Tripp Lite N201-014-BK User Manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: saleshelp@tripplite.com

Model #: N201-014-BK

14-ft. Black Cat6 Gigabit Snagless Patch Cable

Highlights

Premium cabling for Category 6, Category 5e and Category 5

applicationsrated for 550 MHz/1 Gbps communications

Designed to meet Category 6 specifications; reduces cross-talk and return loss

IEC 802.3ab

PVC 4-pair stranded UTP

All cables feature boots with integral strain-relief and RJ45 (Male) connectors

Description

With Tripp Lite's new category 6 molded patch cables you can stay ahead of the game by using this high-speed cable to distribute data, voice and

video. These cables deliver stable performance up to 550MHz. Each comes UL verified meets EIA/TIA Cat6 TIA/EIA-568-B-2.1 draft 9 standards.

Constructed with high-quality copper wire and a staggered-pin plug design, near-end crosstalk levels are kept to a minimum. Designed for use in

category 6, category 5e and category 5 applications. Cat6 cables are available in a variety of colors with a snagless boot preventing cable snags.

Tripp Lite warrants this product to be free from defects in materials and workmanship for life.

System Requirements

For 1000 Base-T (1Gbps Ethernet), 10/100 Base-T (Ethernet), 100 Mbps TPDDI, 155 Mbps ATM, ISDN, voice and Token Ring TYPE 3

applications as well as EIA/TIA applications.

Package Includes

14-ft. Cat6 Black Gigabit Patch Cord Snagless Molded

Features

Meets category 6 cabling standards

Premium cabling for category 6, category 5e and category 5 applications

Length: 14 ft./Color: black/Connectors: RJ45 male

Drastically reduce impedance & structural return loss compared to standard 100MHz wire

High-quality copper wire and a staggered-pin plug design to keep near-end crosstalk levels to a minimum

Feature molded connectors with integral strain relief

Snagless design protects the locking tabs on the RJ45 connectors from being damaged or snapped off during installation

PVC 4-pair stranded UTP

Deliver stable performance up to 550MHz/1 Gbps communication

Meets most current industry standards including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568, ISO/IEC 11801 and ETL (category 6 draft

11)

Available in other colors and lengths

Warranted to be free from defects in materials and workmanship for life

Specifications

OVERVIEW

Intended Application Computer Networking

PHYSICAL

Color Black

Style Cat6/6e/6a

Length 14 ft.

CONNECTIONS

Connector A

RJ45 (MALE)

Connector B

RJ45 (MALE)

CERTIFICATIONS

Certifications RoHS-Compliant
