Tripp-Lite N254-024-6AD Data Sheet
24-Port 1U Rack-Mount Cat6a Feedthrough Patch
Panel w/90-Degree Down-Angled Ports, RJ45
Ethernet, TAA
MODEL NUMBER: N254-024-6AD
Manages and organizes Cat6a input and output cable connections in your high-density Ethernet network.
Recommended for MDFs and IDFs where quick patching changes are necessary.
Description
The N254-024-6AD 24-Port 1U Rack-Mount Cat6a Feedthrough Patch Panel meets or exceeds Cat6a
specifications and works with USOC, T568A and T568B wiring to comply with industry standards. Its 24
RJ45 ports point downward at a 90-degree angle to make installation in hard-to-reach places easier.
Highlights
●
90° down-angled RJ45 ports for
installation in tight spaces
●
No 110 punchdown termination
required
●
Heavy-duty 14 ga cold-rolled
steel construction
●
Numbered ports for easy
connection identification
●
Mounts into 1U of EIA-standard
19 in. racks
Package Includes
●
N254-024-6AD 24-Port 1U
Rack-Mount Cat6a Feedthrough
Patch Panel
●
(24) Cat6a snap-in RJ45
couplers (F/F)
●
Wall-mounting hardware
●
Assembly instructions
Recommended for MDFs (main distribution frames) and IDFs (intermediate distribution frames) where
quick patching changes are necessary, this low-profile patch panel manages and organizes the cabling in
your high-density network. No 110 punchdown termination is required. Just plug your Cat6a cables into
the RJ45 coupler jacks on both sides of the panel.
Made from heavy-duty 14-gauge cold-rolled steel, the N254-024-6AD features numbered ports to help you
identify connections. It mounts easily into 1U of an EIA-standard 19-inch rack. Mounting hardware for wall-
mount installations is included. Compliant with the Federal Trade Agreements Act (TAA) for GSA
Schedule purchases.
Features
Manages and Organizes High-Density Network Cabling
●
Meets or exceeds Cat6a specifications
●
Works with USOC, T568A and T568B wiring to comply with industry standards
●
Heavy-duty 14 ga cold-rolled steel construction
●
Recommended for MDFs and IDFs where quick patching changes are necessary
24 RJ45 Coupler Jacks
1 / 3
●
90° down-angled RJ45 ports for easy installation in tight spaces
●
Clearly numbered ports for easy connection identification
●
Low-profile form factor requires no 110 punchdown termination
Quick, Easy Installation
●
Mounts easily into 1U of EIA-standard 19 in. rack
●
Includes hardware for wall-mount installation
TAA-Compliant
●
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule Purchases
Specifications
OVERVIEW
UPC Code 037332199683
Technology Cat5/5e; Cat6; Cat6a
INPUT
Cable Length (ft.) 0
Cable Length (m) 0
PHYSICAL
Shipping Dimensions (hwd / in.) 0.500 x 19.690 x 1.850
Shipping Dimensions (hwd / cm) 1.27 x 50.01 x 4.70
Shipping Weight (lbs.) 1.7600
Shipping Weight (kg) 0.80
Color Black
CONNECTIONS
Ports 24
Side A - Connector 1 RJ45 (FEMALE)
Side B - Connector 1 RJ45 (FEMALE)
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
© 2018 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
