Tripp Lite OMNIVS1000 User Manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
Model #: OMNIVS1000
Highlights
1000VA / 1kVA tower 120V line interactive UPS
Corrects brownouts as low as 89V without using battery power
6 UPS battery supported outlets, 2 surge-only outlets
USB port, TEL/DSL/ethernet protection
NEMA 5-15P input plug and 8 NEMA 5-15R outlets
Description
Tripp Lite's OMNIVS1000 line interactive UPS system offers voltage regulation, surge suppression and long lasting battery support for personal
computers, internetworking equipment and other sensitive electronics. Internal UPS circuits support entry level PC systems for up to 60 minutes
during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits regulate
brownouts as low as 89 volts back to usable levels without using battery power. Offers complete desktop power protection in an attractive black
tower configuration. Includes 6 battery supported outlets for computer, monitor and one vital system peripheral, plus 2 additional surge
suppression-only outlets for printers and other system accessories not requiring battery support. USB port enables optional unattended system
shutdown without data loss in the case of extended power failure, USB cable included. PowerAlert software available via free download from
www.tripplite.com. Built-in RJ45 TEL/Ethernet suppression jacks protect modem, fax machine, cordless phone or other peripheral with a standard
single-line tel/DSL or data line connection. Built-in audible alarm and 4 front panel LEDs indicate line power status, battery power status, battery
low/replace status and overload. 1000VA/500 watt power handling ability supports entry-level PCs, network workstations, point-of-sale equipment,
small business phone systems, audio/video equipment and home theater systems. Offers 3.5 minutes battery runtime with a full load of 1000VA/500
watts and 14 minutes with a half load of 500VA/250 watts. Supports battery replacement via built-in access panel. $200,000 connected equipment
insurance (USA and Canada Only).
Package Includes
OMNIVS1000 Line Interactive UPS USB and telephone cable User manual with warranty information
Features
OMNIVS1000 Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support Supports entry level PCs up to 60 minutes during blackouts to enable shutdown without data loss Regulates brownouts as low as 89 volts back to usable levels without using battery power 6 UPS battery supported outlets, plus 2 additional surge suppression-only outlets USB port and cable enables unattended shutdown in the case of extended power failure PowerAlert software available via free download from www.tripplite.com Built-in RJ45 TEL/Ethernet suppression jacks protect modem, fax machine, cordless phone or other peripheral with a standard single-line tel/DSL or data line connection
Audible alarm and 4 front panel LEDs offer complete UPS and line power status information 1000VA/500 watt power handling ability supports a variety of sensitive electronic equipment
3.5 minutes full load runtime (1000VA/500 watts), 14 minutes half load runtime (500VA/250 watts) Supports battery replacement via built-in access panel Short circuit protection in AC and battery mode $200,000 connected equipment insurance (USA and Canada Only)
Specifications
OUTPUT
Output Volt Amp Capacity (VA)
1000
Output Watt Capacity (watts)
500
Nominal Output Voltage(s) Supported
115V; 120V
Frequency compatibility 60 Hz
Output voltage regulation (Battery mode)
115V (+/- 5%)
Built-in UPS output receptacles
8 5-15R outlet(s)
Surge suppression only outlets
6 UPS outlets, 2 surge-only outlets
Output AC waveform (AC mode)
Sine wave
Output AC waveform (battery mode)
PWM sine wave
INPUT
Rated input current (at maximum load)
12A
Nominal Input Voltage(s) Supported
120V AC
UPS input connection type 5-15P
UPS Input cord length (ft.) 6
UPS Input cord length (m) 1.8
Recommended Electrical Service
15A 120V
BATTERY
Full load runtime (minutes) 3.5 min. (500w)
Half load runtime (minutes) 14 min. (250w)
DC system voltage (VDC) 12
Battery recharge rate (included batteries)
Less than 4.5 hours from 10% to 90%
Replacement battery cartridge (internal UPS battery replacement)
RBC51
Battery Access Battery access door
Battery replacement description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation description
Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
Undervoltage correction Input voltages between 89 and 105 are boosted by 14%
LEDS ALARMS & SWITCHES
LED Indicators 4 LEDs indicate line power, battery power, overload and battery low/replace status
Alarms Audible alarm indicates power-failure and low-battery conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule rating
510
UPS AC suppression response time
Instantaneous
UPS Dataline suppression 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC noise suppression
Yes
PHYSICAL
Installation form factors supported with included accessories
Tower
Installation form factors supported with optional accessories
Wallmount (UPSWM - tower mounting kit)
Primary form factor Tower
UPS / Power Module dimensions in primary form factor (height x width x depth / inches)
10.8 x 5.2 x 7.5
UPS / Power Module dimensions in primary form factor (height x width x depth / cm)
27.3 x 13.3 x 19
UPS / Power Module weight (lbs)
18.4
UPS / Power Module weight (kg)
8.4
UPS Shipping dimensions (height x width x depth / inches)
14 x 8.5 x 11
UPS Shipping dimensions (height x width x depth / cm)
35.6 x 21.6 x 27.9
Shipping weight (lbs) 19.9
Shipping weight (kg) 9
UPS housing material PVC
ENVIRONMENTAL
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full load)
70.8
Battery mode BTU / hr. (full load)
694.4
COMMUNICATIONS
Communications interface USB (HID enabled)
PowerAlert software Free download from www.tripplite.com
Communications cable USB interface cable included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 4 milliseconds
Low voltage transfer to battery power (setpoint)
89
High voltage transfer to battery power (setpoint)
139
SPECIAL FEATURES
Cold Start (startup in battery mode during a power failure)
Cold-start operation supported
High availability UPS features
Hot swappable batteries
Green & high efficiency features
Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B
(EMI)
WARRANTY
Product Warranty Period (U.S. & Canada)
3-year limited warranty
Product Warranty Period (International)
2-year limited warranty
Product Warranty Period (Mexico)
3-year limited warranty
Product Warranty Period (Puerto Rico)
3-year limited warranty
Connected Equipment Insurance (U.S., Canada & Puerto Rico)
$200,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Related Model Description Qty.
DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial lines 1
DNET1 Network Surge Suppressor - Essential protection for data and communication lines 1
DTEL2 Network Surge Suppressor - Essential protection for data and communication lines 1
UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws, 1 Velcro safety
strap)
1
U022-010 10-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1
WEXT5-OMNI 5-Year Extended Warranty - For OmniSmart, OmniPro, OmniVS 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?variables.txtModelID=2656.
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
