Model #: OMNI750ISO

OmniSmart UPS with built-in isolation transformer - Provides battery support during blackouts, voltage regulation during brownouts and continuous line filtering with built-in isolation transformer

Highlights

750VA line interactive UPS with built-in isolation transformer

Maintains 120V nominal output over an input range of 81 to 143V

Built-in USB communications port

Input: NEMA 5-15P (120V 15A) / Output: 6 NEMA 5-15R (120V)

2 year product warranty

Description

Tripp Lite's OMNI750ISO offers complete UPS protection with built-in line-interactive voltage regulation, intelligent monitoring and unattended

shutdown capability. Built-in isolation transformer with Faraday shield offers full isolation and complete common mode noise rejection. 750VA

power-handling capacity supports point-of-sale applications, computers, internetworking equipment and home theater systems during commercial

power failures. Line-interactive voltage regulation corrects brownouts as low as 81V and overvoltages as high as 143V back to normal 120V levels,

saving battery power for use during complete power failures. Built-in USB communications port works with PowerAlert Software and cabling to

provide automatic unattended shutdown of connected network and PC applications.

Applications

Ideal for providing a continuous clean grounding reference, voltage regulation and backup power for sensitive POS, networking and home-theater applications

Package Includes

OMNI750ISO UPS system USB cable User manual with warranty information

Features

750VA line-interactive UPS with Faraday-shielded, low-impedance isolation transformer delivers full isolation from potential damage and performance problems Provides immunity from EMI/RFI line noise in both normal and common modes. Delivers clean signal-reference ground, reducing data errors and audio/video distortion Automatic voltage regulation (AVR) automatically corrects incoming voltage to keep equipment working through low voltage (brownouts) as low as 81V and overvoltages as high as 143V without consuming battery power Supports loads up to 750VA/500W Offers 31 min. battery runtime with a half load of 375VA/250W and 13 min. with a full load of 750VA/500 watts Electrostatic discharge (ESD) resistance reduces potential static damage to connected electronics Built-in USB port and PowerAlert Software (free via web download) provide safe, unattended system shutdown during extended blackouts Built-in surge suppression (backed by $200,000 Ultimate Lifetime Insurance) safeguards connected equipment against damage

SURGE VOLTAGE WITHSTAND CAPABILITY: ANSI/IEEE C62.41 Catagories A & B 6KV/200/500 amp 100Khz Ringwave and category B BiWave SURGE VOLTAGE ATTENUATION: N-G 2000:1, L-G 240:1, L-N 100:1 INSERTION LOSS: 65 db N-G from 10Khz to 100Khz, 45 to 60 db L-G from 10Khz to 100Khz, 18 to 54 db L-N from 50Khz to 500 Khz 6 UPS-supported AC outlets; 6-ft. cord 5 diagnostic LEDs indicate AC present, on battery, voltage correction status, overload and battery low/replace 2-year product warranty

Specifications

SYSTEM OVERVIEW

Voltage compatibility 120V

Frequency compatibility

60Hz

OUTPUT

Output VA 750

Output watts 500

Output nominal voltage

120V (line mode) ; 115V (battery mode)

Output voltage regulation

Line Mode: Sine wave line voltage 120V (+8%/-18%) / BATTERY MODE: 115V (+/-5%)

Output frequency regulation

Line Mode: Passes line frequency of 60Hz. +/-10%

Outlet quantity / type 6 NEMA 5-15R

INPUT

Maximum input amps

5.5A

Input connection type

NEMA 5-15P

Input cord length 6ft./1.8m

Recommended Electrical Service

15A, 120V

BATTERY

Full load runtime 13 min. (750VA/500W)

Half load runtime 31 min. (375VA/250W)

DC system voltage 36VDC

Typical battery lifespan

4-6 years (typical)

Battery recharge rate 2-4 hours to 90%

Replacement Battery Cartridge

RBC51 (3 required)

VOLTAGE REGULATION

Voltage regulation description

Line-interactive UPS offers two boost levels of brownout correction and one voltage reduction level for overvoltage correction to maintain usable, computer grade output

Overvoltage correction

Input voltages between 128-143V are reduced by 9%

Brownout correction Input voltages between 97-107V are boosted by 10%

Severe brownout correction

Input voltages between 81-96V are boosted by 21%

LEDS ALARMS & SWITCHES

Front panel LEDs 5 front-panel status indicactor LEDs for line power, battery power, voltage regulation, overload and battery low/replace

status

Alarms Audible alarm indicates power failure conditions, silenceable via alarm cancel switch. Once cancelled, alarm will resume

when approximately 2 min. of battery operation remain (assuming full load)

Switches 2 front panel-mounted push-button switches for system enable, self-test and alarm cancel functions

SURGE / NOISE SUPPRESSION

AC surge suppression

SURGE VOLTAGE WITHSTAND CAPABILITY: ANSI/IEEE C62.41 Catagories A & B 6KV/200/500 amp 100Khz Ringwave and category B BiWave. SURGE VOLTAGE ATTENUATION: N-G 2000:1, L-G 240:1, L-N 100:1. INSERTION LOSS: 65 db N-G from 10Khz to 100Khz, 45 to 60 db L-G from

AC suppression response time

Instantaneous

Dataline suppression

EMI / RFI AC noise suppression

Yes

PHYSICAL

Shipping weight (lbs)

Shipping weight (kg) 18.2

Shipping Dimensions (HWD/in)

18.25 x 13.75 x 12

Shipping Dimensions (HWD/cm)

46.4 x 34.9 x 30.5

Unit weight (lbs) 36.4

Unit weight (kg) 16.5

Unit Dimensions (HWD/in)

12.75 x 9.25 x 7.5

Unit Dimensions (HWD/cm)

32.4 x 23.5 x 19.1

Material of construction

PVC

Form factors supported

Tower

Cooling method Fan

Battery Access Battery access door

ENVIRONMENTAL

Relative Humidity 0 to 95%, non-condensing

Storage Temperature +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Operating Temperature

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

COMMUNICATIONS

Network monitoring port

USB

Software and cabling included

USB cable included; PowerAlert software is available via free download from www.tripplite.com

WatchDog compatibility

Yes with optional WATCHDOGSW

LINE / BATTERY TRANSFER

Transfer time from line power to battery mode

2-4 milliseconds

Low voltage transfer to battery power

81V (resets to line power as line voltage increases to 85V or higher)

High voltage transfer to battery power

143V (switches to line power as line voltage decreases to 139V or lower)

SPECIAL FEATURES

Cold Start Inverter can be cold started to enable temporary AC output during a power failure

Appearance Attractive all-black color scheme

CERTIFICATIONS

Certifications Tested to UL1778 (USA), CSA C22.2 No. 107.3 (Canada), Class B (Emissions)

WARRANTY

Product Warranty Period

2 years

Connected Equipment Coverage

$200,000

Optional Coverage 3-year, 5-year, next-day and on-site warranty coverage available
