Tripp-Lite P580-030 Data Sheet

DisplayPort Cable with Latches (M/M) 30 ft.

MODEL NUMBER: P580-030

Description

DisplayPort is a digital display interface standard put forth by the Video Electronics Standards Association
(VESA). It defines a digital audio/video interconnect intended to be used between computer and display
monitors, or computers and home theater systems. Similar to HDMI, in that it supports both Digital
Video/Audio signals, DisplayPort is geared more toward the computer market, where HDMI dominates the
Home Theater market. Tripp Lite's DisplayPort cables support a maximum bandwidth of 10.8Gbps, as well
as DPCP ( DisplayPort Content Protection), and HDCP.

Highlights

●

Digital Video and Audio in one
cable

●

Supports Displayport v1.2

●

Monitor Resolution Support:
2560x1600 @ 60Hz, 1920x1200
@ 120Hz

●

Small footprint compared to
VGA or DVI

Package Includes

DisplayPort Monitor Cable - 30-ft

Features

●

The future standard for Digital Video and Audio connections

●

Supports Displayport v1.2

●

Monitor Resolution Support: 2560x1600 @ 60Hz, 1920x1200 @ 120Hz

●

Supports High Definition Content Protection ( HDCP )

●

28AWG, Aluminum/Mylar Shielding

Specifications

OVERVIEW

UPC Code 037332185846

INPUT

Cable Length (ft.) 30
Cable Length (m) 9.1

PHYSICAL

1 / 2

Color Black
Shipping Dimensions (hwd / cm) 30.48 x 25.40 x 1.27
Shipping Dimensions (hwd / in.) 12.00 x 10.00 x 0.50
Shipping Weight (kg) 0.48
Shipping Weight (lbs.) 1.06

CONNECTIONS

Side A - Connector 1 DISPLAYPORT (MALE)
Side B - Connector 1 DISPLAYPORT (MALE)

FEATURES & SPECIFICATIONS

Technology DisplayPort

WARRANTY

Product Warranty Period
(Worldwide)

Lifetime limited warranty
