Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
Model #: BP72V18-2US
BP72V18-2US - 72V External 2U Rack / Tower Battery Pack for select UPS Systems
Highlights
Extends the runtime of select Tripp Lite Rackmount and tower UPS systems
with 72VDC external battery connector
Daisychain connector supports the addition of multiple BP72V18-2US external
battery packs
Description
BP72V18-2US rack / tower external battery pack offers extended battery runtime when used in conjunction with compatible 72V Tripp Lite Rack and
Tower UPS systems. Supports 2U installation in 19 inch 4 post racks with included accessories. Optional 2POSTRMKITWM enables 2 post
rackmount installation. Optional 2-9USTAND accessory enables tower placement. Supports the connection of multiple BP72V18-2US external
battery packs with built-in daisychain connector. Includes heavy gauge cabling with high current DC connector for simple installation in rackmount
and tower configurations. Compatible with these UPS Systems - SMART3000RMOD2U, SU3000RTXL2U, SU3000RTXL3U, SU3000RTXL3UHV,
SU3000RTXLCD2U, SU3000RTXLCD3U, SU3000RTXR3U, SU3000RTXR3UHW, SU3000XL, SU3000XLCD, SUINT3000RTXL2U,
SUINT3000RTXL3U and other Tripp Lite UPS systems that specify the use of this battery pack.
Applications
Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems
Package Includes
BP72V18-2US external battery pack
4 post rack mounting hardware
Warranty information
Instruction manual
Features
Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems
Supports 4 post rackmount installation using only 2 rack spaces (2U) with included accessories
Supports 2 post rackmount installation with optional 2POSTRMKITWM accessory
Supports upright tower installation with optional 2-9USTAND accessory
Supports multi-battery pack installation via built-in daisychain connector
Includes heavy gauge cabling with high current DC connectors for simple installation
Specifications
BATTERY
DC system voltage (VDC) 72
Connects to UPS via Attached cable with black 3-point DC connector
Typical battery lifespan 4-6 years typical (North America)
Page 2
PHYSICAL
Shipping Dimensions
(HWD/in)
9.3 x 26.4 x 29.3
Shipping Dimensions
(HWD/cm)
23.6 x 67.1 x 74.4
Shipping weight (lbs) 134.4
Shipping weight (kg) 61
Unit Dimensions (HWD/in) 3.4 x 17.3 x 20.8
Unit Dimensions (HWD/cm) 8.6 x 44 x 52.8
Unit weight (lbs) 88.2
Unit weight (kg) 40
Material of construction Steel
Form factors supported Ships with 4 post rackmount installation accessories; Use 2-9USTAND accessory for upright tower
placement option
WARRANTY
Product Warranty Period
(U.S. & Canada)
2-year limited warranty
Product Warranty Period
(International)
1-year limited warranty
Product Warranty Period
(Mexico)
1-year limited warranty
Product Warranty Period
(Puerto Rico)
1-year limited warranty
Optional Coverage 3 year, 5 year, next day and on-site warranty coverage available
Related Items
Optional Products
Related Model Description Qty.
WEXT3-BP72V 3-Year Extended Warranty - For All 72V Battery Packs 1
WEXT5-BP72V 5-Year Extended Warranty - For All 72V Battery Packs 1
2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select Rackmount UPS Systems 1
2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=5638.
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
