connector on the other, this cable requires no separate
adapter. It features a low profile VGA connector that fits neatly into the available monitor space, without
jamming between the wall and the back of the display or impeding neighboring connectors. It lets you use
your existing VGA display instead of buying a new DisplayPort monitor.
Ideal for displaying video on a large monitor or digital sign, this cable supports computer video resolutions
up to 1920 x 1200 and high-definition video resolutions up to 1920 x 1080 (1080p). It converts both
Single-Mode and Dual-Mode (DP++) DisplayPort output, and is perfect for use with graphics cards, such
as AMD Eyefinity, that do not output DP++ signals.
First-class foil and braid shielding delivers reliable, error-free signal quality and protection from EMI/RFI
interference. Nickel-plated connectors with gold-plated contacts ensure excellent conductivity. The
DisplayPort plug latches to the port to provide a secure connection. Integral strain relief ensures the cable
and molded connectors last a long time.
Highlights
●
Active adapter cable for use with
any Displayport port
●
Low-profile VGA connector fits
neatly into available space; no
jamming between wall and
monitor or impeding neighboring
connections
●
Supports computer video
resolutions up to 1920 x 1200
●
Supports HD video resolutions
up to 1920 x 1080 (1080p)
●
No separate adapter required
●
Nickel-plated connectors with
gold-plated contacts
Package Includes
●
P581-010-VGA-V2 DisplayPort
1.2 to VGA Active Adapter
Cable, 10 ft.
Features
Send High-Quality DisplayPort v1.2 Video Signals to a VGA Display
●
Connects DisplayPort computer to VGA-enabled monitor, projector or TV
●
Ideal for displaying video on large monitor or digital sign
●
Low-profile VGA connector fits neatly into available space; no jamming between wall and monitor or
impeding neighboring connections
●
HD15 and latching DisplayPort male connectors
●
No separate adapter required
Vibrant, Superior Video Quality
●
Supports computer video resolutions up to 1920 x 1200
●
Supports HD video resolutions up to 1920 x 1080 (1080p)
●
Converts Single-Mode and Dual-Mode (DP++) DisplayPort output
●
Perfect for use with graphics cards, such as AMD Eyefinity, that do not output DP++ signals
Superior Materials for Superior Performance
●
Double shielding with foil and braid for maximum EMI/RFI protection
●
Nickel-plated connectors with gold-plated contacts for excellent conductivity
●
Latching DisplayPort plug for secure connection
1 / 2
●
Integral strain relief for long life
Specifications
OVERVIEW
UPC Code 037332191946
INPUT
Cable Length (ft.) 10
Cable Length (m) 3.1
PHYSICAL
Color Black
Shipping Dimensions (hwd / cm) 25.40 x 20.32 x 1.27
Shipping Dimensions (hwd / in.) 10.00 x 8.00 x 0.50
Shipping Weight (kg) 0.20
Shipping Weight (lbs.) 0.44
CONNECTIONS
Side A - Connector 1 DISPLAYPORT (MALE)
Side B - Connector 1 HD15 (MALE)
FEATURES & SPECIFICATIONS
Technology VGA/SVGA; DisplayPort
WARRANTY
Product Warranty Period
(Worldwide)
3-year limited warranty
© 2020 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https:// products/product-certification-agencies
2 / 2
