Cat6 Gigabit Snagless Molded Slim UTP Patch
Cable with Right-Angle Connectors (RJ45 M/M),
Blue, 1 ft.
MODEL NUMBER: N201-SR1-BL
Connects network components like printers, computers, copiers, routers, servers, modems and switches.
Ideal for high-density data centers. Slim design increases airflow in tight spaces.
Highlights
●
Over 35% slimmer than
standard Cat6 cables
●
Rated for Cat6 Gigabit/1 Gbps
communications
●
Snagless right-angle RJ45 male
connectors
●
Easy to route through cable
management panels
●
High-quality 28 AWG stranded
copper wire
Package Includes
●
N201-SR1-BL Cat6 Gigabit
Snagless Molded Slim UTP
Patch Cable (M/M), 1 ft.
Description
The N201-SR1-BL Cat6 Gigabit Snagless Molded Slim UTP Patch Cable is perfect for connecting network
components like printers, computers, copiers, routers, servers, modems and switches in high-density data
centers. Designed for fast transmission and excellent signal quality, this one-foot blue cable ensures peak
performance throughout your local area network (LAN).
Manufactured from 28 AWG copper wire, the four-pair stranded UTP N201-SR1-BL delivers speeds up to
Cat6 Gigabit/1 Gbps. Protected by a PVC jacket, this cable is more than 35% smaller in diameter than
standard Cat6 cable, which increases airflow in tight spaces and makes it easier to install around corners
and through cable management panels.
Space-saving right-angle RJ45 male connectors are easy to plug into patch panels and switches located
in adjoining spaces inside a rack. The plugs’ snagless design protects the locking tabs against being
damaged or broken off during installation. Integral strain relief ensures the cable and connectors last a
long time.
Features
Perfect Solution for Your Networking Needs
●
Ideal for connecting components like printers, computers, copiers, routers, servers, modems and
switches in high-density data centers
●
Designed for fast transmission and excellent signal quality
●
Ensures peak performance throughout your LAN
1 / 3
Page 2
●
Delivers speeds up to Cat6 Gigabit/1 Gbps
No-Snag Right-Angle RJ45 Connectors
●
Male connectors plug easily into patch panels and switches in adjoining rack spaces
●
Molded snagless boots protect locking tabs from damage during installation
Special Slim Design
●
More than 35% smaller in diameter than standard Cat6 cable
●
Increases airflow in tight spaces
●
Increased flexibility for installing around corners and through cable management panels
Premium Construction for Superior Performance
●
Made from 28 AWG copper wire
●
PVC 4-pair stranded UTP
●
Integral strain relief for long life
Specifications
OVERVIEW
UPC Code 037332193650
INPUT
Cable Length (ft.) 1
Cable Length (m) 0.3
PHYSICAL
Wire Gauge (AWG) 28
Shipping Dimensions (hwd / in.) 7.00 x 9.00 x 0.50
Shipping Dimensions (hwd / cm) 17.78 x 22.86 x 1.27
Shipping Weight (lbs.) 0.06
Shipping Weight (kg) 0.03
Color Blue
ENVIRONMENTAL
Operating Temperature Range -10 ~ 60C (14 ~ 140F)
Storage Temperature Range -20 ~ 70C (-4 ~ 158F)
Relative Humidity 10% ~ 90%, NON-CONDENSING
2 / 3
Page 3
CONNECTIONS
Side A - Connector 1 RJ45 (MALE)
Side B - Connector 1 RJ45 (MALE)
FEATURES & SPECIFICATIONS
Technology Cat6
CERTIFICATIONS
Certifications RoHS Compliant
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
© 2018 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
3 / 3
