Tripp Lite CS16USB User Manual
Multi-Device Charging Station, 16 USB Ports,
iPad and Android Tablets, Wall-Mount Option
Black
MODEL NUMBER: CS16USB
Locking steel cabinet provides 2.4A USB charging, syncing, secure storage and cord management for up
to 16 tablets and other USB devices. Recommended for education, office, commercial, retail, industrial
and healthcare environments.
Features
Fast Charging
●
16 USB ports provide fastest charging supported by each device, up to 2.4A per port
●
Recommended for iPad®, Android™, Surface™ and Kindle™ tablets
●
Also charges mobile phones and other USB devices
●
Detachable 10-ft. (3.05 m) AC input cord with NEMA 5-15P plug
Highlights
●
Fast 2.4A USB charging,
syncing and storage for 16
devices
●
Locking steel cabinet with flowthrough ventilation
●
Adjustable device dividers and
integrated cord management
●
Ships fully assembled and
mounts to wall, desk, table or
floor
●
Detachable 10-ft. (3.05 m)
power cord
Package Includes
●
CS16USB 16-Device USB
Charging Station Cabinet, Black
●
Detachable 10-ft. (3.05 m) AC
input cord w/NEMA 5-15P plug
●
(2) Keys
●
Owner's manual
Convenient Syncing
●
USB sync uplink port connects to host computer for wired syncing
●
Compatible with wireless syncing
●
Supports simultaneous syncing and charging (up to 1.5A per port during wired syncing)
Comprehensive Protection
●
Sturdy steel construction and powder-coated finish promote long-term durability
●
Doors lock with included keys to help prevent device theft, damage or tampering
●
Flow-through ventilation helps prevent devices from overheating
●
Coated shelf shields devices from scratches and scuffs
Flexible Configuration
●
Ships fully assembled
1 / 4
●
Supports mounting to wall, desk, table, counter or floor
●
Door opens 180 degrees for improved device and service access
●
Removable dividers accommodate thicker devices
●
Firmware upgrade port for future updates
Specifications
OVERVIEW
UPC Code 037332185419
Product Type Multi-Device Charger
Charging Form Factor Stationary Cabinet
Functions Charge; Secure; Sync
Device Compatibility Tablet; Phone
Device Slots 16
INPUT
Nominal Input Voltage(s) Supported 120V AC; 230V AC
Voltage Compatibility (VAC) 110-240
Input Frequency 50 / 60 Hz (auto-select)
Input Plug Type NEMA 5-15P
Input Cord Length (ft.) 10
Input Cord Length (m) 3.05
CHARGING
Number of Charging Ports 16
Total Charging Amps 40A
Charging Method USB
Charging Port Type USB A (FEMALE)
Charging Ports Details Pass through
Charging Ports / Amps (16) 2.4A
Overcharge Protection Yes
Charging Amps per Port 2.4A
PHYSICAL
Color Black
Antimicrobial Coating No
