Tripp-Lite P136-06N-ACT Data Sheet

DisplayPort to HDMI Active Adapter Video
Converter, HDCP, 4K 30Hz (M/F), 6 in.

MODEL NUMBER: P136-06N-ACT

Connect a HDMI monitor to a computer with a Displayport output

Description

Tripp Lite's P136-06N-ACT, Active Displayport Male to HDMI Female adapter, allows you to connect a
computer with a Displayport output to a HDMI monitor. Supports computer video resolutions up to 1920 x
1200, and HD resolutions up to 1080p, as well as Ultra High Definition 4Kx2K up to 3840x2160. As an
active adapter, it converts both Single-Mode and Dual-Mode (DP++) DisplayPort output. It’s perfect for
use with graphics cards, such as AMD Eyefinity, that do not output DP++ signals. Fully molded ends
ensure long life enjoyment

Highlights

●

Active adapter cable for use with
any Displayport port

●

Connect a HDMI monitor to a
computer with a Displayport
output

●

Supports Ultra High Definition (
UHD ) 4K x 2K video resolutions
up to 3840x2160

System Requirements

●

Computer with Displayport
output

●

Display with HDMI input

Package Includes

●

DisplayPort to HDMI Active
Converter, 1920x1200/1080P
(M/F) 6-in.

Features

●

Actively converts ALL Displayport signals ( Single-Mode and Dual-Mode (DP++) )

●

Perfect for use with graphics cards, such as AMD Eyefinity, that do not output DP++ signals

●

Converts Displayport to HDMI

●

Supports Ultra High Definition ( UHD ) 4K x 2K video resolutions up to 3840x2160

●

Displayport 1.1a compliant

●

Plug and Play...no software or drivers

●

No external power required

Specifications

OVERVIEW

UPC Code 037332186324

INPUT

1 / 2

Cable Length (in.) 6
Cable Length (cm) 15.24

PHYSICAL

Color Black
Shipping Dimensions (hwd / cm) 4.57 x 12.19 x 13.72
Shipping Dimensions (hwd / in.) 1.80 x 4.80 x 5.40
Shipping Weight (kg) 0.14
Shipping Weight (lbs.) 0.30

CONNECTIONS

Side A - Connector 1 DISPLAYPORT (MALE)
Side B - Connector 1 HDMI (FEMALE)

FEATURES & SPECIFICATIONS

Technology HDMI; DisplayPort

WARRANTY

Product Warranty Period
(Worldwide)

3-year limited warranty
