Tripp Lite N286-01GTX User Manual
Cisco-Compatible GLC-T SFP Mini Transceiver,
1000Base-TX Copper RJ45, Cat5e, Cat6, 328.08
ft. (100 m)
MODEL NUMBER: N286-01GTX
Adds a copper Gigabit Ethernet RJ45 connector to your 10/100/1000 network equipment. Complies with
MSA (Multi-Sourcing Agreement) standards. 100% compatible with Cisco networking hardware.
Description
The N286-01GTX Cisco GLC-T Compatible 1000Base-TX Copper RJ45 SFP Mini Transceiver with an
RJ45 Ethernet connector functions just like the Cisco® GLC-T transceiver module and is designed to
operate with Cisco networking equipment. It also meets or exceeds the GLC-T's original specifications
and complies with MSA standards.
Highlights
●
Supports data transfer rates up
to 1 Gbps
●
Auto-sensing RJ45 port with
Auto MDI/MDI-X support
●
Transmits up to 328.08-ft. (100
m) with RJ45 cabling
●
Low EMI and power dissipation
●
Supports up to 1.25 Gbps bidirection communication
System Requirements
For a list of compatible switches,
see the Switch Compatibility
document in the Resources tab or
the Technical Support page.
Package Includes
●
N286-01GTX Cisco GLC-T
Compatible 1000Base-TX
Copper RJ45 SFP Mini
Transceiver
●
Owner’s manual
This 1000Base-TX copper transceiver is fully hot-pluggable, so you can install it without shutting down the
network or rebooting your device. It supports data transfer rates up to 1 Gbps with auto-negotiation up to
328.08-ft. (100 m) and automatic MDI/MDI-X crossover support. Its metallic housing allows low EMI and
power dissipation. It supports up to 1.25 Gbps bi-directional communication.
Features
1000Base-TX Copper Transceiver with RJ45 Connector
●
Hot-pluggable for installation without rebooting or shutting down
●
Data transfer rates up to 1 Gbps
●
Transmits up to 328.08-ft. (100 m) with RJ45 cabling
●
10/100/1000 auto-sensing RJ45 port with auto MDI/MDI-X support
●
Metallic housing for low EMI and power dissipation
●
Supports up to 1.25 Gbps bi-directional communication
Designed for Use with Cisco Networking Equipment
●
Functionally equivalent to Cisco GLC-T
1 / 3
●
Meets or exceeds GLC-T specs
●
Complies with MSA standards
Specifications
OVERVIEW
UPC Code 037332197412
Technology SFP+/QSPP+/QSFP28
PHYSICAL
Shipping Dimensions (hwd / cm) 2.79 x 5.59 x 12.19
Shipping Dimensions (hwd / in.) 1.10 x 2.20 x 4.80
Shipping Weight (kg) 0.09
Shipping Weight (lbs.) 0.20
Unit Dimensions (hwd / cm) 0,84 x 1,32 x 5,69
Unit Dimensions (hwd / in.) 0.33 x 0.52 x 2.24
Unit Weight (kg) 0.02
Unit Weight (lbs.) 0.05
ENVIRONMENTAL
Storage Temperature Range -40 to 185 F (-40 to 85 C)
Relative Humidity 10 to 85% RH, Non-Condensing
Operating Temperature 32 to 158 F (0 to 70 C)
COMMUNICATIONS
Signal Range (m) 100
Transmission Distance 100 m
CONNECTIONS
Side A - Connector 1 SFP+ (MALE)
Side B - Connector 1 RJ45 (FEMALE)
FEATURES & SPECIFICATIONS
Brand Compatibility Cisco
SPECIAL FEATURES
Data Transfer Rate 1Gbps
