Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: INTERNET525
Internet Office UPS System - All-in-one SOHO Solution
Highlights
6 outlets (3 UPS/surge, 3 surge-only)
Built-in jacks provide complete 1-line phone/DSL surge protection
Communications port and free software (web download) facilitate unattended shutdown
Compact cabinet design fits easily on or under any desk
$100,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)
Description
Tripp Lite's INTERNET 525 standby UPS system offers complete protection from blackouts, brownouts and transient surges on both AC and dialup
modem lines. Provides seamless battery support during brownouts and power failures with enough runtime to save and shutdown connected
equipment without data loss. Offers complete power protection in an ultra-compact, flat-pack housing with an appearance closer to a power strip
than other bulky UPS designs. Includes 3 battery supported outlets for computer, monitor and one vital system peripheral, plus 3 additional surge
suppression-only outlets for printers and other system accessories not requiring battery support. Communications port with contact closure
messaging enables optional unattended system shutdown without data loss in the case of extended power failure. PowerAlert software is available
via free download from www.tripplite.com and includes a phone cable. Built-in single line RJ11 phone suppression jacks protect modem, fax
machine, cordless phone or other peripheral with standard dialup phone connection. Built-in audible alarm and front panel LEDs offer continuous
status information regarding line and battery power operation. 525VA/300 watt power handling ability supports entry-level PC systems for several
minutes during power fail conditions. 2 year warranty. $100,000 connected equipment insurance (USA & Canada only).
Applications
Basic desktop PCs for home/home-office use, basic audio/video and home entertainment components and other sensitive electronic devices
Package Includes
INTERNET 525 Standby UPS System
Telephone cord
Instruction manual with warranty information
Features
INTERNET 525 standby UPS offers protection from blackouts, brownouts and surges on both AC and dialup modem lines
Provides seamless battery support so that connected equipment can be shutdown without data loss
3 battery supported outlets protect computer, monitor and one vital system peripheral, plus 3 additional surge suppression-only outlets for
printers and other system accessories not requiring battery support
Lightweight, ultra-compact, flat-pack housing offers an appearance closer to a power strip than most traditional bulky UPS designs
Attractive stealth black UPS color scheme
Communications port with basic messaging enables automatic system shutdown if power fails while the system runs unattended
PowerAlert software available via free download from www.tripplite.com, cable included
Built-in single line RJ11 phone suppression jacks protect peripherals with a standard dialup phone connection, phone cable included
Built-in audible alarm and front panel LEDs offer continuous status information regarding line and battery power operation
525VA/300 watt power handling ability supports entry-level PC systems for several minutes during power fail conditions
Includes attached 6 ft. AC power cord, on/off power switch
Compatible with 120V/60Hz applications in USA, Canada, Mexico and other countries
Page 2
2 year warranty, $100,000 connected equipment insurance (USA & Canada only)
Specifications
OUTPUT
Frequency
compatibility
60 Hz
Output VA 525
Output watts 300
Output nominal
voltage
120V AC
Output voltage
regulation
LINE MODE: Passes sine wave line voltage from 100-141V to connected equipment unchanged
BATTERY MODE: PWM sine wave output 120V +/-5%
Output frequency
regulation
LINE MODE: Passes line frequency of 60Hz +/-10%
BATTERY MODE: Inverter output regulated to 60Hz +/-0.5Hz
Outlet quantity / type 6 NEMA 5-15R output receptacles (3 with UPS and surge suppression / 3 with surge suppression only)
INPUT
UPS Input cord
length (ft.)
6 ft., 16 gauge
Recommended
Electrical Service
15A 120V
Maximum Input
Amps (A)
12
Maximum Input Watts 1440
Input connection type NEMA 5-15P
Voltage compatibility
(VAC)
120
BATTERY
DC system voltage
(VDC)
12
Battery Access User replaceable batteries are accessible via user accessible battery door
Full load runtime 3 minutes (450VA)
Half load runtime 10 minutes (250VA)
Typical battery
lifespan
3-6 years, depending on usage
Battery charge 2-4 hours to 90%
LEDS ALARMS & SWITCHES
Alarms Two program audible alarm beeps at regular intervals to indicate battery backup operation. Continuous alarm tone
indicates the UPS is running on battery power and is nearly depleted. Alarm also sounds during self-test operation.
Switches Power on/off switch
Front panel LEDs 2 LEDs indicate line power, battery power status
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
Conforms to IEEE 587 / ANSI C62.41 specifications
Page 3
EMI / RFI AC noise
suppression
Yes
AC suppression
response time
Instantaneous
Dataline suppression Single line TEL/DSL surge suppression with RJ-style phone connectors (center 2 wires protected, 260V clamping),
includes phone cable
PHYSICAL
Shipping weight (lbs) 11.8
Shipping weight (kg) 5.4
Unit Dimensions
(HWD/in)
4.75 x 13.25 x 8.75
Unit Dimensions
(HWD/cm)
12.1 x 33.7 x 22.2
Unit weight (lbs) 10.8
Unit weight (kg) 4.9
Cooling method Convection
Material of
construction
Plastic
Form factors
supported
Ultra-compact desk/floor mount
ENVIRONMENTAL
Relative Humidity 0 to 95%, non-condensing
COMMUNICATIONS
Network monitoring
port
Single built-in DB9 serial port supports on battery, low battery and power restored messaging. Interface supports
timed inverter shutoff after unattended shutdown. Compatible with Tripp Lite's PowerAlert and Watchdog service
software
Software and cabling
included
Includes DB9 serial cable, PowerAlert software available via free download
LINE / BATTERY TRANSFER
Transfer time from
line power to battery
mode
2-4 milliseconds
Low voltage transfer
to battery power
approx. 100V AC
High voltage transfer
to battery power
approx. 141V AC
SPECIAL FEATURES
Appearance Attractive black ultra-compact housing
Cold Start Yes, inverter can be "cold started" to enable temporary AC output during a power failure
CERTIFICATIONS
Certifications Tested to UL1778 (USA), cUL (Canada), FCC Class B (emissions), NOM (Mexico), FCC Part 68 / Industry Canada
(telecommunications)
WARRANTY
Product Warranty
Period (Worldwide)
2-year limited warranty
Page 4
Optional Coverage Optional 3 and 5 year on site or factory warranties available for select opportunities, contact Tripp Lite for more
information
Connected
Equipment Insurance
(U.S., Canada &
Puerto Rico)
$100,000 Ultimate Lifetime Insurance
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=2019.
