DVI over Cat5/6 Active Extender, Box-Style
Remote Receiver for Video, DVI-I Single Link, Up
to 200 ft. (60 m), TAA
MODEL NUMBER: B140-1A0
Transmit a DVI-D Single-Link signal up to 200 ft. away using a single Cat5e/6 patch cable
Description
The B140-1A0 is a receiver unit that is used with the B140-002 and B140-004 extender/splitter transmitter
units, and it transmits a DVI-D Single-Link signal up to 200-ft. (60.96 m) away using a single Cat5e/6
patch cable. To achieve maximum distance and resolution, use 24AWG Solid Wire Cat5e/6 cable (Tripp
Lite's N202-Series). The B140-1A0 is compatible with all operating systems, and is plug and play, with no
software or drivers required. It features a built-in Equalization control for adjustment of the video image.
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
Installation is simple. Connect a B140-002 or B140-004 transmitter (not included) to a DVI source using a
Tripp Lite P561-Series DVI cable (not included). Connect the B140-1A0 to a display using a Tripp Lite
P561-Series DVI cable (not included). Finally, the receiver unit is connected to an RJ45 port on the
transmitter unit using a single Cat5e/6 cable. A 1920 x 1080 @ 60Hz signal can be extended up to 150-ft.
(45.72 m) from the source,, or a 1024 x 768 @ 60Hz signal up to 200-ft. (60.96 m)
Further expand the range and number of monitors by using a B140-110 repeater unit. Add up to four
remote units (three repeaters and one active receiver) to each channel of the B140-002 or B140-004, for a
total of 4 displays per channel. (An active receiver should be the last unit in a channel) A 1920 x 1080 @
60Hz signal can be extended up to 125-ft. (38.1 m) from each repeater to the next unit in the channel, or a
1024 x 768 @ 60Hz signal can be extended up to 175-ft. (53.34 m)
Features
●
Transmit a DVI-D Single-Link signal up to 200-ft. (60.96 m) away using a single Cat5e/6 patch cable
●
For use with B140-002 or B140-004 extender/splitter transmitter units
●
Supports DVI-D Single-Link video resolutions up to 1920 x 1080 @ 60Hz
Highlights
●
For use with B140-002 or B140004 extender/splitter transmitter
units
●
Supports DVI-D Single-Link
video resolutions up to 1920 x
1080 @ 60Hz
●
Extends a 1920 x 1080 @ 60Hz
signal up to 150-ft. (45.72 m), or
a 1024 x 768 @ 60Hz signal up
to 200-ft. (60.96 m)
●
Use 24AWG, Solid Wire Cat5e/6
cable, such as Tripp Lite's
N202-Series, to achieve
maximum distance and
resolution
●
Can further expand the range
and number of monitors by
adding B140-110 repeaters
●
Compatible with all operating
systems
●
Plug and play, no software or
drivers required
●
Features a built-in Equalization
control for adjustment of the
video image
●
Compliant with the Federal
Trade Agreements Act (TAA) for
GSA Schedule purchases
System Requirements
Package Includes
●
B140-1A0 DVI over Cat5 Active
Extender Remote Unit
●
Mounting hardware
●
Screwdriver for adjustment of
Equalization
1 / 4
●
Extends a 1920 x 1080 @ 60Hz signal up to 150-ft. (45.72 m), or a 1024 x 768 @ 60Hz signal up to
200-ft. (60.96 m)
●
Use 24AWG, Solid Wire Cat5e/6 cable, such as Tripp Lite's N202-Series, to achieve maximum distance
and resolution
●
Features a built-in Equalization control for adjustment of the video image
●
Further expand the range and number of monitors by using a B140-110 repeater unit
●
Add up to four remote units (three repeaters and one active receiver) to each channel of the B140-002
or B140-004, for a total of 4 displays per channel. (An active receiver should be the last unit in a
channel)
●
A 1920 x 1080 @ 60Hz signal can be extended up to 125-ft. (38.1 m) from each repeater to the next
unit in the channel, or a 1024 x 768 @ 60Hz signal can be extended up to 175-ft. (53.34 m)
●
HDCP compatible
●
Compatible with all operating systems
●
Plug and play; no software or drivers required
●
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Specifications
●
External Power Supply with
NEMA 1-15P Plug (Input: 100240V, 50/60Hz, 0.5A; Output:
5V, 2A, 5-ft. (1.52 m)
●
Owner's Manual
OVERVIEW
UPC Code 037332156631
Product Type Cat5/Cat6 Receiver
AC Adapter Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A, 5 ft.
