Tripp-Lite N201-015-BK Data Sheet

Cat6 Gigabit Snagless Molded Patch Cable (RJ45
M/M) - Black, 15-ft.

MODEL NUMBER: N201-015-BK

Description

With Tripp Lite's category 6 molded patch cables you can stay ahead of the game by using this high­speed cable to distribute data, voice and video. These cables deliver stable performance up to 550MHz.
Each comes UL verified meets EIA/TIA Cat6 TIA/EIA-568-B-2.1 draft 9 standards. Constructed with high­quality copper wire and a staggered-pin plug design, near-end crosstalk levels are kept to a minimum.
Designed for use in category 6, category 5e and category 5 applications. Cat6 cables are available in a
variety of colors with a snagless boot preventing cable snags.

Features

●

Meets category 6 cabling standards.

●

Premium cabling for category 6, category 5e and category 5 applications

●

Length: 15 ft./Color: Black/Connectors: RJ45 male

●

Drastically reduce impedance & structural return loss compared to standard 100MHz wire.

●

High-quality copper wire and a staggered-pin plug design to keep near-end crosstalk levels to a
minimum

●

Feature molded connectors with integral strain relief

●

Snagless design protects the locking tabs on the RJ45 connectors from being damaged or snapped off
during installation

●

PVC 4-pair stranded UTP

●

Deliver stable performance up to 550MHz/1 Gbps communication

●

Meets most current industry standards including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568,
ISO/IEC 11801 and ETL (category 6 draft 11)

●

Available in other colors and lengths

Highlights

●

Premium cabling for Category 6,
Category 5e and Category 5
applications—rated for 550
MHz/1 Gbps communications

●

Designed to meet Category 6
specifications; reduces cross­talk and return loss

●

IEEE 802.3ab

●

PVC 4-pair stranded UTP

●

All cables feature boots with
integral strain-relief and RJ45
(Male) connectors

System Requirements

●

For 1000 Base-T (1Gbps
Ethernet), 10/100 Base-T
(Ethernet), 100 Mbps TPDDI,
155 Mbps ATM, ISDN, voice
and Token Ring TYPE 3
applications as well as EIA/TIA
applications.

Package Includes

●

15-ft. Cat6 Black Gigabit Patch
Cord Snagless Molded

1 / 2

Specifications

OVERVIEW

UPC Code 037332172969

INPUT

Cable Length (ft.) 15
Cable Length (m) 4.6

PHYSICAL

Wire Gauge (AWG) 24
Shipping Dimensions (hwd / in.) 10.000 x 8.000 x 0.500
Shipping Dimensions (hwd / cm) 25.40 x 20.32 x 1.27
Shipping Weight (lbs.) 0.4000
Shipping Weight (kg) 0.18
Color Black

CONNECTIONS

Side A - Connector 1 RJ45 (MALE)
Side B - Connector 1 RJ45 (MALE)

FEATURES & SPECIFICATIONS

Technology Cat6

WARRANTY

Product Warranty Period
(Worldwide)

Lifetime limited warranty
