VGA with Audio over Cat5 / Cat6 Extender,
Wallplate Transmitter and Receiver with EDID Copy,
1920x1440 at 60Hz
MODEL NUMBER: B130-101A-WP-1
Description
Tripp Lite's B130-101A-WP-1 allows you to extend a 1920 x 1440 (60Hz) Video and Audio signal up to 500 ft., or
a 1024 x 768 (60Hz) Video and Audio signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such
as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6). For optimal image quality between 500 and 1,000
ft., use Zero-Skew cable, such as Tripp Lite P524-01K. A maximum resolution of 1920 x 1440 (60Hz) is
supported. The remote (Receiver) unit features built-in Equalization and Gain controls to adjust the video image.
Kit includes local (Transmitter) and remote (Receiver) RJ45 type wallplates, which allow you to use standard
patch cable, eliminating the need for a 110 punchdown connection. A VGA + Audio "Y" cable is included for use
with the local unit, allowing for the connection of a local monitor and speakers. Ideal for digital signage
situations, such as retail, schools, churches, etc.
Features
Extends a 1920 x 1440 (60Hz) Video and Audio signal up to 500 ft., or a 1024 x 768 (60Hz) Video and Audio
signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5)
and N222-01K-GY (Cat6)
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K
A VGA + Audio "Y" cable is included for use with the local unit, allowing for the connection of a local monitor and speakers
RJ45 type wallplates allow you to use standard patch cable, eliminating the need for a 110 punchdown connection
The remote (Receiver) unit features built-in Equalization and Gain controls to adjust the video image
Ideal for digital signage situations, such as retail, schools, churches, etc.
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Specifications
Highlights
Extends a 1920 x 1440 (60Hz)
Video and Audio signal up to 500
ft., or a 1024 x 768 (60Hz) Video
and Audio signal up to 1,000 ft.,
when using 24Awg, Solid Wire
Cat5e/6 cable, such as Tripp
Lite's N022-01K-GY (Cat5) and
N222-01K-GY (Cat6)
For optimal image quality
between 500 and 1,000 ft., use
Zero-Skew cable, such as Tripp
Lite P524-01K
RJ45 type wallplates allow you to
use standard patch cable,
eliminating the need for a 110
punchdown connection
Compliant with the Federal Trade
Agreements Act (TAA) for GSA
Schedule purchases
Package Includes
Local (Transmitter) wallplate
Remote (Receiver) wallplate
VGA + Audio "Y" cable
Mini-Screwdriver for EQ/Gain
adjustment
Wallplate Screws
(x2) External Power Supply
(Input: 100-240V, 50/60Hz, 0.5A
Output: 5V, 2A)
Owner's Manual
1 / 3
Page 2
OVERVIEW
Cable Type VGA
Display Style Extender
PHYSICAL
Shipping weight (lbs) 1.65
Shipping weight (kg) 0.75
CONNECTIONS
Connector A
(X2) HD15 (FEMALE)
Connector B
(X2) 3.5MM (FEMALE)
Connector C
(X2) RJ45 (FEMALE)
WARRANTY
Product Warranty Period (Worldwide) 1-year limited warranty
Related Items
Recommended Products
Model Number Description Qty.
N202-050-BL 50-ft. Cat6 Gigabit Solid Conductor Snagless Patch Cable (RJ45 M/M ) - Blue 1
N202-075-BL 75-ft. Cat6 Gigabit Solid Conductor Snagless Patch Cable (RJ45 M/M ) - Blue 1
N202-100-BL 100-ft. Cat6 Gigabit Solid Conductor Snagless Patch Cable (RJ45 M/M ) - Blue 1
N202-150-BL 150-ft. Cat6 Gigabit Solid Conductor Snagless Patch Cable (RJ45 M/M ) - Blue 1
N202-200-BL 200-ft. Cat6 Gigabit Solid Conductor Snagless Patch Cable (RJ45 M/M ) - Blue 1
P504-006 6-ft. SVGA/VGA Monitor + Audio Cable with Coax (HD15 M/M, 3.5mm M/M) 1
P504-010
10-ft. SVGA/VGA Monitor + Audio Cable with Coax
(HD15 M/M, 3.5mm M/M)
1
P504-015
15-ft. SVGA/VGA Monitor + Audio Cable with Coax
(HD15 M/M, 3.5mm M/M)
1
P524-01K 1000-ft. Zero-Skew UTP Bulk Patch Cable for RGB Video 1
2 / 3
Page 3
Optional Products
Model Number Description Qty.
B110-INT International AC Adapter for Tripp Lite Video over CAT5 Extenders 1
B130-101-2 VGA over Cat5 Extender Kit ( Transmitter + Receiver ) 1
B130-101A-2
VGA + Audio over Cat5 Extender Kit
(Transmitter + Receiver)
1
B130-101-WP-1 VGA over Cat5 ( RJ45 Type ) Extender Wallplate Kit ( Transmitter + Receiver ) 1
B132-002-2 VGA over Cat5 Extender 2-Port Transmitter 1
B132-002A-2 VGA / Audio over Cat5 Extender 2-Port Transmitter 1
B132-004-2 VGA over Cat5 Extender 4-Port Transmitter 1
B132-004A-2
4-Port VGA with Audio over Cat5 / Cat6 Extender Splitter, Transmitter with EDID Copy, 1920x1440
at 60Hz
1
B132-100-1 VGA over Cat5 Receiver 1
B132-100A VGA + Audio over Cat5 Receiver 1
B132-100-WP-1 VGA over Cat5 Receiver - RJ45-type Wallplate 1
B132-100A-WP-1 VGA with Audio over Cat5 / cat6 Extender, Wallplate Receiver, 1920x1440 at 60Hz 1
B132-110 VGA over Cat5 Extender Remote/Repeater Unit 1
B132-110A VGA + Audio over Cat5 Extender Remote/Repeater Unit 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/B130-101A-WP-1.
