Tripp-Lite P581-003-VGA Data Sheet
DisplayPort to Active VGA Cable, DisplayPort
with Latches to HD15 Adapter (M/M), 3 ft.
MODEL NUMBER: P581-003-VGA
Connects a VGA monitor to a computer with Displayport using a single cable
Description
Tripp Lite's P581-003-VGA allows you to connect a desktop or laptop computer with a Displayport port to
a VGA monitor. All in one 3-ft. cable design requires no additional adapters or software....plug-and-play.
Supports computer video resolutions up to 1920 x 1200, and HD video resolutions up to 1920 x 1080
(1080p). Unlike passive adapters, Active adapters convert both Single-Mode and Dual Mode (DP++)
Displayport output. It is ideal for use with graphics cards, such as AMD Eyefinity, that do not output Dual
Mode (DP++) signals.
Features
●
3-ft. Displayport Male to VGA Male cable
●
Supports computer video resolutions up to 1920 x 1200, and HD video resolutions up to 1920 x 1080
(1080p)
●
Ideal for use with graphics cards, such as AMD Eyefinity, that do not output Dual Mode (DP++) signals
●
Converts both Single-Mode and Dual Mode (DP++) Displayport output
Highlights
●
Connect a Displayport computer
port to a VGA monitor
●
Supports computer video
resolutions up to 1920 x 1200,
and HD video resolutions up to
1920 x 1080 (1080p)
●
Ideal for use with graphics
cards, such as AMD Eyefinity,
that do not output Dual Mode
(DP++) signals
●
Converts both Single-Mode and
Dual Mode (DP++) Displayport
output
System Requirements
●
VGA Monitor
●
Computer with Displayport
●
Not for use with MST Hubs. For
compatibility with MST Hubs,
use a Displayport 1.2 compliant
product such as P581-003-VGAV2
Package Includes
●
3-ft. Displayport to Active VGA
Cable, M/M
Specifications
OVERVIEW
UPC Code 037332186201
INPUT
Cable Length (ft.) 3
1 / 2
Cable Length (m) 0.9
PHYSICAL
Color Black
Shipping Dimensions (hwd / cm) 22.86 x 17.78 x 1.27
Shipping Dimensions (hwd / in.) 9.00 x 7.00 x 0.50
Shipping Weight (kg) 0.06
Shipping Weight (lbs.) 0.14
CONNECTIONS
Side A - Connector 1 DISPLAYPORT (MALE)
Side B - Connector 1 HD15 (MALE)
FEATURES & SPECIFICATIONS
Technology VGA/SVGA; DisplayPort
WARRANTY
Product Warranty Period
(Worldwide)
3-year limited warranty
