Tripp-Lite N250-012 Data Sheet

12-Port Cat6/Cat5 Wall-Mount Vertical 110 Patch Panel, TAA

MODEL NUMBER: N250-012

Description

Tripp Lite's Cat6 wall-mount patch panel guarantees compatibility with all networks. Color-coded for both

EIA/TIA 568a & 568b installations. Panel comes with 110-type termination blocks. This 12" panel

effortlessly mounts to a wall or desk with two "C" brackets. Mounting bracket is provided.

Highlights

●

12-port vertical wall-mount

●

110 punch down termination

●

Includes 89D mounting bracket

●

Cat6 Certified

●

Compliant with the Federal

Trade Agreements Act (TAA) for

GSA Schedule purchases

Package Includes

●

Cat6 Wall Mount Patch Panel

568B-12 Port w/bracket

●

2 mounting screws

●

Pkg wire ties

●

Instruction Sheet

Features

●

CAT6 Rated/Certified

●

UL Approved

●

110 punch down termination

●

Ports clearly numbered both on front and back

●

Labels on front enable each port to be named.

●

Color-coded label on back offers both EIA/TIA 568A & 568B wiring

●

Metal frame

●

Includes mounting bracket

Specifications

OVERVIEW

UPC Code 037332131034

Technology Cat5/5e; Cat6

PHYSICAL

Shipping Dimensions (hwd / in.) 11.020 x 3.150 x 2.170

1 / 2

Shipping Dimensions (hwd / cm) 27.99 x 8.00 x 5.51

Shipping Weight (lbs.) 0.6800

Shipping Weight (kg) 0.31

Unit Dimensions (hwd / in.) 3.3 x 10.0 x 1.9 (with bracket)

Unit Dimensions (hwd / cm) 8.382 x 25.4 x 4.82 (with bracket)

CONNECTIONS

Ports 12

Side A - Connector 1 110 IDC

Side B - Connector 1 RJ45 (FEMALE)

CERTIFICATIONS

Approvals RoHS

WARRANTY

Product Warranty Period (Worldwide)

Lifetime limited warranty

not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Tripp Lite uses primary and third-party agencies to test its products for compliance with standards.
