Tripp Lite ISOBAR6ULTRA User Manual

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +[phone]

E-mail: [e-mail]

Model #: ISOBAR6ULTRA

6-Outlet Isobar Surge Protector with 6-ft Cord and All-Metal Housing

Highlights

6 outlets/6-ft cord

3330 joule rating—more joules mean more protection!

All-metal housing with diagnostic LEDs

Isolated filter banks remove damaging line noise

$50,000 Insurance for connected equipment (USA , Puerto Rico & Canada

only)

Lifetime warranty

Description

For more than 20 years, America's leading companies have trusted Tripp Lite's Isobar Premium surge and noise protectors to protect sensitive
computer, networking and telecom equipment. With more than 18 million satisfied customers, the Isobar remains the world's number one selling
premium surge protector. Loaded with a generous combination of high quality components, near indestructible all-metal case and unique noise
filtration system, the Isobar offers the highest level of protection attainable in a multi-outlet strip. Robust surge suppression circuits with sine-wave
tracking offer extreme levels of protection against the heaviest surge conditions exceeding IEEE 587 category A & B specifications and reducing
6,000V test surges to harmless levels under 35 volts. Isobar's unique protection system combines large toroidal chokes, ferrite rod-core inductors,
HF/VHF capacitors and multiple layers of metal oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise
generated by other pieces of connected equipment. ISOBAR6ULTRA offers 6 outlets arranged in three filter banks to prevent system crashes,
reboots and performance problems common as noisy system peripherals are powered off and on. Surge suppression rated at 3330 joules/97,000
amps offers network-grade protection. Widely spaced NEMA 5-15 outlets accommodate up to 4 large transformer plugs without blocking outlets.
Diagnostic LEDs confirm power availability, line fault and protection status. Includes 6 foot AC line cord with space-saving angled input plug, keyhole
mounting tabs and a set of 4 child safety covers.
PLUG/OUTLETS: Input: NEMA 5-15P/Output: 6 NEMA5-15R/6-ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz (Requires NEMA 5-15R wall receptacle)
SUPPRESSION: AC: 140V RMS Clamping/3330 joules/97,000 amps
FORMAT: Corded all-metal strip with transformer spaced outlets

Applications

Ideal for premium protection of personal computers with peripherals, network and CAD/CAM/CAE workstations, internetworking
accessories, telecommunications systems, point of sale equipment, audio/video and home theater systems in any home, office or industrial
application.

Package Includes

ISOBAR6ULTRA premium surge protector
Set of 4 outlet safety covers
Instruction manual with warranty information

Features

Tripp Lite's ISOBAR is the world's number one selling premium protector series with more than 18 million satisfied customers and a
safety-tested history of 20+ years
Robust surge suppression with sine-wave tracking protects against the heaviest of surge conditions, exceeding IEEE category A&B
specifications and reducing 6,000V test surges to harmless levels less than 35 volts.
Multi-component suppression circuits combine toroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal
oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise from other pieces of connected equipment.
6 outlets arranged in three filter banks prevent system crashes, reboots and performance problems common as noisy peripherals are
powered off and on.

Network grade surge suppression rated at 3330 joules/97,000 amps
Widely spaced outlets accommodate up to 4 large transformer plugs without blocking outlets
3 LED indicators confirm suppressor operation and site wiring status, plus warning of suppressor or electrical fault conditions
Lighted power switch with integrated 12 amp circuit breaker offers power control and overload protection
6 foot AC line cord with space-saving angled input plug6 foot AC line cord with space-saving angled input plug
Keyhole mounting tabs for installation in a variety of applications
Set of 4 outlet covers safely seal off unused outlets
120VAC, 50/60Hz electrical compatibility
$50,000 Ultimate Lifetime Insurance (USA and Canada Only)

Specifications

OVERVIEW

Intended Application Home/Office, Computer Networks

OUTPUT

Frequency
compatibility

50 / 60 Hz

Output watts 1440

Circuit Breaker (amps) 12

Outlet quantity / type 6 NEMA 5-15R

Transformer
accommodation

Supports up to 4 large transformer plug accessories without covering remaining outlets

INPUT

Nominal Input
Voltage(s) Supported

120V AC

Recommended
Electrical Service

120V (110-125V)

Input connection type NEMA 5-15P input plug

Input plug features Space-saving right angle input plug

Input cord length (ft.) 6

Input cord length (m) 1.83

Voltage compatibility
(VAC)

120

Maximum Surge Amps 135000

UPC ASSIGNMENT

Unit Carton UPC# 037332010544

LEDS ALARMS & SWITCHES

Switches Combination AC circuit breaker and two position red illuminated on/off power switch

Diagnostic LEDs PROTECTION PRESENT (green), LINE FAULT (red) and LINE OK (green)

SURGE / NOISE SUPPRESSION

AC suppression joule
rating

3330

AC suppression
response time

NM = 0 ns. CM =

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
