OmniSmart LCD 120V 900VA 475W Line-Interactive
UPS, Tower, LCD display, USB port
MODEL NUMBER: OMNI900LCD
Highlights
900VA tower 120V line
interactive UPS with LCD display
Corrects brownouts as low as
89V without using battery power
LCD screen reports input voltage,
battery charge and UPS status
USB port, Surge-only outlets,
97% efficiency
NEMA 5-15P input plug and 8
NEMA 5-15R outlets
Package Includes
OMNI900LCD UPS System
Instruction manual
Description
Tripp Lite's OMNI900LCD Line-Interactive Digital UPS System offers voltage regulation, surge suppression and long lasting battery support for personal
computers, home entertainment systems and media centers. Internal UPS circuits support entry level PCs for up to 50 minutes or individual VCR/DVR
components for as long as 2.5 hours during power failures. Prevents data loss, viewing interruptions, lost recordings and loss of component programming.
Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 89 volts back to usable levels without using battery power. 97% line-mode efficiency
saves energy and reduces BTU heat output. Offers complete power protection in an attractive black tower configuration. Includes 4 battery-supported and
surge-protected outlets, plus 4 additional surge suppression-only outlets for items not requiring battery support. USB port enables optional unattended system
shutdown without data loss in the case of extended power failure. PowerAlert software available via free download from www.tripplite.com. HID-compliant USB
interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Built-in audible alarm and large LCD
front panel voltage display indicates line power status, battery power status, battery low/replace status and voltage boost operation. The LCD display includes
a dimmer switch and can be rotated for easy viewing in any application. 900VA/475 watt power handling ability supports entry-level PCs, home entertainment
systems, network workstations, audio/video components. Offers 3 minutes battery runtime with a full load of 900VA/475 watts and 10 minutes with a half load
of 450VA/237 watts. Supports battery replacement via built-in access panel. $200,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only).
Features
LCD Display with dimmer switch indicates input voltage, battery capacity and a variety of operating conditions. Display is rotatable for easy viewing
whether UPS is in vertical or horizontal position
OMNI900LCD Digital Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support during blackouts
Supports entry level PCs up to 50 minutes or single VCR/DVR components for up to 2.5 hours during blackouts
97% line-mode efficiency saves energy and reduces BTU heat output
Regulates brownouts as low as 89 volts back to usable levels without using battery power
4 UPS battery-supported and surge-protected outlets, plus 4 additional surge suppression-only outlets
USB port enables unattended shutdown in the case of extended power failure(user supplies cable)
HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
PowerAlert software available via free download from www.tripplite.com
900VA/475 watt power handling ability supports a variety of sensitive computer, home theater and other equipment
3 minutes full load runtime(900VA/475 watts), 10 minutes half load runtime(450VA/237 watts)
Cabinet adapts to tower format or rackmount shelf format. Rackmount(2U) format requires an optional shelf, available separately
Supports battery replacement via built-in access panel
Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
$200,000 Ultimate Lifetime Insurance(U.S., Canada, and Puerto Rico only)
Specifications
OUTPUT
Output Volt Amp Capacity (VA) 900
Output Watt Capacity (Watts) 475
Nominal Output Voltage(s)
Supported
Nominal Voltage Details 115v nominal output in battery mode
Frequency Compatibility 60 Hz
Output Voltage Regulation (Battery
Mode)
Output Receptacles (8) 5-15R
UPS Output Receptacles (Surge
Suppression Only)
Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)
Output AC Waveform (AC Mode) Sine wave
Output AC Waveform (Battery Mode) PWM sine wave
INPUT
Rated input current (Maximum Load) 12A
Nominal Input Voltage(s) Supported 120V AC
UPS Input Connection Type 5-15P; Right-Angled
UPS Input Cord Length (ft.) 6
UPS Input Cord Length (m) 1.8
110V; 115V; 120V
+/- 5%
4 UPS outlets, 4 surge-only outlets
Recommended Electrical Service 15A 120V
Input Phase Single-Phase
BATTERY
Full Load Runtime (min.) 3 min. (475w)
Half Load Runtime (min.) 10 min. (240w)
DC System Voltage (VDC) 12
Battery Recharge Rate (Included
Batteries)
Less than 16 hours from 10% to 90%
Internal UPS Replacement Battery
Cartridge
Battery Access Battery access door
Battery Replacement Description Hot-swappable, user replaceable batteries
Expandable Runtime No
VOLTAGE REGULATION
Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
Undervoltage Correction Input voltages between 89 and 104 are boosted by 14%
USER INTERFACE, ALERTS & CONTROLS
Front Panel LCD Display
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness
Alarm Cancel Operation
Audible Alarm Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software
LED Indicators Front panel LCD display
RBC51
Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace
battery status; LCD screen rotates for rack/tower viewing
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
SURGE / NOISE SUPPRESSION
UPS AC Suppression Joule Rating 870
UPS AC Suppression Response
Time
EMI / RFI AC Noise Suppression Yes
PHYSICAL
Installation Form Factors Supported
with Included Accessories
Primary Form Factor Tower
UPS Power Module Dimensions
(hwd, in.)
UPS Power Module Dimensions
(hwd, cm)
UPS Power Module Weight (lbs.) 15.1
UPS Power Module Weight (kg) 6.86
UPS Shipping Dimensions (hwd / in.) 15.55 x 10.43 x 4.8
UPS Shipping Dimensions (hwd /
cm)
Shipping Weight (lbs.) 15.85
Instantaneous
Tower
11.8 x 3.7 x 7.2
30.1 x 9.3 x 18.4
39.5 x 26.5 x 12.3
Shipping Weight (kg) 7.2
UPS Housing Material ABS
ENVIRONMENTAL
Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC Mode BTU / Hr. (Full Load) 61
AC Mode Efficiency Rating (100%
Load)
COMMUNICATIONS
Communications Interface USB (HID enabled)
PowerAlert Software Free download from www.tripplite.com
Communications Cable User supplies USB cable
WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
Network UPS Tools Compatibility
LINE / BATTERY TRANSFER
Transfer Time 4 milliseconds (AC to Battery); 3 milliseconds (Battery to AC)
Low Voltage Transfer to Battery
Power (Setpoint)
High Voltage Transfer to Battery
Power (Setpoint)
SPECIAL FEATURES
Cold Start (Startup in Battery Mode
During a Power Failure)
97%
NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at
http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
89
139
Cold-start operation supported
Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications
WARRANTY
Product Warranty Period (U.S. &
Canada)
Product Warranty Period (Latin
America)
Product Warranty Period
(International)
Product Warranty Period (Mexico) 3-year limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico)
Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B
(EMI); ROHS (Restriction of Hazardous Substances)
3-year limited warranty
3-year limited warranty
2-year limited warranty
$200,000
Ultimate Lifetime Insurance
