Page 1
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: ISOBAR2-6
2-outlet, 6-ft cord, 1410 joule, All metal housing Isobar Surge Suppressor - Premium surge, spike and line
noise protection
Highlights
2 outlets / 6-ft. cord
1410 joule rating
All metal housing
$25,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)
Description
For more than 20 years, America's leading companies have trusted Tripp Lite's Isobar Premium surge and noise suppressors to protect sensitive
computer, networking and telecom equipment. With more than 18 million satisfied customers, the Isobar remains the world's #1 selling premium
surge suppressor. Loaded with a generous combination of high quality components, near indestructible all-metal case and enhanced noise filtration
system, Isobars offer the highest level of protection. Robust surge suppression circuits with sine-wave tracking offer extreme levels of protection
against the heaviest surge conditions exceeding IEEE 587 category A & B specifications and reducing 6,000V test surges to harmless levels under
35 volts. Isobar's unique protection system combines large toroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of
metal oxide varistors into a complete surge and EMI/RFI noise reduction system. ISOBAR2-6 offers 2 outlets with network-grade surge suppression
rated at 1410 joules/48,000 amps. Widely spaced NEMA 5-15 outlets accommodate up to 2 large transformer plugs. Includes 6 foot AC line cord
with space-saving angled input plug and keyhole mounting tabs.
PLUG/OUTLETS: Input: NEMA 5-15P/Output: 2 NEMA5-15R/6 ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz (Requires NEMA 5-15R wall receptacle)
SUPPRESSION: AC: 140V RMS Clamping/1410 joules/48,000 amps
FORMAT: Corded all-metal strip
Applications
Ideal for premium protection of personal computers with peripherals, network and CAD/CAM/CAE workstations, internetworking
accessories, telecommunications systems, point of sale equipment, audio/video and home theater systems in any home, office or industrial
application.
Package Includes
ISOBAR2-6 Surge Suppressor
Set of 4 outlet safety covers
Instruction manual with warranty information
Features
Tripp Lite's ISOBAR is the world's #1 selling premium suppressor series with more than 18 million satisfied customers and a safety-tested
history of 20+ years
Robust surge suppression with sine-wave tracking protects against the heaviest of surge conditions, exceeding IEEE category A&B
specifications and reducing 6,000V test surges to harmless levels less than 35 volts
Multi-component suppression circuits combine toroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal
oxide varistors
2 AC outlets accommodate up to 2 large transformer plugs
Network grade surge suppression rated at 1410 joules/48,000 amps
Widely spaced outlets accommodate up to 2 large transformer plugs without blocking outlets
Page 2
Lighted power switch with integrated 12 amp circuit breaker offers power control and overload protection
6 foot AC line cord with space-saving angled input plug
Keyhole mounting tabs allow permanent installation
120V AC, 50/60Hz electrical compatibility
$25,000 Ultimate Lifetime Insurance (USA and Canada Only)
Specifications
OVERVIEW
Intended Application Home/Office, Computer Networks
OUTPUT
Frequency compatibility 50 / 60 Hz
Output watts 1410
Circuit Breaker (amps) 12
Outlet quantity / type 2 NEMA 5-15R
Transformer accommodation Supports up to 2 large transformer plug accessories without covering remaining outlets
INPUT
Nominal Input Voltage(s)
Supported
120V AC
Recommended Electrical
Service
120V (110-125V)
Input connection type NEMA 5-15P input plug
Input plug features Space-saving right angle input plug
Input cord length (ft.) 6
Input cord length (m) 1.83
Voltage compatibility (VAC) 120
Maximum Surge Amps 60000
LEDS ALARMS & SWITCHES
Switches Combination AC circuit breaker & 2 position red illuminated on/off switch
SURGE / NOISE SUPPRESSION
AC suppression joule rating 1410
AC suppression response
time
NM = 0 ns. CM =
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping voltage (RMS) 140
AC suppression surge
current rating
48,000 amps (24,000 NM / 24,000 CM)
AC suppression components
used
Metal oxide varistors, toroidal balanced chokes, ferrite rod-core inductors and VHF capacitors.
Safe thermal fusing Prevents unsafe conditions during extreme extended over-voltages and catastrophic occurrences
UL1449 let through rating 400V
Page 3
IEEE587 Cat. A ringwave let
through
Less than 35 volts
EMI / RFI filtering 40-80 dB
Immunity Conforms to IEE 587 / ANSI C62.41
DATALINE SURGE SUPPRESSION
Cable (Coax) Protection No
Network (Ethernet) Protection No
PHYSICAL
Shipping weight (lbs) 2
Shipping weight (kg) 0.91
Unit Dimensions (HWD/in) 2.5 x 5 x 3.5
Unit Dimensions (HWD/cm) 6.35 x 12.7 x 8.89
Shipping Dimensions
(HWD/in)
10 x 5.75 x 2.75
Shipping Dimensions
(HWD/cm)
25.4 x 14.61 x 6.99
Unit weight (lbs) 1.6
Unit weight (kg) 0.73
Material of construction Metal
Integrated keyhole mounting
tabs
Metal end caps are fitted with keyhole mounting tabs for wallmount installation
Receptacle Color Black
AC line cord color Gray
Style Strip
Outlets center to center
measurement
Distance between vertical outlets = 38.66mm
Keyhole slot center to center
measurement
Distance between horizontal tabs = 108.43mm; Distance between vertical tabs = 58.17mm
SPECIAL FEATURES
Appearance Rugged all-metal corded strip format with high quality duplex receptacles
Right-Angle Plug Yes
CERTIFICATIONS
UL1449 3rd Edition (AC
Suppression)
Tested to UL1449 3rd Edition by ETL
cUL / CSA (Canada) Approved for Canada by ETL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Page 4
Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$25,000 Ultimate Lifetime Insurance
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=97.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
