Tripp-Lite N201-002-WH Data Sheet

Cat6 Gigabit Snagless Molded Patch Cable (RJ45
M/M) - White, 2-ft.

MODEL NUMBER: N201-002-WH

Description

With Tripp Lite's new Category 6 molded patch cables you can stay ahead of the game by using this high­speed cable to distribute data, voice and video. These cables deliver stable performance up to 550MHz.
Each comes UL verified meets EIA/TIA Cat6 TIA/EIA-568-B-2.1 draft 9 standards. Constructed with high­quality copper wire and a staggered-pin plug design, near-end crosstalk levels are kept to a minimum.
Designed for use in category 6, category 5e and category 5 applications. Cat6 cables are available in a
variety of colors with a snagless boot preventing cable snags.

Features

●

Meets category 6 cabling standards

●

Premium cabling for category 6, category 5e and category 5 applications

●

Length: 2 ft./Color: White/Connectors: RJ45 male

●

High-quality copper wire and a staggered-pin plug design to keep near-end crosstalk levels to a
minimum

●

Feature molded connectors with integral strain relief

●

Snagless design protects the locking tabs on the RJ45 connectors from being damaged or snapped off
during installation

●

PVC 4-pair stranded UTP

●

Deliver stable performance up to 550MHz/1 Gbps communication

●

Meets most current industry standards including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568,
ISO/IEC 11801 and ETL (category 6 draft 11)

●

Available in other colors and lengths

Highlights

●

Premium cabling for Category 6,
Category 5e and Category 5
applications—rated for 550
MHz/1 Gbps communications

●

Designed to meet Category 6
specifications; reduces cross­talk and return loss

●

IEEE 802.3ab

●

2ft White PVC 4-pair stranded
UTP

●

All cables feature boots with
integral strain-relief and RJ45
(Male) connectors

System Requirements

For 1000 Base-T (1Gbps
Ethernet), 10/100 Base-T
(Ethernet), 100 Mbps TPDDI, 155
Mbps ATM, ISDN, voice and Token
Ring TYPE 3 applications as well
as EIA/TIA applications.

Package Includes

2-ft. Cat6 White Gigabit Patch Cord
Snagless molded

Specifications

1 / 2

OVERVIEW

UPC Code 037332148070

INPUT

Cable Length (ft.) 2
Cable Length (m) 0.6

PHYSICAL

Wire Gauge (AWG) 24
Shipping Dimensions (hwd / in.) 9.00 x 7.00 x 0.50
Shipping Dimensions (hwd / cm) 22.86 x 17.78 x 1.27
Shipping Weight (lbs.) 0.08
Shipping Weight (kg) 0.04
Color White

CONNECTIONS

Side A - Connector 1 RJ45 (MALE)
Side B - Connector 1 RJ45 (MALE)

FEATURES & SPECIFICATIONS

Technology Cat6

WARRANTY

Product Warranty Period
(Worldwide)

Lifetime limited warranty
