Tripp Lite NPOE-EXT-1G30WP User Manual

Gigabit Ethernet PoE/PoE+ Extender, Water
Resistant - Cat5e/6/6a, IP65, IEEE 802.3at/af,
30W, 1 Port

MODEL NUMBER: NPOE-EXT-1G30WP

Highlights

●

Saves money by delivering 30W
of power + data up to 328.08-ft.
(100 m) through existing cabling

●

Cascade up to 4 extenders to
extend PoE connection up to
1640 ft. (500 m) total

●

Extends power + data to any
PoE or PoE+ device installed
where no AC outlet is available

●

Supports Gigabit Ethernet data
transfer speeds up to 1000
Mbps (1 Gbps)

●

Aluminum housing is IP65 rated
for protection against water
spray from all directions

Extends a 10/100/1000 Mbps network connection between a powered source device and a PoE/PoE+
device up to 328 ft. (100 m).

Features

Gigabit Extender Lets You Cascade Your Existing PoE/PoE+ Connection up to 500 Meters

This single-port connector allows you to extend the connection between your powered source device,
such as a PoE (Power over Ethernet) switch, and a remote PoE device an extra 328.08-ft. (100 m). In
addition, by cascading as many as four NPOE-EXT-1G30 extenders, you can extend that connection as
far as 1640 feet (500 meters) total. Just connect the extender between two sections of Cat5e/6/6a cable
up to 328.08-ft. (100 m) each.

Saves You Time and Money on Unnecessary Equipment Updates

The compact PoE/PoE+ extender delivers 10/100/1000 Mbps of data and up to 30 watts of power using
existing Cat5e/6/6a cables, eliminating the need to install new AC power lines and electrical outlets. This
cost-effective extender sends DC power and Ethernet data through your Ethernet cable, cutting down on
cable clutter, equipment costs and installation time and labor. It also automatically detects PoE/PoE+
equipment and protects it from being damaged by incorrect installation.

Supports Power over Ethernet to Save You Money and Give You More Installation Choices

Because this extender supports PoE, it can supply the power to operate compatible IEEE 802.3at/af PoE
devices, such as security cameras, VoIP telephones, point-of-sale kiosks and access control devices. This
saves you the expense and effort of purchasing, connecting and installing individual power supplies for
each device. It also helps you install PoE devices in areas far away from AC outlets, such as poles or
ceilings. It supports half/full-duplex 1 Gbps communication for sending and receiving data simultaneously,
and protects your PoE device against short circuits and overloads.

IP65 Rating Denotes Resistance to Dust and Water

The IP65 rating means the aluminum housing is not only 100% protected against dust, but also able to
endure water spray, such as from a nozzle, from all directions. This makes the NPOE-EXT-1G30WP
ideally suited to outdoor use.

Simple Plug-and-Play Installation Has Your Device Connected in Minutes

No configuration or software is required to add the NPOE-EXT-1G30WP to your LAN. Just connect your
switch or network jack and your PoE/PoE+ device to the shielded RJ45 Power + Data ports using existing
Cat5e/6/6a cable. LEDs indicate the unit is receiving power and is ready to transmit data.

Applications

●

Install a touchscreen kiosk or
VoIP phone in an area without a
standard power connection

●

Fill in Wi-Fi dead spots in your
office with a wireless access
point connected to your LAN

●

Set up digital signage in an
outdoor environment susceptible
to rain, such as a mall, stadium
or college campus

●

Connect security cameras and
other A/V surveillance
equipment in a video wall

System Requirements

●

Device that meets IEEE 802.3af
/ IEEE 802.3at standards

Package Includes

●

NPOE-EXT-1G30WP Gigabit
Ethernet PoE/PoE+ Extender ­IEEE 802.3at/af, 30W, 1 Port

1 / 3

Designed for Installation Almost Anywhere

Mounting holes are featured for installing the extender on a shelf, desktop, wall or any other smooth
surface with user-supplied hardware. The silver aluminum housing fits in the palm of your hand, so it is
small enough to hide away without interfering with your workflow or décor. The fanless design is ideal for
silent operation.

Specifications

OVERVIEW

UPC Code 037332236135
Product Type Extender
Technology Cat5/5e; Cat6; Cat6a

PHYSICAL

Color Silver
Primary Form Factor Desktop; Wall-mount
Unit Dimensions (hwd / in.) 5.7 x 2.4 x 1.6in

ENVIRONMENTAL

●

(2) Water-resistant covers

●

Owner’s manual

Operating Temperature Range 14 to 113 F (-10 to 45 C)
Storage Temperature Range -4 to 158 F (20 to 70 C)
Operating Humidity Range 0% to 90% RH, Non-Condensing
Storage Humidity Range 0% to 95% RH, Non-Condensing

COMMUNICATIONS

Network Speed 1Gbps
IEEE Standards Supported 802.3; 802.3ab; 802.3af; 802.3at; 802.3u; 802.3x

CONNECTIONS

Side A - Connector 1 RJ45 (FEMALE)
Side B - Connector 1 RJ45 (FEMALE)
Network Switch Ports 10/100/1000 (RJ45)

STANDARDS & COMPLIANCE

Certifications Tested to CE, FCC, RoHS, REACH

WARRANTY

Product Warranty Period
(Worldwide)

3-year limited warranty