Technology DVI; Cat5/5e; Cat6
VIDEO
Max Supported Video Resolution 1920x1080 (1080p @ 60Hz)
Max 720P Range (ft) 200
Max 1080P Range (ft) 150
Max 1280 x 720 (720p) Range (ft) 150
Max 1920 x 1080 (1080p) Range (ft) 150
Receiver/Transceiver Video Output DVI-I
Receiver - Number of Video Outputs 1
Signal Range (ft) 200ft @ 1024 x 768 XGA 150ft @ 1920 x 1080 UXGA
Signal Range (m) 61m @ 1024 x 768 XGA 45.7 @ 1920 x 1080 UXGA
Range Extension using other Tripp
Lite product
175ft @ 1024 x 768 XGA 125ft @ 1920 x 1080 UXGA
Recommended Cabling N202-Series Cat6 Patch Cable
2 / 4
Other Tripp Lite product used to
extend range
B140-110
3D Video Supported Yes
POWER
Power Source Unit (Included)
Power Source Type AC Adapter
AC Plug Type NEMA 1-15P
External Power Supply Input Specs
(V / Hz / A)
External Power Supply Output
Specs (V / A)
External Power Supply Cord Length
(ft.)
External Power Supply Cord Length
(m.)
External Power Supply DC Barrel
Connector Specs
100-240V / 50-60Hz / 0.5A
5V/2A
4.5
1.4
OD: 5.5 x 2.1 x 7.5mm, Positive Pin, Negative Sleeve
External Power Supply Certifications FCC; PSE; TUV; UL; cUL
USER INTERFACE, ALERTS & CONTROLS
LED Indicators RJ45: Green (Connection), Orange (Data Transmission)
PHYSICAL
Color Black
Included Mounting Accessories Wallmount
Number of Displays 1
Form Factor/Mounting Options Box; Wall-mount
Shipping Dimensions (hwd / cm) 5.59 x 18.29 x 16.51
Shipping Dimensions (hwd / in.) 2.20 x 7.20 x 6.50
Shipping Weight (kg) 0.49
Shipping Weight (lbs.) 1.08
Unit Dimensions (hwd / cm) 2.54 x 6.35 x 9.14
Unit Dimensions (hwd / in.) 1 x 2.5 x 3.6
Unit Packaging Type Box
Unit Weight (kg) 0.20
Unit Weight (lbs.) 0.43
Housing Metal
ENVIRONMENTAL
3 / 4
Operating Temperature Range 32 to 104 °F (0 to 40 °C)
Storage Temperature Range 5 to 122 °F (-15 to 50 °C)
Relative Humidity 0% to 85%, Non-Condensing
COMMUNICATIONS
Max 1024 x 768 Range (ft) 200
Max 480P Range (ft) 200
Max 1440 x 900 Range (ft) 200
Max 1080i Range (ft) 150
Max 480i Range (ft) 200
Max 640 x 480 Range (ft) 200
Max 800 x 600 Range (ft) 200
Max 1600 x 1200 Range (ft) 200
EDID Compatible Yes
Consumer Electronics Control (CEC)
Supported
USB Extension Support No
CONNECTIONS
Ports 1
Side A - Connector 1 RJ45 (FEMALE)
Side B - Connector 1 DVI-I DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
FEATURES & SPECIFICATIONS
Driver Required No
Built-In Equalizer Yes
STANDARDS & COMPLIANCE
Certifications Tested to FCC, RoHS, REACH
WARRANTY
Product Warranty Period
(Worldwide)
Yes
1-year limited warranty
© 2021 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
4 / 4
